Description

29050027231 箱体 Transmission housing
4011000017 螺栓GB21-M10*30EpZn-8.8 BOLT
29050015481 垫圈10 WASHER
4011001127 螺栓GB5783-M14*40-10.9 SCREW
4015000358 垫圈GB1230-14EpZn-45 PLAIN WASHER
008617753913626 SDLG woooyeah1@163.com
29050023791 二档总成 Shaft
29050022981 中盖 Cover
3030900091 端盖 END PLATE
29050011321 密封垫 Gasket
4030000011 O形圈GB1235-20*2.4 O-RING
3030900102 螺塞 PLUG
29230009951 鼓式制动器总成 Brake assembly
008617753913626 SDLG woooyeah1@163.com
29050026801 前输出法兰总成 Flange
29050036551 输出轴总成 Output shaft
29050021541 输出法兰总成 Flange
29050023121 销 Pin
29050032151 一倒档总成 Planet gear kit
29050025551 调整垫片 Shim
29050020581 调整垫片 Shim
29050020541 调整垫片 Shim
29050020531 调整垫片 Shim
29050020521 调整垫片 Shim
008617753913626 SDLG woooyeah1@163.com
7200000462 二轴总成 SECONDARY SHAFT
29050019471 超越离合器总成 Clutch
7200000462
7200000462
7200000462
2030900027 三轴总成 SHAFT
29040012411 变矩器总成YJSW315-7 Torque converter
4110003131
4110003131
4110003131
4110003131 变矩器总成YJSW315-7 Torque covertor
4021000019 滚动轴承GB276-6210N BALL BEARING
4015000024 挡圈GB894.1-90-65Mn RETAINING RING
008617753913626 SDLG woooyeah1@163.com
29050012701 轴齿轮 Drive shaft gear
29050023111 密封垫 Gasket
4021000012 滚动轴承GB276-6012 BALL BEARING
29050011361 密封垫 Gasket
29050011362
29050011362
29050011362
4011000855 螺栓GB16674-M10*55EpZn-10.9 BOLT
4120005410 变速泵LG03-BSB-A GEAR PUMP
008617753913626 SDLG woooyeah1@163.com
29050020551 调整垫片 Shim
29050020561 调整垫片 Shim
29050020571 调整垫片 Shim
29050020921 调整垫片 Shim
29050025561 调整垫片 Shim
4014000030 吊环螺钉GB825-M20EpZn-20 SCREW
29050018031 透气接头 Nipple
29050033171 螺塞R1/2 Plug
4011000174 螺栓GB21-M10*70EpZn-8.8 BOLT
4120000064 变速操纵阀LG03-BSF CONTROL VALVE
008617753913626 SDLG woooyeah1@163.com
29050011381 密封垫 Gasket
4011000097 螺栓GB5783-M18*40EpZn-8.8 BOLT
4015000029 垫圈GB93-18-65Mn SPRING WASHER
29050019321 连接座 ATTACHMENT BRACKET
2030900065 滤油器总成 OIL FILTER
29050015471 垫圈8 WASHER
4011000107 螺栓GB5783-M8*30EpZn-8.8 BOLT
008617753913626 SDLG woooyeah1@163.com
29050023011 压盖 Plate
4015000163 垫圈JB1002-39-T2 WASHER
29050023001 接头体 Nipple
4190000007 环形磁铁LG03-CT70*32*14 MAGNET
4015000013 挡圈GB893.1-70-65Mn RETAINING RING
3030900232 垫片 SHIM
4011001013 螺栓GB5782-M10*80EpZn-10.9 SCREW
29050020181 转向泵驱动齿轮 Gear
4021000020 滚动轴承GB276-6211 BALL BEARING
008617753913626 SDLG woooyeah1@163.com
29050000071 轴承套 Bearing bushing
3030900098 圆柱堵塞 PLUG
29050018471 接头体 Nipple
4030000013 O形圈GB1235-32*3.1 O-RING
29050025601 变速箱通用标牌 Name plate
4019000012 铆钉GB827-3*5-BL2 RIVET
3030900178 输入二级齿轮 DRIVE SHAFT GEAR
3030900177 输入一级齿轮 DRIVE SHAFT GEAR
008617753913626 SDLG woooyeah1@163.com
3030900110 旋转油封 SEALING RING
3030900111 旋转油封 SEALING RING
4021000023 滚动轴承GB276-6311 BALL BEARING
4021000013 滚动轴承GB276-6016 BALL BEARING
4021000040 滚动轴承GB301-51111 BALL BEARING
008617753913626 SDLG woooyeah1@163.com
29050018221 调整垫片 SHIM
29050018231 调整垫片 SHIM
29050018241 调整垫片 SHIM
29040008331 弹性板 PLATE
29040008341 轮罩 COVER
29040012431 涡轮组 Turbine
29040009571 调整垫 SHIM
29040009581 调整垫 SHIM
29040008361 圆垫板 PLATE
4011000756 螺栓GB5783-M12*25EpZn-10.9 SCREW
4015000288 垫圈GB1230-12EpZn-45 WASHER
4021000018 滚动轴承GB276-6210 BALL BEARING
4011001171 螺栓GB5782-M8*40EpZn-10.9 SCREW
4013000031 螺母GB6170-M8EpZn-10 NUT
008617753913626 SDLG woooyeah1@163.com
29050015471 垫圈8 WASHER
29040008371 弹性板总成 PLATE
4011001246 螺栓GB5783-M8*16flZnyc-8.8-480 SCREW
29040008391 垫板 PLATE
29040008401 胶垫 GASKET
29040010041 调整垫 SHIM
29040010051 调整垫 SHIM
29040008422 导轮 WHEEL
4016000327 销GB119.1-8m6*26 PIN
008617753913626 SDLG woooyeah1@163.com
4021000076 滚动轴承GB276-6017 BALL BEARING
29040008411 壳体 HOUSING
29040008451 密封环 SEALING RING
29050015481 垫圈10 WASHER
29040012371 螺栓 Screw
29040008482 导轮座 SEAT
4014000408 螺钉GB70.1-M8*30-10.9 SCREW
4021000110 滚动轴承GB276-6013 BALL BEARING
008617753913626 SDLG woooyeah1@163.com
29040008501 压紧垫片 WASHER
29040012421 泵轮 Impeller
29040008531 接头 NIPPLE
29040008431 油温表接头 NIPPLE
29040008491 管接头 NIPPLE
4030000013 O形圈GB1235-32*3.1 O-RING
29040009551 螺塞M30×1.5 PLUG
4011000917 螺栓GB5783-M8*25EpZn-10.9 BOLT
4011000754 螺栓GB5783-M8*20EpZn-10.9 SCREW
008617753913626 SDLG woooyeah1@163.com
4019000012 铆钉GB827-3*5-BL2 RIVET
29040011951 变矩器通用标牌 Name plate
29040008551 阀杆 SLIDE
29040008571 进油阀弹簧 SPRING
29040008561 阀盖 FLANGE
29040008601 回油阀弹簧 SPRING
29040008591 压板 PLATE
29040008441 齿轮 GEAR
29040009972 导轮压板 PLATE
29040008761 调压垫 SHIM
29040008541 调压垫 SHIM
29040008711 调压垫 SHIM
29040008581 调压垫 SHIM
