Description

2821001164.S1a:前车架总成-46 Front frame
28210011651 左侧板焊合 Side plate
4011000220 螺栓GB5783-M20*55EpZn-8.8 BOLT GB5783-M20*55EpZn-8.8
4015000176 垫圈GB97.1-20EpZn-300HV WASHER
008617753913626 XCMG woooyeah1@163.com
28210011691 刮泥板 Bracket
28210011421 后横梁 balance beam
28210010331 固定杆 LOCK LEVER
008617753913626 XCMG woooyeah1@163.com
4011001051 螺栓GB5782-M24*80EpZn-10.9 SCREW
4015000167 垫圈GB97.1-24EpZn-300HV WASHER GB97.1-24EpZn-300HV
4013000170 螺母GB6170-M24EpZn-10 NUT GB6170-M24EpZn-10
28210011531 灌装前横梁 backing bar
28210011671 右侧板焊合 Side plate
008617753913626 XCMG woooyeah1@163.com
28210010281 销轴 PIN
28210010291 卡环 CLAMP
2821001169.S1a:刮泥板-47 Bracket
28210011701 支板 BRACKET
008617753913626 XCMG woooyeah1@163.com
4011000089 螺栓GB5783-M12*30EpZn-8.8 BOLT
4015000168 垫圈GB97.1-12EpZn-300HV WASHER
4011000091 螺栓GB5783-M12*40EpZn-8.8 BOLT GB5783-M12*40EpZn-8.8
28210011721 支板 Bracket 008617753913626 XCMG woooyeah1@163.com
28210011731 刮泥齿 Bracket
2822000399.S1d:铰接架总成-48 Hinged support assembly
4190003105 回转支承400 SWING RING TELL:008617753913626 XCMG
4011000231 螺栓GB5782-M16*70EpZn-8.8 SCREW GB5782-M16*70EpZn-8.8
4015000181 垫圈GB97.1-16EpZn-300HV WASHER GB97.1-16EpZn-300HV
28220004001 铰接架 PIVOT ANCHORAGE
4011000095 螺栓GB5783-M16*35EpZn-8.8 SCREW GB5783-M16*35EpZn-8.8
4011000877 螺栓GB5783-M16*80EpZn-8.8 SCREW
4016000339 销GB91-8*63EpZn-Q235A SPLIT PIN
4021000248 关节轴承GB9163-GE35ES SPHERICAL PLAIN BEARING
28220003431 转向销 PIN
4030000065 油杯JB7940.1-M10*1 LUBRICATING NIPPLE
28220004801 调整垫 Shim
28220004591 销轴 Pin 008617753913626 XCMG woooyeah1@163.com
4021000043 关节轴承GB9163-GE70ES-2RS SPHERICAL PLAIN BEARING GB9163-GE70ES-2RS
29250000301 垫片 SHIM
29250000291 通油螺栓 BOLT
28220003971 油管焊合 LUBRICATING PIPE
29250000311 管夹 CLAMP
4014000024 螺钉GB818-M6*10EpZn-4.8 SCREW
4015000207 垫圈GB97.1-6EpZn-300HV WASHER
28220004811 调整垫 Shim
28220004821 调整垫 Shim
008617753913626 XCMG woooyeah1@163.com
4190003105:回转支承400(340501)-50 Slew ring(340501)
4030000065 油杯JB7940.1-M10*1 LUBRICATING NIPPLE
4190003105001 回转支承外圈 Slew ring
4190002923004 钢球19.844G40 Ball
4190002923005 隔离块QG20 Block
4190002923006 调整块QT20 Block
4190003105002 回转支承内圈 Slew ring
008617753913626 XCMG woooyeah1@163.com
4190002923003 密封条MT12 PROTECTING MOULDING
4190002923007 堵塞 Plug
4090000140 销GB117-10*45 PIN
4190003105:回转支承400(3713GS)-51 Slew ring(3713GS)
4030000065 油杯JB7940.1-M10*1 LUBRICATING NIPPLE
008617753913626 XCMG woooyeah1@163.com
4190003105010 回转支承外圈 Slew ring
4190003105013 钢球φ19.05 Ball
4190003105014 隔离块HG19.05 Block
4190003105011 回转支承内圈 Slew ring
4190003105012 密封圈4mm Sealing ring
4190003105016 堵φ22 Plug
4190003105015 圆锥销φ8 Pin
2823001428.S1h:后车架总成-52 Rear frame
28230018012 后车架 Rear frame
008617753913626 XCMG woooyeah1@163.com
4040000008 垫圈LGB001-10 WASHER LGB001-10
4011000081 螺栓GB5783-M10*20EpZn-8.8 BOLT GB5783-M10*20EpZn-8.8
4015000162 垫圈GB97.1-10EpZn-300HV WASHER
4011000080 螺栓GB5783-M10*16EpZn-8.8 BOLT
28230002741 垫板 PLATE
4011000472 螺栓GB5783-M20*60EpZn-8.8 BOLT
4015000168 垫圈GB97.1-12EpZn-300HV WASHER
4011000197 螺栓GB5783-M12*25EpZn-8.8 BOLT GB5783-M12*25EpZn-8.8
29280010241 扶手 HANDLE 008617753913626 XCMG woooyeah1@163.com
28230015361 右配重 Counterweight
28290007411 梯子 Foot step
4011000106 螺栓GB5783-M8*25EpZn-8.8 BOLT GB5783-M8*25EpZn-8.8
4015000072 垫圈GB97.1-8EpZn-300HV WASHER GB97.1-8EpZn-300HV
008617753913626 XCMG woooyeah1@163.com
28230011272 蜂鸣器固定板 ANCHOR PLATE
28230015311 左配重 COUNTERWEIGHT
28230014331 护套 RUBBER SLEEVE
28230003731 调整垫 SHIM
28230017951 底封板焊合 COVER
008617753913626 XCMG woooyeah1@163.com
4014000024 螺钉GB818-M6*10EpZn-4.8 SCREW
4015000207 垫圈GB97.1-6EpZn-300HV WASHER
29250000311 管夹 CLAMP
4030000065 油杯JB7940.1-M10*1 LUBRICATING NIPPLE
4043000326 垫片LGB303-35*60*1 SHIM
4043000327 垫片LGB303-35*60*2 SHIM
28230014321 左油管焊合 LUBRICATING PIPE
4043000645 销轴LGB301-35g7*58*105/G-40Cr PIN
008617753913626 XCMG woooyeah1@163.com
29250000291 通油螺栓 BOLT
29250000301 垫片 SHIM
28230014311 右油管焊合 LUBRICATING PIPE
4011000417 螺栓GB5783-M20*35EpZn-8.8 BOLT
4015000176 垫圈GB97.1-20EpZn-300HV WASHER
