Description

4110000924:气缸盖GR615040439-15 cylinder head assembly
4110000556159 气缸盖罩衬垫614040021 GASKET
4110000113003 气缸盖罩614040065 CYLINDER HEAD
4110000924066 六角头螺栓90003802438 SCREW
4110001015013 出水管612600040526 PIPE 612600040526
4110000556132 密封垫圈612600080246 SEALING RING
008617753913626 SDLG woooyeah1@163.com
4110000924092 六角头螺塞90003962014 PLUG
4110000924093 方头锥形螺塞90017010003 PLUG
4110000924094 六角螺塞90003962020 PLUG
4110001015014 双温控开关612600061653 THERMOSWITCH 612600061653
4110000556125 螺堵612600040016 PLUG
008617753913626 SDLG woooyeah1@163.com
4110000591033 波形弹性垫圈90003932023 SPRING WASHER 90003932023
4110000924096 六角头螺栓90003800466 SCREW
4110000556130 密封垫圈612600080200 SEALING RING
4110000924:气缸盖罩GR615040416-16 valve cover
008617753913626 SDLG woooyeah1@163.com
4110000924:出水管总成GR615040448-17 water pipe assembly
4110000924:配气机构GR615050033-18 valve drive device
4110000924:水泵冷却系GR615060914-19 water pump assembly
4110000924:水管接头GR615060994-20 water pipe assembly
4110000924:节温器总成GR6150601191-21 thermostat kit
4110000924:张紧轮总成GR615060999-22 belt tensioner
4110000924097 凸轮轴61500050096 CAMSHAFT
008617753913626 SDLG woooyeah1@163.com
4110000556199
4110000556198 凸轮轴止推片614050133 THRUST WASHER
4110000924098 六角头螺栓90003802399 SCREW
4110000556197 凸轮轴正时齿轮614050053 GEAR
4110001015122 圆柱销90003901409 PIN
008617753913626 SDLG woooyeah1@163.com
4110000556116 六角头螺栓612600050145S SCREW
4110000924099 中间齿轮61560050052 GEAR
4110000556245
4110000556248 轴61560050058 SHAFT
4110000556120 六角头螺栓61560050059S SCREW
4110000556033 垫片61560050045 WASHER
008617753913626 SDLG woooyeah1@163.com
4110000924100 衬套61560050051 BEARING BUSHING
4110000556244 中间齿轮轴61560050044 SHAFT
4110000556089 进气门612600050073 INLET VALVE
4110000556090 进气门弹簧下座614050017 SPRING SEAT
4110000556169 气门内弹簧61500050001 VALVE SPRING
4110000556173 气门外弹簧61500050002 VALVE SPRING
4110000556170 气门锁夹61500050025 COLLET
008617753913626 SDLG woooyeah1@163.com
4110000556163 气门弹簧上座61500050109 SPRING SEAT
4110000556168 气门帽61500050105 VALVE CAP
4110000113004 进气门摇臂614050048 ROCKER ARM
4110000556166 气门间隙调整螺钉614050010 SCREW
4110000556167 气门间隙调整螺母2130050065 NUT
4110000924101 六角头螺栓90003802655 SCREW
4110000113006 气门摇臂座614050119 SEAT
008617753913626 SDLG woooyeah1@163.com
4110000924102 气门推杆总成612600050210 PUSH ROD
4110000556171 气门挺柱61500050032 TAPPET
4110000556145 排气门612600050025 EXHAUST VALVE
4110000113005 排气门摇臂614050049 ROCKER ARM
4110000924:发电机总成GR615090915-23 alternator assembly
4110000924103 水泵总成612600061739 WATER PUMP
008617753913626 SDLG woooyeah1@163.com
4110000556189 水泵密封垫614060008 GASKET
4110000924104 双头螺柱90003813470S STUD
4110000591031
4110000924105 双头螺柱900003813429S STUD
4110000924106 六角法兰面承面带齿螺母612600061719 NUT
4110001017:水管结合组 GR0607009-24 Pipe
008617753913626 SDLG woooyeah1@163.com
4110000556192 水管接头612600060171A NIPPLE
4110000556193 水管接头垫片615G00060001 GASKET
4110000924107 六角头螺栓90003800467 SCREW
4110000924108 六角头螺栓90003802424 SCREW
4110000591033 波形弹性垫圈90003932023 SPRING WASHER 90003932023
4110000924093 方头锥形螺塞90017010003 PLUG
008617753913626 SDLG woooyeah1@163.com
110000924:机油泵总成GR615070246-25 oil pump assembly
4110000556085 外置节温器615G00060016 THERMOSTAT
4110000556106 冷却液连接管612600060518 HOSE
4110001554024 胶管612600061840 RUBBER TUBE
4110000924198 卡箍612600061883 CLAMP
008617753913626 SDLG woooyeah1@163.com
4110000924:集滤器总成GR615070248-26 Oil strainer
4110000924112 六角法兰面螺栓90011400001 SCREW
4110001015023 张紧轮总成612600061510 TENSION PULLEY 612600061510
4110003115021
4110000924170 1型六角螺母90003871252 NUT
008617753913626 SDLG woooyeah1@163.com
4110000924113 双头螺柱M8*22 90003813429S STUD
4110000591030
4110001015024 张紧轮座612600012921 SEAT 612600012921
4110000924:机油滤清器总成GR615070247-27 oil filter assembly
4110000556002 1.5kW交流发电机(多楔带)612600090206D ALTERNATOR
4110000556210 压紧块612600090292 BLOCK
008617753913626 SDLG woooyeah1@163.com
4110000924122 鞍型弹性垫圈90003932025 SPRING WASHER
4110000924125 六角头螺栓90011260010 SCREW
4110001015029 拉紧块612600090663 BLOCK 612600090663
4110001015030 拉紧螺栓612600090681 SCREW 612600090681
4110000924127 1型六角螺母90003871319 NUT
4110000924126 小垫圈90003930282 WASHER
008617753913626 SDLG woooyeah1@163.com
4110000591036 2型全金属六角锁紧螺母90003888453 NUT 90003888453
4110000924128 波形弹性垫圈90003932016 WASHER
4110000556122 六角头螺栓615P00090003 SCREW
4110000924:喷油器总成GR615081428-28 fuel injection nozzle
008617753913626 SDLG woooyeah1@163.com
4110000556203 橡胶管612600530037 HOSE
4110000924110 软管卡箍90003989308 CLAMP
4110000556003 48mm加宽机油泵AZ1500070021A LUBRICATING OIL PUMP
4110000556069 机油泵垫片614070055 GASKET
008617753913626 SDLG woooyeah1@163.com
4110000924131 机油泵限压阀612630010143 PRESSURE LIMITING VALVE
4110000924132 六角法兰面承面带齿螺栓612600070411 SCREW
4110000924061 六角法兰面承面带齿螺栓90011430008 SCREW
4110000556070 机油泵中间齿轮614070061 GEAR
4110001755056
4110000924133 向心球轴承90003311410 BALL BEARING
4110000556246 中间隔圈6140749 SPACER RING
008617753913626 SDLG woooyeah1@163.com
4110000924135 带凸齿的孔用挡圈90003934732 WASHER
4110000556243 中间齿轮轴6140756 SHAFT
4110000556138 密封圈614070155 SEALING RING
4110000924136 六角头螺栓90003802578 SCREW
