Description

I2000-2920020237.1 转向器总成 Steering gear system
29200012161 转向柱部装总成 Steering column
29200013321 转向器部装 Steering system
4041001047 组合接头LGB143-01406 NIPPLE
008617753913626 XCMG woooyeah1@163.com
4011001296 螺栓GB16674.1-M8*20flZnyc-8.8-480 SCREW
29211000451 支架 Plate
4011001470 螺栓GB16674.1-M8*70flZnyc-8.8-480 Bolt
008617753913626 XCMG woooyeah1@163.com
29211000481 橡胶管夹 Clamp
29211000471 板 Plate
29200013301 转向器回油管 Hose assembly
29141006551 转向器进油胶管 Hose assembly
29200013311 转向器反馈油管 Hose assembly
4041003526 软管LGB125-003028 Hose assembly
008617753913626 XCMG woooyeah1@163.com
29200013241 板 Plate
4011001299 螺栓GB16674.1-M10*25flZnyc-8.8-480 SCREW
29200013261 板 Plate
29200013271 板 Plate
29200013281 橡胶管夹 Clamp
29200014421 优先阀部装 Priority valve
008617753913626 XCMG woooyeah1@163.com
4015000433 垫圈GB97.1-10flZnyc-300HV-480 WASHER
4011001463 螺栓GB16674.1-M10*75flZnyc-8.8-480 Bolt
4013000370 螺母GB6170-M10flZnyc-8-480 NUT
I2010-2920001216.S 转向柱部装总成 Steering column
4120004343 可调转向柱-02 STEERING COLUMN
4120003680 方向盘FXP-953 STEERING WHEEL
4013000007 螺母GB6170-M10EpZn-8 NUT
29200012091 固定支架 Bracket
29200009081 橡胶套 RUBBER SLEEVE
29200009091 管夹 CLAMP
008617753913626 XCMG woooyeah1@163.com
4011000164 螺栓GB16674-M10*35EpZn-8.8 BOLT
4011000282 螺栓GB16674-M10*75EpZn-8.8 SCREW
29200009311 钢管 PIPE
4011000309 螺栓GB16674-M10*50EpZn-8.8 BOLT
29200009321 钢管 PIPE
29200009361 橡胶块 RUBBER MAT
29200009561 盖板 COVER PLATE
008617753913626 XCMG woooyeah1@163.com
4011000447 螺栓GB16674-M10*20EpZn-8.8 BOLT
4013000028 螺母GB6170-M6EpZn-8 NUT
4015000207 垫圈GB97.1-6EpZn-300HV WASHER
29200009431 管夹 CLAMP
4011000194 螺钉GB818-M6*12EpZn-4.8 SCREW
29200009421 管夹 CLAMP
008617753913626 XCMG woooyeah1@163.com
4014000048 螺钉GB818-M5*12EpZn-4.8 SCREW
4130000896 锁紧手柄JB/T270.12-94 HANDLE
I2011-4120004343 可调向转向柱02 Steering column
4120004343001 可调向转向柱LG-ZXZ02G Steering shaft
4130000896 锁紧手柄JB/T270.12-94 HANDLE
008617753913626 XCMG woooyeah1@163.com
4120008528002 螺母M16 GB/T61721-2000 Nut
4120004343002 转向器连接轴LG-ZXZ02G-1 Steering shaft
4120008528004 尼龙套一LG-ZXZ02G-7 Nylon sleeve
4120004343003 固定支架 LG-ZXZ02G.2 Attachment bracket
4120008528006 方向盘连接轴LG-ZXZ02G-3 Shaft
4120004343004 移动支架LG-ZXZ02G.4 Bracket
4120008528008 尼龙套二LG-ZXZ02G-10 Nylon sleeve
008617753913626 XCMG woooyeah1@163.com
4190000831012 导电环KCT1.2-11 Ring
4120008528009 垫圈LG-ZXZ02-7 Washer
4120008528010 转动套LG-ZXZ02-8 Sleeve
4120008528011 挡圈LG-ZXZ02-9 Retaining ring
4120008528012 固定座LG-ZXZ02.10 Seat
4120001703101 万向节 WXJ-03 Cross axle
4190000831010 堵头KCT1.2-12 Plug
4120008528013 锁紧轴LG-ZXZ02-11 Pin
4120008528014 锁紧套LG-ZXZ02-12 Sleeve
4120004343005 销轴GB882B 8*36 Control shaft
4120004343006 开口销GB91-86 3.2*15 Split pin
4120004343007 锁定螺钉GB72-88 M4*5 Set screw
008617753913626 XCMG woooyeah1@163.com
4120001703068 深沟球轴承61805-27GB/T276-1994 Bearing
4120001703073 A型轴用弹性挡圈25GB/T894.1-1986 Spring washer
4120004343008 轴用弹性挡圈37 Stop washer
4120000904213 弹垫Φ18GB93-87 Washerφ18gb93-87
4120004343011 六角头螺栓M6*16 Hexagon screw
4120004343009 十字盘头螺钉GB/T818-2000 M5*8 Screw
4120004343010 I形六角螺母GB/T6170-2000 M12 Hexagon nut
I2000-2920001332.S 转向器部装 Steering system
008617753913626 XCMG woooyeah1@163.com
4120007029 转向器Xcel80-1000 DIVERTER VALVE
4041000783 O形圈LGB168-11724 O-RING
4041000564 直接头LGB120-02620 NIPPLE
4041000131 直接头LGB120-01412 NIPPLE
4041000784 O形圈LGB168-10924 O-RING
I2010-2920001442.S 优先阀部装 Priority valve
4041000088 直接头LGB155-23326 NIPPLE
4030000276 O形圈GB3452.1-32.5*2.65G O-RING
008617753913626 XCMG woooyeah1@163.com
4120005054 优先阀VLH-240S-16 PRIORITY VALVE
4030000285 O形圈GB3452.1-12.5*2.65G O-RING
4041000084 直接头LGB155-01214 NIPPLE
4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 SCREW
4011001561 螺栓GB5782-M12*135flZnyc-8.8-480 Screw
4013000368 螺母GB6170-M12flZnyc-8-480 NUT
4041002451 组合接头LGB143-11406 Nipple
008617753913626 XCMG woooyeah1@163.com
29200013251 板 Plate
11220538 减震垫 DAMPER MAT
29200013011 钢套 Thimble
29330059111 垫圈12 WASHER
29200013071 支撑螺钉 Support screw
