Description

外摩擦片 ZL20-032104 860114636 Clutch Disc(Outer)
内磨擦片 ZL20-030103 860114635 Clutch Disc(Inner)
轴用弹性挡圈60 GB894.2-86 300F-020805 Snap Ring
弹簧座 ZL20-032110 860114648 Spring Seat
弹簧 ZL20-032108 860114649 Spring
活塞 ZL20-032016 860114708 Piston
封油圈 ZL20-032107 860114640 Seal Ring
离合器壳体总成 ZL20-032105 860114690 Clutch Housing
离合器壳体总成 ZL20-032105 300F-020806 Clutch Housing
齿轮 m=4.5,Z=44 ZL20-036004×1 860114683 Gear
轴端挡板 ZL20-032002 860113201 Plate
烽塞环φ52 CA10-350914-A 860114637 Piston Ring
内封油套 ZL20-032003 860114642 Piston
圆锥滚子轴承7507 GB297-84 860110987 Cone Roller Bearing
齿轮m=5, Z=24 ZL20-033001×1 860114629 Gear
中间轴 ZL20-033002 860114665 Middle Shaft
孔用弹性挡圈75 GB893-86 300F-020903 Snap Ring
向心球轴承109 ZL276-89 300F-020904 Ball Bearing
齿轮m=4.5, Z=41 ZL20-032004×1 860114684 Gear
挡圈 ZL20-032101 860114646 Snap Ring
外端盖 ZL20-032102 860114647 Cover
外摩擦片 ZL20-032104 860114636 Clutch Disc(Outer)
内磨擦片 ZL20-030103 860114635 Clutch Disc(Inner)
轴用弹性挡圈60 GB894.2-86 300F-020905 Snap Ring
008617753913626 XCMG woooyeah1@163.com
弹簧座 ZL20-032110 860114648 Spring Seat
弹簧 ZL20-032108 860114649 Spring
活塞 ZL20-032016 860114708 Piston
封油圈 ZL20-032107 860114640 Seal Ring
O形密封圈6.0×3.1 GB1235-76 300F-020906 O- Ring
离合器壳体总成 ZL20-032105 860114690 Clutch Housing
齿轮 m=4.5,Z=54 ZL20-033005×1 860114672 Gear
压板 ZL20-030078 860114676 Plate
O形密封圈52×5.7 Q26-01 300F-021002 O-Ring
输出轴法兰 ZL20-030013 860114650 Flange
防尘罩 ZL20-030030 300F-021003 Dust Proof Cover
油封65×90×12 HG4-692-67 860110602 Oil Seal
输出轴后端盖 ZL20-030071 860114707 End Cover
六角螺栓M10×30 GB5783-86 300F-021004 Bolt
垫圈10 GB93-87 300F-021005 Washer
球轴承310 GB276-89 300F-021006 Ball Bearing
止推环 ZL20-030010A 860114651 Stop Ring
滑动轴承 SF-1 5530 860114727 Slide Bearing
隔套 300F-021007 300F-021007 Spacing Sleeve
齿轮z=36 ZL20-030009×1 860114621 Gear
高低档滑动齿套 ZL20-030019 860114624 Gear Bushing
输出轴 ZL20-030072A 860114620 Output Shaft
齿轮(输出轴低速档)(Z=56) ZL20-030021×1 860114673 Gear
隔套 300F-021009 300F-021009 Spacing Sleeve
手制动鼓 860114713 860114713 Parking Brake Drum
手制动磨擦片 ZL20-038104 860114726 Friction Plate
钢带 ZL20-038103 300F-021118 Steel Band
ZL20-039000X2 CONTROL VALVE
高低换挡拨叉 ZL20-030048 860114724 Yoke
纸垫 ZL20-030045 300F-021302 Paper Cushion
拨叉支架 ZL20-030047 860114723 Yoke Support
油封18×35×10 HG4-692-67 860110586 Oil Seal
拨叉轴 ZL20-030046 860108434 Yoke Shaft
