Description

7200000462 SECONDARY SHAFT 二轴总成
29050020581 SHIM 调整垫片
29050020541 SHIM 调整垫片
29050020531 SHIM 调整垫片
29050020521 SHIM 调整垫片
29050025551 SHIM 调整垫片
4110000011081 SEAT 导轮座YB315Z5-13A
4110000011082 SEALING RING 密封环YB315Z5-33
4110000011083 SEALING RING 密封环YB315Z5-12A
4110000011085 HOUSING 壳体YB315Z5-08D
4110000011086 SCREW 螺栓M8*16 01010-50816
008617753913626 XCMG woooyeah1@163.com
4110000011087 WASHER 垫圈801602-10825
4110000011088 SPACER 垫板YB315Z5-06D
4110000011089 GASKET 胶垫YB315Z5-07D
4110000518016 GEAR 齿轮YJSW315-8B-00001
4021000076 BALL BEARING 滚动轴承GB276-6017
4110000011091 SCREW 螺栓M8*35 01010-50835
4110000518001 IMPELLER 泵轮YJSW315-8A-00003
4110000518002 NUT 螺母01580-00806 M8
4110000011121 WASHER 调整垫YB315Z5-35
4110000011094 WASHER 压紧垫片YB315Z5-22A
4110000518003 STATOR 导轮YJSW315-8A-00002
4015000208 RETAINING RING 挡圈GB894.1-85-65Mn
008617753913626 XCMG woooyeah1@163.com
4110000518013 WHEEL 罩轮YJSW315-8A-00001
4110000011113 WASHER 调整垫YB315Z5-34
4110000011096 WASHER 调整垫YB315Z5-30/31/32
4110000011114 PLATE 弹性板总成YJSW315-20000
4110000011115 PLATE 弹性板YJSW315-20001
4011000663 BOLT 螺栓GB21-M10*25EpZn-8.8
4110000011097 WASHER 垫圈10 01602-11030
4110000011098 NIPPLE 管接头YB315Z5-14S
4110000011128 WASHER 垫圈30 YB315Z5-09组合密封垫圈
4015000209
4110000011100 BRACKET 阀盖YB315Z5-17A
4110000011101 SPRING 弹簧YB315Z5-18A
4110000011102 WASHER 调压垫YB315Z5-16.21
4110000011103 VALVE ROD 阀杆YB315Z5-26A
4110000011104 PLUG 螺塞YB315Z5-15L
008617753913626 XCMG woooyeah1@163.com
4110000011105 ANCHOR PLATE 压板YB315Z5-19A
4110000011106 SPRING 弹簧YB315Z5-20
4110000011108 WASHER 垫圈12 01602-11236
4110000011109 SCREW 螺栓M12*45 01010-51245
4110000011129 NIPPLE 管接头YB315Z5-24K
4110000011116 SHIM 圆垫板YB315Z5-04
4110000518015 TURBINE 涡轮组件YJSW315-8A-10000
4110000011117 SCREW 螺栓M12*30 01010-51230
4021000018 BALL BEARING 滚动轴承GB276-6210
4110000011118 GASKET 衬垫YB315Z5-05
4030000712 O-RING O形圈GB3452.1-365*3.55G
008617753913626 XCMG woooyeah1@163.com
4110000659 CONTROL MECHANISM 变速操纵机构LG956L
4110000660 LINK ROD 变速连杆机构LG956L
4011000137 BOLT 螺栓GB16674-M12*20EpZn-8.8
4016000143 CLEVIS PIN 销轴GB882-B8*26EpZn-35
4015000072 WASHER 垫圈GB97.1-8EpZn-300HV
4016000183 SPLIT PIN 开口销GB91-3.2*22EpZn-Q235A
4110000172006 HANDLE BALL 手球LGH9530001
4110000659004 Handle 手柄组件LGH956L0001
4110000172008 COVER 盒罩LGH9530003
4110001680004 SHAFT 轴组件LGH9530004
4110000659005 Nut 螺母M10 GB6185.1
4110000746003 M16 nyong bonnet M16尼龙帽LGH9530016
