Description

9D652-47A012110A0     锁扣环座板焊合    Welding of Lock Ring Seat Plate
9D652-47A010002A0     隔热棉2 Heat insulation cotton 2
9D652-47A010001A0     隔热棉1 Heat insulation cotton 1
9D653-47B010001A0     隔热棉    Heat insulation cotton
9D653-47B010005C0     套管         Casing
008617753913626 XCMG woooyeah1@163.com
9D652-47B010001B1     吊环螺钉M10X55 Hanging screw M10X55
9D653-47B012200B0     后扶手焊合    Welding of rear armrest
GBT6177.1-M12-8-A3L  六角法兰面螺母    Hexagon nut with flange
9D670-47A014500A0     右后工作灯罩        Right rear working lampshade
9D670-47A014400A0     左后工作灯罩        Left rear working lampshade
9D652-47B020000A0     气弹簧总成    Air spring assembly
GBT6177.1-M10-8-DC    六角法兰面螺母    Hexagon nut with flange
GBT96.1-12-A3L     大垫圈    Big washer
008617753913626 XCMG woooyeah1@163.com
GBT16674.1-M12X30-8.8-DC         六角法兰面螺栓    Hex bolt with flange
9D670-47A040000B0     后风窗焊合    Rear windscreen weldment
9F653-47A000003A0      减震密封条    Shock absorbing seal strip
9D650-48A070000A0     左前泥瓦        Left front mudguard
9D650-48A080000A0     右前泥瓦        Right front mudguard
GBT16674.1-M12X30-8.8-A3L       六角法兰面螺栓    Hex bolt with flange
GBT96.1-12-A3L     大垫圈    Big washer
008617753913626 XCMG woooyeah1@163.com
9D659-48A030000C1     左前扶手        Left front armrest
9D659-48A040000C1     右前扶手        Right front armrest
9D861-48A010000B0     左走台焊合    Left footstand welding
9F657-47A000004A0      隔套         Spacing sleeve
GBT16674.1-M12X50-8.8-A3L       六角法兰面螺栓    Hex bolt with flange
008617753913626 XCMG woooyeah1@163.com
9D861-48A080000A0     左前支架        Left front bracket
9D861-48A100000A0     扶梯总成        Escalator assembly
9D861-48A040000A0     右支架焊合    Right bracket welding
9D861-48A060000A1     右后扶手        Right rear armrest
9D861-48A110000A0     左后泥瓦        Left rear mud tile
9D861-48A050000A1     左后扶手        Left rear armrest
9D861-48A120000A0     右后泥瓦        Right rear mud tile
9D861-48A000008A0     左后支架        Left rear bracket
008617753913626 XCMG woooyeah1@163.com
GBT16674.1-M12X45-8.8-A3L       六角法兰面螺栓    Hex bolt with flange
GBT6177.1-M12-8-A3L  六角法兰面螺母    Hex bolt with flange
9D861-48A090000A0     挡泥板总成    Fender assembly
9D861-48A020000B0     右走台总成    Right cover plate assembly
9D861-48A000001A0     右支架1 Right bracket 1
008617753913626 XCMG woooyeah1@163.com
GBT16674.1-M12X35-8.8-A3L       六角法兰面螺栓    Hex bolt with flange
9D861-48A170000A1     小扶手    Small armrest
9D861-48A180000A1     小扶手    Small armrest
9D690-48A140000A0     扶梯总成        Escalator assembly
GBT16674.1-M12X40-8.8-A3L       六角法兰面螺栓    Hex bolt with flange
9D664-48A000009A0     垫块         Pad 008617753913626 XCMG woooyeah1@163.com
9D860-54A020000A0     全液压转向器总成        Fully hydraulic steering mechanism
GBT16674.1-M10X20-8.8-A3L       六角法兰面螺栓    Hex bolt with flange
9F850-59A000001A0      聚氨酯螺旋护套    Polyurethane spiral shield
QLWZG057.1-0120950   24°锥软管总成    24°taper hose assembly
QLWZG056.3-0120550   24°锥软管总成    24°taper hose assembly
QLWZG077-001414         直角可调接头        Right angle adjustable jonit
QLWZG056.3-0040400   24°锥软管总成    24°taper hose assembly
QLWZG059.1-0160850   24°锥软管总成    24°taper hose assembly
QLWZG090-020380         分体法兰        Separated flange
008617753913626 XCMG woooyeah1@163.com
GBT16674.1-M10X30-8.8-A3L       六角法兰面螺栓    Hex bolt with flange
QLWZG080-103620         直角法兰接头        Right angle flange joint
9D680-54A020000A0     优先阀进油钢管    Priority valve into the steel pipe
QLWZG077-001412         直角可调接头        Right angle adjustable jonit
9D680-54A010000B0     优先阀    Pilot valve
ISO3601-37.69X3.53-90 O形圈     O-ring 008617753913626 XCMG
GBT16674.1-M10X90-8.8-A3L       六角法兰面螺栓    Hex bolt with flange
9D860-54A040000A0     支架焊合        Bracket welding
GBT16674.1-M12X25-8.8-A3L       六角法兰面螺栓    Hex bolt with flange
QLWZG074-003033         直通接头        Straight joint
008617753913626 XCMG woooyeah1@163.com
QLWZG078-003030         直角组合接头        Rectangular compound joint
9D860-54A100000A0     管夹总成        Clip assembly
9D860-54A010000A0     转向油缸        Steering cylinder
QLWZG078-002222         直角组合接头        Rectangular compound joint
QLWZG082-002218         三通可调向接头    Tee adjustable joint
QLWZG077-002218         直角可调接头        Right angle adjustable jonit
QLWZG079-102222         三通组合接头        T-union joint
QLWZG057.3-0080650   24°锥软管总成    24°taper hose assembly
008617753913626 XCMG woooyeah1@163.com
9D860-54A080000A0     缸间软管        Cylinder hoses
9D860-54A070000A0     转向过铰接软管1         Turned to hinged hose 1
9D860-54A090000A0     转向过铰接软管2         Turned to hinged hose 1
9D550-54C010000B0     三通可调向接头    Tee adjustable joint
9F850-59A190000A0      测压接头M14X1.5ED    Pressure measuring joint M14X1.5ED