手柄 ZL40.7.1-16 300F-021401 Knob
操纵杆 Z3.7.6A 300F-021403 Control Lever
固定座 ZL40.10.7-4A 300F-021406 Fixing Seat
隔套 ZL40.10.7-3A 300F-021408 Spacer
衬套 ZL40.10.7-1A 300F-021409 Lining Bushing
轴 Z3.7-5 300F-021410 Shaft
油杯45°M10×1 JB/T7940.2-1995 300F-021411 Grease Cup
008617753913626 XCMG woooyeah1@163.com
叉接头M12 Z3.7.5-2 300F-021413 Joint
销轴B12×40 GB882-86 300F-021414 Pin Shaft
销3.2×30 GB91-86 300F-021415 Cotter Pin
联接杆 Z3.7.5-1 300F-021417 Link Rod
支承板 Z3.7-3 300F-021419 Supporting Plate
垫板 Z3.7-2 300F-021420 Plate
支架 Z3.7-7 300F-021425 Bracket
下部机构 Z3.7.4 300F-021428 Lower Mechanism
销轴B10×60 GB882-86 300F-021430 Pin Shaft
轴 Z3.7-4 300F-021431 Shaft
前驱动桥 800302227 Front Axle
后驱动桥 800302228 Rear Axle
后传动轴 250100412 101269 Rear Transmission Shaft
前传动轴 250100114 101269 Front Transmission Shaft
主传动轴 250100113 101269 Main Driving Shaft
轮辋 800302221 Rim
17.5-25轮胎 800302219 GB2980-2001 Tire
测压接头 803268282 EMA3/M12×1.25EB Joint
轮边减速器总成 ZL30C.1 300F-030301 Wheel-end reduction
制动器总成 4010 300F-030302 Brake assembly
前桥壳总成 82020100 300F-030303 Front housing assembly
后桥壳总成 82021100 300F-030304 Rear housing assembly
前桥主减速器总成 75205088A 300F-030305 Front Carrier assembly
后桥主减速器总成 75205088B 300F-030306 Rear Carrier assembly
半轴 80020001AD 300F-030322 Axle shaft
主动螺旋锥齿轮 ZL40B.2.1-4A/ZL40B.2.1-4B 300F-030401/02 active spiral bevel gear
被动螺旋锥齿轮 ZL40B.2.1-15A/ZL40B.2.1-15B 300F-030403/04 passive spiral bevel gear
轴承NUP2306E GB/T283-94 300F-030407 Bearing
轴承32215 GB/T297-94 300F-030408 Bearing
调整螺母 ZL40.2.1-13 300F-030410 Adjust Nut
008617753913626 XCMG woooyeah1@163.com
油封FB70X95X12B GB/T9877.1-88 300F-030411 Oil seal
油封B 60×80×8 300F-030412 300F-030412 Oil seal
锁紧螺母 ZL40.2.1-1 300F-030417 Lock nut
连接法兰 82060404 300F-030418 Flange
防尘罩 ZL40.2.1.1-2 300F-030419 Cover
盖 ZL40.2.1-3 300F-030420 Cover
轴承座 ZL40.2.1-6 300F-030421 Bearing Seat
主减速器壳体 83020403A 300F-030422 Carrier
轴承31311 GB/T297-94 300F-030423 Bearing
锁紧片 ZL40.2.1-18A 300F-030426 Lock plate
轴承31311 GB/T297-94 300F-030427 Bearing
盖 75200033 300F-030429 Cover
差速器总成 ZL40.2.1 300F-030431 Differential
半轴齿轮垫 ZL40.2.1-16 300F-030502 Thrust washer
半轴齿轮 ZL40.2.1-15A 300F-030503 Side gear
十字轴 ZL40.2.1-20 300F-030504 Spider
行星齿轮垫片 ZL40.2.1-11 300F-030507 Pinion washer
行星锥齿轮 ZL40.2.1-12 300F-030508 Thrust gear
