Description

4120004343 可调转向柱-02 STEERING COLUMN
4120003680 方向盘FXP-953 STEERING WHEEL
4013000007 螺母GB6170-M10EpZn-8 NUT
29200012091 固定支架 Bracket
29200009081 橡胶套 RUBBER SLEEVE
29200009091 管夹 CLAMP
4011000164 螺栓GB16674-M10*35EpZn-8.8 BOLT
4011000282 螺栓GB16674-M10*75EpZn-8.8 SCREW
008617753913626 SDLG woooyeah1@163.com
29200009311 钢管 PIPE
4011000309 螺栓GB16674-M10*50EpZn-8.8 BOLT
29200009321 钢管 PIPE
29200009361 橡胶块 RUBBER MAT
29200009561 盖板 COVER PLATE
4011000447 螺栓GB16674-M10*20EpZn-8.8 BOLT
4013000028 螺母GB6170-M6EpZn-8 NUT
4015000207 垫圈GB97.1-6EpZn-300HV WASHER
29200009431 管夹 CLAMP
4011000194 螺钉GB818-M6*12EpZn-4.8 SCREW
008617753913626 SDLG woooyeah1@163.com
29200009421 管夹 CLAMP
4014000048 螺钉GB818-M5*12EpZn-4.8 SCREW
4130000896 锁紧手柄JB/T270.12-94 HANDLE
4120004343001 可调向转向柱LG-ZXZ02G Steering shaft
4190000831012 导电环KCT1.2-11 Ring
4130000896 锁紧手柄JB/T270.12-94 HANDLE
4120008528002 螺母M16 GB/T61721-2000 Nut
4120004343002 转向器连接轴LG-ZXZ02G-1 Steering shaft
4120008528004 尼龙套一LG-ZXZ02G-7 Nylon sleeve
4120004343003 固定支架 LG-ZXZ02G.2 Attachment bracket
008617753913626 SDLG woooyeah1@163.com
4120008528006 方向盘连接轴LG-ZXZ02G-3 Shaft
4120004343004 移动支架LG-ZXZ02G.4 Bracket
4120008528008 尼龙套二LG-ZXZ02G-10 Nylon sleeve
4190000831012 导电环KCT1.2-11 Ring
4120008528009 垫圈LG-ZXZ02-7 Washer
4120008528010 转动套LG-ZXZ02-8 Sleeve
4120008528011 挡圈LG-ZXZ02-9 Retaining ring
4120008528012 固定座LG-ZXZ02.10 Seat
4120001703101 万向节 WXJ-03 Cross axle
4190000831010 堵头KCT1.2-12 Plug
4120008528013 锁紧轴LG-ZXZ02-11 Pin
4120008528014 锁紧套LG-ZXZ02-12 Sleeve
4120004343005 销轴GB882B 8*36 Control shaft
4120004343006 开口销GB91-86 3.2*15 Split pin
4120004343007 锁定螺钉GB72-88 M4*5 Set screw
008617753913626 SDLG woooyeah1@163.com
4120001703068 深沟球轴承61805-27GB/T276-1994 Bearing
4120001703073 A型轴用弹性挡圈25GB/T894.1-1986 Spring washer
4120004343008 轴用弹性挡圈37 Stop washer
4120000904213 弹垫Φ18GB93-87 Washerφ18gb93-87
4120004343011 六角头螺栓M6*16 Hexagon screw
4120004343009 十字盘头螺钉GB/T818-2000 M5*8 Screw
4120004343010 I形六角螺母GB/T6170-2000 M12 Hexagon nut
4120002730 优先阀VLH-240 PRIORITY VALVE
4011001561 螺栓GB5782-M12*135flZnyc-8.8-480 Screw
008617753913626 SDLG woooyeah1@163.com
4013000368 螺母GB6170-M12flZnyc-8-480 NUT
11220538 减震垫 DAMPER MAT
29200013011 钢套 Thimble
29330059111 垫圈12 WASHER
4011001375 螺栓GB16674.1-M12*30flZnyc-8.8-480 Bolt
29200013071 支撑螺钉 Support screw
29200013661 板 Plate
4120002993 接头GE20S11/16UNOMDCF NIPPLE
4120004090 变径接头RED20S/18LOMDCF NIPPLE
