Description
LGMG Off-Highway Dump Truck 2024 – Air conditioner lines installation – N0301-2703017236.S1A
Category: 2024 > Off-Highway Dump Truck > MTE106H > C106HE0A0A504
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bracket 75*25*4 | 27030172091 | 2 |
| 2 | Bracket 60*40*90 | 27630001911 | 1 |
| 3 | Evaporator outlet hose pskt105e-069b | 4190712222-001 | 1 |
| 4 | Evaporator inlet hose pskt105e-068b | 4190712223-001 | 1 |
| 5 | Bracket-100*25*4 | 27030154211 | 4 |
| 6 | Clamp R-D20-M10 | 4190707969 | 11 |
| 7 | Reinforced clamp R1-D30-M10 | 4190707981 | 11 |
| 8 | Bolt GB5783-M10*30flznyc-8.8-480 | 4011010707 | 22 |
| 9 | Washer GB97.1-10flZnyc-300HV-480 | 4015010339 | 22 |
| 10 | Nut GB6185.1-M10flZnyc-8-480 | 4013010292 | 22 |
| 11 | Bracket 110*20*4 | 27030172191 | 4 |