4110000172027 NUT M36螺母LGH9530005
4110000746004 BOLT M5螺栓LGH9530006
4110000172028 BOX 953铝盒LGH9530007
4190002767015 PLATE 固定板LGH9530008
4110000172029 SCREW M8×1.25-30螺栓LGH9530009
008617753913626 XCMG woooyeah1@163.com
4110002042020 WASHER 弹垫Φ8 TD-002
4110002042019 WASHER 平垫Φ8 PD-002
4110000172030 PIN 六方头销轴LGH9530010
4110000172031 GEAR RACK 齿条LGH9530012
4110001680006 GEAR SLEEVE 齿轮套组件LGH9530011
4110000172032 RETAINING RING 卡簧（∮10）KH-003
4110001680007 COVER 盒盖LGH9530013
4110001680008 RACK SLEEVE 齿条筒LGH9530014
4110000659006 Control cable 软轴总成LGHR956L0001
4110000659007 Bracket 软轴支架总成LGHR956L0002
4110000659008 Retainer 连接杆LGHR956L0003
4013000033 NUT 螺母GB6170-M8EpZn-8
4015000072 WASHER 垫圈GB97.1-8EpZn-300HV
4015000036 SPRING WASHER 垫圈GB93-8-65Mn
4110000747005 PLATE 连接板LGH956L00002-1
008617753913626 XCMG woooyeah1@163.com
4110000660005 Sealing ring 密封圈GB13871-2007 12*28
4015000324 RETAINING RING 挡圈GB893.1-28-65Mn
4021000008 BALL BEARING 滚动轴承GB276-6001
4110000660006 Shaft 支架轴LGH956L00002-2
4110000660007 Bracket 支架焊合件LGH956L00002-3
29070012021 Wheel assembly 车轮总成
4190000237 RIM 轮辋LG19.50/2.5-25
4110000582 TIRE 轮胎 23.5-25-18PR-L3
4110000582S)
4110000582S)
4110000582S)
29070012561 FRONT AXLE A510前驱动桥总成
29070011032 SCREW 螺栓
4013000193 NUT 螺母GB889.2-M30*2EpZn-10
008617753913626 XCMG woooyeah1@163.com
29070012881 HUB REDUCTION 轮边减速器
4120001739 BRAKE CALIPER 制动钳
4120001740 NIPPLE 放气嘴
29070012581 SHAFT HALF 半轴
4110000818 NOZZLE 透气嘴
4011000494 BOLT 螺栓GB5786-M16*1.5*45EpZn-8.8
4015000098 SPRING WASHER 垫圈GB93-16-65Mn
29070012591 FINAL DRIVE 前主传动总成
29070012861 FRONT AXLE CASING 前桥壳总成
29070000101 BOLT 螺栓
4015000030 SPRING WASHER 垫圈GB93-20-65Mn
29070000071 DISC BRAKE 制动盘
29070000081 NUT 轮辋螺母
4011000130 BOLT 螺栓GB5786-M20*1.5*50EpZn-8.8
008617753913626 XCMG woooyeah1@163.com
29070012481 PLUG 磁性螺塞
29070012721 NAME PLATE 前桥标牌
4019000012 RIVET 铆钉GB827-3*5-BL2
4011000941 SCREW 螺栓GB5785-M20*1.5*60EpZn-10.9
29070014552 GUARD PLATE 防护板
29070011121 WASHER 垫圈
29070015101 SEALING COVER 油封端盖
4021000038 ROLLER BEARING 滚动轴承GB297-32224
29070012892 Gear ring 齿圈支架总成
29070015792 Gear ring 内齿圈
29070026451
29070010931 FRONT WHEEL HUB 轮毂
29070000621 STUD 轮辋螺栓
008617753913626 XCMG woooyeah1@163.com
4013000203 NUT 螺母GB6171-M20*1.5EpZn-10
4015000030 SPRING WASHER 垫圈GB93-20-65Mn
4041000020 O-RING O形圈LGB308-440*3.5
29070012661 PLANET CARRIER 行星轮架
29070012481 PLUG 磁性螺塞
4011000084 BOLT 螺栓GB5783-M10*30EpZn-8.8
