Description

F1100-2911001418.S1A 工作泵总成 Working hydraulic pump assembly
29110012601 工作泵吸油胶管 Hose
4017000013 喉箍JB8870-d90 CLAMP
29110012152 工作泵吸油钢管 Pipe
008617753913626 XCMG woooyeah1@163.com
4030000482 O形圈GB3452.1-50.0*3.55G O-RING
4011001530 螺栓GB16674.1-M12*60flZnyc-8.8-480 Screw
4120008204 齿轮泵HPT3-63/HPT2-50 Gear pump
4030000633 O形圈GB3452.1-128*3.55G O-RING
4012000082 螺柱GB898-M12*35flZnyc-8.8-480 STUD
4015000428 垫圈GB97.1-12flZnyc-300HV-480 WASHER
4013000368 螺母GB6170-M12flZnyc-8-480 NUT
008617753913626 XCMG woooyeah1@163.com
29110014281 工作泵出油块 Block
4030000029 O形圈GB3452.1-37.5*3.55G O-RING
4011001633 螺栓GB16674.1-M10*85flZnyc-10.9-480 Screw
4041000043 分体法兰LGB117-310490 FLANGE HALF
4030000026 O形圈GB3452.1-32.5*3.55G O-RING
4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 SCREW
29110014191 工作泵出油胶管 Hose assembly
008617753913626 XCMG woooyeah1@163.com
4041000056 分体法兰LGB117-312550 FLANGE HALF
F1120-4120008204 齿轮泵HPT3-63/HPT2-50(120104) Working pump assembly
4120008204001 前盖163A0002 Cover
4120008204002 B类泵体163B0615 Pump body
4120008204003 主齿163F0024 Drive shaft
4120008204004 从齿163G0020 Shaft
4120008204005 接轴163H0010 Shaft
4120006922008 侧板163J0002 Side board
008617753913626 XCMG woooyeah1@163.com
4120005082210 孔用弹性挡圈565C-00016 Retaining ring
4120005082211 外置轴承W58-48 Beaing
4120001058204 油封W62-26-10 SEALING RING
4120006561005 滑动轴承002B0005 Plain bearing
4120005082214 堵油螺钉S-0280 Screw
4120005082215 圆柱销008A0006 Pin
4120005082216 O型密封圈001E0006 O-ring
4120006561006 E型密封圈006E0003 Sealing ring
4120006561007 E型挡圈007E0002 Retaining ring
008617753913626 XCMG woooyeah1@163.com
4120001084204 双头螺柱002A0012 Stud
4120005082220 螺母004A0004 Nut
4120008204006 螺栓001A0007 Screw
4120005082221 垫圈W033-2 Washer
4120006298230 O形密封圈2995C-00003 O-ring
4120008204007 垫圈565C-00035 Washer
4120008204008 螺钉W1C-00007-040 Screw
4120006298218 前盖162A0004 Cover
4120006298219 B类泵体162B0110 Pump body
4120006298220 二级主齿162F0043 Drive shaft
4120006298221 二级从齿162G0019 Shaft
4120007043006 侧板162J0001 Side board
008617753913626 XCMG woooyeah1@163.com
4120006298223 孔用弹性挡圈007A0006 Retaining ring
4120006298224 油封W62-26-18 Sealing ring
4120006298225 滑动轴承002B0001 Plain bearing
4120006298226 圆柱销008A0001 Pin
4120006298227 O形密封圈001E0009 O-ring
4120006298228 E形密封圈006E0002 Sealing ring
4120006298229 E形挡圈007E0001 Retaining ring
4120006298231 螺栓001A0008 Screw
008617753913626 XCMG woooyeah1@163.com
F1200-2912004721.S 液压操纵总成 Hydraulic control
29120047221 液压操纵主管路 Hydraulic control
29120047161 液压操纵先导管路 Hydraulic control
4041001554 软管LGB125-003070 HOSE ASSEMBLY
4041001047 组合接头LGB143-01406 NIPPLE
4041000026 分体法兰LGB117-310491 FLANGE HALF
4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 SCREW
4030000026 O形圈GB3452.1-32.5*3.55G O-RING
4041000818 防尘盖LGB134-01049 COVER
008617753913626 XCMG woooyeah1@163.com
F1210-2912004722.S 液压操纵主管路 Hydraulic control
29120043201 回油块部装总成 Block
4030000130 O形圈GB3452.1-47.5*3.55G O-RING
4041003531 软管LGB161-014080 Hose assembly
4030000029 O形圈GB3452.1-37.5*3.55G O-RING
4041000027 分体法兰LGB117-312551 FLANGE HALF
4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 SCREW
29120043251 合流胶管 Hose assembly
4030000026 O形圈GB3452.1-32.5*3.55G O-RING
29120043211 油路块部装总成 Block
008617753913626 XCMG woooyeah1@163.com
29120043271 多路阀回油胶管 Hose assembly
29120043261 多路阀进油胶管 Hose assembly
29120047241 固定支架部装总成 BRACKET
29120047231 多路阀KM300-III-19A部装总成 Hydraulic unit
4041003284 直接头LGB120-03642*135 Nipple
4041000878 O形圈LGB168-13831 O-RING
F1201-2912004320.S1A 回油块部装总成 Block
4011001510 螺栓GB16674.1-M12*35flZnyc-8.8-480 SCREW
4041000011 分体法兰LGB117-314650 FLANGE HALF
008617753913626 XCMG woooyeah1@163.com
29120037521 回油节流盘 Block
29120034601 回油块总成 Block
F1201-2912004321.S 油路块部装总成 Block
29120034901 油路块总成 Block
4011001248 螺栓GB5783-M10*25flZnyc-8.8-480 SCREW
4015000433 垫圈GB97.1-10flZnyc-300HV-480 WASHER
4041000011 分体法兰LGB117-314650 FLANGE HALF
4011001510 螺栓GB16674.1-M12*35flZnyc-8.8-480 SCREW
008617753913626 XCMG woooyeah1@163.com
4041000774 螺塞LGB135-01422 PLUG
4041000767 O形圈LGB168-11124 O-RING
4041000026 分体法兰LGB117-310491 FLANGE HALF
4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 SCREW
4041000056 分体法兰LGB117-312550 FLANGE HALF
F1211-2912004724.S 固定支架部装总成 BRACKET
29120025131 支架 BRACKET
008617753913626 XCMG woooyeah1@163.com
4011001248 螺栓GB5783-M10*25flZnyc-8.8-480 SCREW
4015000426 垫圈GB96.1-10flZnyc-300HV-480 WASHER
4011001354 螺栓GB5782-M10*90flZnyc-8.8-480 SCREW
4013000370 螺母GB6170-M10flZnyc-8-480 NUT
4041002626 管夹LGB172-A25*28 Hose clamp
29120019531 压板 PLATE
008617753913626 XCMG woooyeah1@163.com
F1210-2912004723.S 多路阀KM300-III-19A部装总成 Hydraulic unit
4120006637 多路阀KM300-III-19A Control valve
4041003467 直接头LGB120-01414*35 Nipple
4041000767 O形圈LGB168-11124 O-RING
008617753913626 XCMG woooyeah1@163.com
4190000204 三通接头ET08LOMDA3C THREE-WAY NIPPLE
4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 SCREW
4041000056 分体法兰LGB117-312550 FLANGE HALF
4041000774 螺塞LGB135-01422 PLUG
008617753913626 XCMG woooyeah1@163.com
4041000011 分体法兰LGB117-314650 FLANGE HALF
29120020701 多路阀进油钢管 PIPE
4030000029 O形圈GB3452.1-37.5*3.55G O-RING