行星轮轴 79001545BD 300F-030602 Planetary pin
行星轮 79001547AD 300F-030603 Planet gear
太阳轮 79001524AD 300F-030604 Sun gear
止动垫圈85 GB/T858-88 300F-030605 Washer
行星轮垫片 75600456B 300F-030606 Thrust washer
螺母M85X2 75501646 300F-030607 Nut
锥套 76101041 300F-030608 Sleeve
滚针6X49.8 75600330D 300F-030609 Roll
油封座 79500813A 300F-030610 Oil Seal cage
挡油板 79500823 300F-030611 Ring
油封FB150X180X15D GB/T9877.1 300F-030612 Oil
油封FB150X180X15D GB/T9877.1 300F-030613 Oil
轮毂 83020502 300F-030614 Hub
轴承32024 GB/T297-94 300F-030615 Bearing
轴承32026 GB/T297-94 300F-030616 Bearing
内齿轮 77500938BD 300F-030621 Ring gear
行星轮架 83020501A 300F-030626 PLANETARY ASSY WITH GEAR
008617753913626 XCMG woooyeah1@163.com
端盖 79001544C 300F-030628 Cover
隔套 77000021 300F-030629 Sleeve
限位块 73520042 300F-030630 Block
制动盘 72006561 300F-030701 Brake disc
放气嘴保护罩 5010-17 300F-030702 Protect
销轴 770695 300F-030703 Pin shaft
放气嘴 4010-6A 300F-030704 Nozzle
O形密封圈75×3.1 GB/T3452.1-92 300F-030705 O-ring
夹钳体 770664 300F-030706 Clamp
圆柱销 GB/T73-85 300F-030716 Column pin
孔塞 5010-16 300F-030718 Plug
摩擦片 4010.1 300F-030719 Friction slice
摩擦垫块底板 300F-030720 300F-030720 Soleplate
矩形密封圈 1136179 300F-030721 Seal
活塞 770784 300F-030722 Piston
防尘圈 770723 300F-030723 Dustproof ring
进油分泵盖 770907 300F-030724 Cover
封油分泵盖 770876 300F-030725 Cover
动臂缸销 251700192 300F.05.3 Lift Cylinder Pin
黄油嘴M10X1 801100336 JB/T7940.1-1995 Grease Nipple
转斗缸后销轴 251702733 Tilt Cylinder Pin Shaft
前罩板 251702690 Front Cover Plate
动臂销 251702683 Lift Arm Pin
弹性挡簧 251500108 ELASTIC SPRING
连杆 251500111 85Z.7-12 Lock Link
销轴 B32×70 805601624 GB882-86 PIN
前转向销 251702735 Front Steering Pin
接头体 A6F 803163961 GB/T5631.2-1985 CONNECTOR A6F
前转向销 251702703 Front Steering Pin
后转向销 250500145 Rear Steering Pin
钢套 250100127 Z3.8-7 Steel Sleeve
下法兰 250100182 Z3.8-11 Lower Flange
关节轴承GE60ES-C3 800511348 GB304.5-81 Knuckle Bearing
008617753913626 XCMG woooyeah1@163.com
O形圈 801100113 GB1235-76 O-Ring
上法兰 250100181 Z3.8-10 Upper Flange
铰接销 250100215 Z3.8.6 Articulating Pin
注油管 250100870 Z3.8.10A Oil Injecting Pipe
副车架销 250100212 AUXILIARY CHASSIS PIN
铜垫 250200178 WASHER
套 250100180 BUSHING
副车架 250900177 LW330F.8.7 Auxiliary Chassis
配重 251702739 Counter Weight
牵引销 250600201 HITCH PIN
橡胶护套 252903961 Rubber Sleeve
左挡泥板 250500142 Left Fender
右挡板 251703051 right cover
档板 251700293 cover