4120003023 接头GE08L7/16UNFOMD NIPPLE
008617753913626 SDLG woooyeah1@163.com
4120008888 左转向油缸HSGL-100*60*432-918 Steering cylinder
29210011631 左钢管 Pipe
4041003159 O形圈LGB168-11221 O-ring
4120009938 软管20411Y-22-08TZ×GH781-08×600 Hose assembly
4120009937 软管20411Y-22-08TZ×GH781-08×550 Hose assembly
29200012971 管夹 Clamp
4041000876 缓冲套LGB123-0322 RUBBER SLEEVE
4011001286 螺栓GB16674.1-M8*55flZnyc-8.8-480 SCREW
4015000430 垫圈GB97.1-8flZnyc-300HV-480 WASHER
4013000373 螺母GB6170-M8flZnyc-8-480 NUT
29210011601 板 Plate
4011001247 螺栓GB5783-M8*20flZnyc-8.8-480 SCREW
008617753913626 SDLG woooyeah1@163.com
4120009935 软管20411Y-26-10TZ×GH781-10×520 Hose assembly
4120009936 软管20411Y-26-10TZ×GH781-10×540 Hose assembly
29210011751 分流块部装 Connection block
29210011621 管夹 Clamp
4011001279 螺栓GB16674.1-M8*50flZnyc-8.8-480 SCREW
4120008889 右转向油缸HSGL-100*60*432-918 Steering cylinder
29210011661 右钢管 Pipe
29210011521 过渡钢管A Pipe
29210011541 过渡钢管B Pipe
29210011561 过渡钢管C Pipe
29210011581 过渡钢管D Pipe
4011001297 螺栓GB16674.1-M8*16flZnyc-8.8-480 SCREW
4015000425 垫圈GB96.1-8flZnyc-300HV-480 WASHER
4120008888001 缸筒总成-左24A143500 Cylinder tube
4120008889002 活塞杆总成24A116750 Piston rod
008617753913626 SDLG woooyeah1@163.com
4120008573003 缸盖24C105330 Cover
4120005494005 衬套24S260301 Bushing
4120008718004 钢丝挡圈-孔用24C090140 Retaining ring
4120006672005 密封件-缓冲24H006004 Sealing ring
4120006672006 密封件-活塞杆24F206003 Sealing ring
4120008718005 挡圈-U形圈24E00602C Retaining ring
4120006672008 密封件-防尘24D206002 Sealing ring
4120007051004 钢丝挡圈-孔用24C090170 Retaining ring
4120006742006 O形圈24K10950A O-ring
4120008468003 挡圈-O形圈24M11000C Retaining ring
4120006603013 O形圈24K310001 O-ring
4120008889003 活塞24C106280 Piston
4120006603016 密封件-活塞24P210002 Sealing ring kit
008617753913626 SDLG woooyeah1@163.com
4120006672013 O形圈24K10600A Sealing ring
4120008573006 挡圈-O形圈24M10650C Retaining ring
4120006742009 支承环24G210001 Support ring
4120006603018 钢球24U004001 BALL
4120006316010 螺钉-内六角凹端紧定24T906121 M6*12L SCREW
4120003878021 关节轴承24U105001 SPHERICAL PLAIN BEARING
4021000236
4120006441005 弹性挡圈-孔用-A型24T007501 RETAINING RING
4015000014
4120008889004 密封件包24A104970S Sealing ring kit
008617753913626 SDLG woooyeah1@163.com
29210011761 分流块 Block
4041000508 螺塞LGB135-01824 PLUG
4041000768 O形圈LGB168-11524 O-RING
4041000187 直接头LGB120-02622 NIPPLE
4041000771 O形圈LGB168-11924 O-RING
4041000143 直接头LGB120-02222 NIPPLE
4011001294 螺栓GB16674.1-M10*20flZnyc-8.8-480 SCREW
