Description

F1310-4120015490 动臂油缸（3713CH） Lifting cylinder
4120005999001 缸筒总成24A139210 Cylinder tube
4120009098001 活塞杆总成24A116910 Piston rod
4120005999003 缸盖24C101150 Cover
4120005980010 衬套24S290501 BUSHING
008617753913626 XCMG woooyeah1@163.com
4120005980008 钢丝挡圈-孔用24C090220 RETAINING RING
4120005999004 密封件-缓冲24H009004 Sealing ring
4120005999005 密封件-活塞杆24F209003 Sealing ring
4120008479002 挡圈-U形圈24E00902C Retaining ring
4120004336016 密封件-防尘24D209002 Sealing ring
4120005980009 钢丝挡圈-孔用24C090240 RETAINING RING
4120005999008 O形圈24K11600A O-ring
4120009098002 挡圈-O形圈24M11700C O-ring
4120005999010 O形圈24K316701 O-ring
4120015490001 活塞24A181550 Piston
008617753913626 XCMG woooyeah1@163.com
4120008911005 密封件-活塞24P317003 Sealing ring
4120005999013 O形圈24K10900A O-ring
4120008479003 挡圈-O形圈24M10950C O-ring
4120015490002 支承环24G217025 Sealing ring
4120005980011 活塞背母24C103050 NUT
4120009418007 钢球402200003 Ball
4120009418008 螺钉-内六角凹端紧定401700157 Screw
4120007579004 轴套24C051050 Sleeve
008617753913626 XCMG woooyeah1@163.com
4120005999017 销边防尘24R308030 Sealing ring
4120009470008 螺钉-内六角圆柱头401700173 Screw
4120005685012 固定座24C003020 M16 ANCHORAGE
4120015490003 密封件维修包24A106510S Sealing kit
F1400-2914002555.S 转斗缸总成 Tilt cylinder system
4120009245 转斗油缸HSGF-200*105*550-1064 Tilt cylinder
4011001248 螺栓GB5783-M10*25flZnyc-8.8-480 SCREW
4015000426 垫圈GB96.1-10flZnyc-300HV-480 WASHER
29140025441 放平护板 Indicator plate
29140025541 接近开关支架部装 Bracket
008617753913626 XCMG woooyeah1@163.com
29140018961 转斗缸小腔胶管 HOSE ASSEMBLY
4041000144 分体法兰LGB117-312552 FLANGE HALF
4011001510 螺栓GB16674.1-M12*35flZnyc-8.8-480 SCREW
4030000029 O形圈GB3452.1-37.5*3.55G O-RING
29140012931 U形螺栓 U-BOLT
4041001018 底板LGB160-3040 BRACKET
4013000370 螺母GB6170-M10flZnyc-8-480 NUT
008617753913626 XCMG woooyeah1@163.com
29140019001 转斗联小腔钢管 PIPE
29140020911 转斗缸大腔胶管 Hose assembly
29140016451 动臂指示板 INDICATOR PLATE
4011001246 螺栓GB5783-M8*16flZnyc-8.8-480 SCREW
4015000425 垫圈GB96.1-8flZnyc-300HV-480 WASHER
29140019031 转斗联大腔钢管 PIPE
29140020901 转斗缸大腔钢管 Pipe
008617753913626 XCMG woooyeah1@163.com
4011001529 螺栓GB16674.1-M12*55flZnyc-8.8-480 Screw
4011001530 螺栓GB16674.1-M12*60flZnyc-8.8-480 Screw
4041000774 螺塞LGB135-01422 PLUG
4041000767 O形圈LGB168-11124 O-RING
4041000026 分体法兰LGB117-310491 FLANGE HALF
4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 SCREW
4030000026 O形圈GB3452.1-32.5*3.55G O-RING
4041000818 防尘盖LGB134-01049 COVER
008617753913626 XCMG woooyeah1@163.com
4015000433 垫圈GB97.1-10flZnyc-300HV-480 WASHER
4011001354 螺栓GB5782-M10*90flZnyc-8.8-480 SCREW
4011001243 螺栓GB5783-M12*35flZnyc-8.8-480 SCREW
4015000428 垫圈GB97.1-12flZnyc-300HV-480 WASHER
F1410-4120009245 转斗油缸(3713CH) Tilt cylinder
4120006001001 缸筒总成24A139180 Cylinder tube
4120006001002 活塞杆总成24A114190 Piston rod
4120009245001 缸盖24C104200 Cover
4120006001004 衬套24S2A5601 Bushing
008617753913626 XCMG woooyeah1@163.com
4120006001005 钢丝挡圈-孔用24C090250 Retaining ring
4120006001006 密封件-缓冲24H010504 Sealing ring
4120006001007 密封件-活塞杆24F210503 Sealing ring
4120009245002 挡圈-U形圈24E01052C Retaining ring
4120006001009 密封件-防尘24D210502 Sealing ring
4120006560009 钢丝挡圈-孔用24C090280 Retaining ring
008617753913626 XCMG woooyeah1@163.com
4120006001010 O形圈24K11900A O-ring
4120008912009 挡圈-O形圈24M12000C O-ring
4120006996003 O形圈 24K319511 O-ring
4120006001013 活塞24C102140 Piston
4120006001014 密封件-活塞24P220002 Sealing ring
4120006001015 O形圈 24K11050A O-ring
4120009245003 挡圈-O形圈24M11100C O-ring
4120008912007 支承环24G220001 Sealing ring
4120006001018 活塞背母24C103080 Nut
4120006560007 螺钉-内六角凹端紧定24T910161 SCREW
008617753913626 XCMG woooyeah1@163.com
4120006560006 钢球24U006501 BALL
4120006001019 轴套24C116140 Bushing
4120006001020 销边防尘24R308030 Sealing ring
4120007383004 螺钉-内六角圆柱头24TN22805 Screw
4120009245004 密封件包24A105340S Sealing kit
