Description

29090010221 车轮总成（无内胎） Wheel
29090010011 摆动型驱动桥总成 Rear axle assembly
4011000954 螺栓GB5785-M24*2*190EpZn-10.9 SCREW
4013000184 螺母GB889.2-M24*2EpZn-10 LOCK NUT GB889.2-M24*2EpZn-10
4110001694 轮辋LGW22.00/3.0-25 Wheel trim
4110001696 轮胎26.5-25-20PRTL-L3 TIRE
4190000338 气门嘴GB3900-Z4-02-1 AIR INLET HATCH GB3900-Z4-02-1
29070009082 O形圈 O-RING 008617753913626 XCMG woooyeah1@163.com
29090010231 A503后驱动桥总成 Rear axle
4011000244 螺栓GB5786-M16*1.5*50EpZn-8.8 BOLT GB5786-M16*1.5*50EpZn-8.8
29070009511 垫圈 WASHER 008617753913626 XCMG woooyeah1@163.com
29090008541 套 SLEEVE
29090008552 衬套 SLEEVE
29090008921 前摆动支架 BRACKET
29090008931 后摆动支架 BRACKET
29090008941 支承轴 SUPPORT SHAFT
4011000090 螺栓GB5783-M12*35EpZn-8.8 BOLT GB5783-M12*35EpZn-8.8
29070010131 垫圈 WASHER 008617753913626 XCMG woooyeah1@163.com
29090008951 密封盖 SEALING COVER
4030000286 O形圈GB3452.1-180*5.30G O-RING GB3452.1-180*5.3G
29090008961 端盖 END PLATE 008617753913626 XCMG woooyeah1@163.com
4011000583 螺栓GB5785-M20*1.5*100EpZn-10.9 SCREW GB5785-M20*1.5*100EpZn-10.9
29070011121 垫圈 WASHER
29090008971 垫块 BLOCK
29090008981 衬垫 SHIM
4011000091 螺栓GB5783-M12*40EpZn-8.8 BOLT GB5783-M12*40EpZn-8.8
29090009001 垫片 SHIM 008617753913626 XCMG woooyeah1@163.com
29090008992 套 SLEEVE
29090010271 轮边减速器总成 Hub reduction
29070015921 轮辋螺母M22 NUT
29090009021 左半轴 SHAFT HALF
4030000359 O形圈GB3452.1-21.2*1.80G O-RING GB3452.1－21.2*1.80G
29070008061 透气塞 BREATHER CAP A503.1.2.1－5
4110000818 透气嘴 NOZZLE
29090009031 后桥壳 REAR AXLE CASING
008617753913626 XCMG woooyeah1@163.com
4011000701 螺栓GB5786-M14*1.5*45EpZn-10.9 BOLT GB5786-M14*1.5*45EpZn-10.9
29090007961 垫圈 WASHER 008617753913626 XCMG woooyeah1@163.com
4016000124 销GB119.2-10u8*30 PIN GB119.2-10u8*30
29090009041 后主传动总成 FINAL DRIVE
29090009051 右半轴 SHAFT HALF
29070011661 磁性螺塞 PLUG
4041000765 O形圈LGB168-12931 O-RING
4120004308 制动钳 Brake caliper
29090010241 A503后桥标牌 Name plate
4019000012 铆钉GB827-3*5-BL2 RIVET GB827-3*5-BL2
4011000608 螺栓GB5782-M20*60EpZn-10.9 SCREW GB5782-M20*60EpZn-10.9
29070011121 垫圈 WASHER 008617753913626 XCMG woooyeah1@163.com
29090009071 轮毂 WHEEL HUB
29070011203 齿圈支架 Gear ring holder
29070011212 挡圈 Retaining ring
29070011221 内齿圈 GEAR RING
29070011231 行星齿轮 PLANET GEAR
29070011751 磁性螺塞 PLUG 008617753913626 XCMG woooyeah1@163.com
4030000076 O形圈GB3452.1-13.2*1.80G O-RING GB3452.1-13.2*1.80G
29070011241 行星轮架 PLANET CARRIER
29070011251 太阳轮 SUN GEAR
29070011661 磁性螺塞 PLUG
4041000765 O形圈LGB168-12931 O-RING
29070011701 调整垫片 SHIM
29070011711 调整垫片 SHIM
29070012441 太阳轮垫片 SHIM
29070011261 连接套 ENGAGING SLEEVE
29070011271 垫片 SHIM
29070011281 行星齿轮轴 PLANET GEAR SHAFT
29070011291 挡环 RETAINING RING
29070011301 滚柱 ROLLER
29070011311 挡环 RETAINING RING 008617753913626 XCMG woooyeah1@163.com
4011000214 螺栓GB5786-M14*1.5*40EpZn-10.9 BOLT GB5786-M14*1.5*40EpZn-10.9
29070011141 O形圈 O-RING
29070011321 挡板 BAFFLE
4011000081 螺栓GB5783-M10*20EpZn-8.8 BOLT GB5783-M10*20EpZn-8.8
29070012932 锁紧片 Lock washer
4014000033 螺钉GB70.1-M8*16EpZn-8.8 SCREW GB70.1-M8*16EpZn-8.8
29070011332 圆螺母 ROUND NUT 008617753913626 XCMG woooyeah1@163.com
4014000206 螺钉GB70.1-M10*16EpZn-8.8 SCREW
29070011171 轮辋螺栓 SCREW
29070013471 轴承 ROLLER BEARING
4011000244 螺栓GB5786-M16*1.5*50EpZn-8.8 BOLT GB5786-M16*1.5*50EpZn-8.8
29070009511 垫圈 WASHER
29070011341 螺柱 STUD
29070015721 制动盘 BRAKE DISC
29070011831 轴承 ROLLER BEARING
008617753913626 XCMG woooyeah1@163.com
4030000591 密封圈 GB9877.1-FB170*210*15D SEALING RING
29090009061 轮边支承轴 SUPPORT SHAFT
29070015731 制动钳支架 BRACKET
29070011371 防尘罩 DUST COVER
29070013511 双头螺柱 STUD
29070011121 垫圈 WASHER
4013000204 螺母GB6176-M20*1.5-10 NUT
