Description

4120006611:动臂油缸(3713CH)-39 Lifting cylinder(3713CH)
4120006611001 缸筒总成24A138700 Cylinder tube
4120006628002 活塞杆总成24A113870 piston rod
4120006611002 缸盖24C101110 Cover
008617753913626 SDLG woooyeah1@163.com
4120006000005 衬套24S290401 9040 BUSHING
4120005980008 钢丝挡圈-孔用24C090220 RETAINING RING
4120005999004 密封件-缓冲24H009004 Sealing ring
4120005999005 密封件-活塞杆24F209003 Sealing ring
4120005999006 挡圈-U形圈24E009025 Retaining ring
4120005999007 密封件-防尘24D209001 Sealing ring
4120005980009 钢丝挡圈-孔用24C090240 RETAINING RING
008617753913626 SDLG woooyeah1@163.com
4120006611003 O形圈24K11500A O-ring
4120006611004 挡圈-O形圈24M11600D O-ring
4120006611005 O形圈24K315761 O-ring
4120006611006 活塞24C102080 Piston
4120006611007 密封件-活塞24P216002 Sealing ring
4120005999013 O形圈24K10900A O-ring
4120005999014 挡圈-O形圈24M30950A O-ring
4120006611008 支承环24G216051 Sealing ring
4120005980011 活塞背母24C103050 NUT
4090000168 钢球GB308-5-GCr6 BALL
008617753913626 SDLG woooyeah1@163.com
4120005685008 螺钉-内六角凹端紧定24T908161 M8*16L SCREW
4120006628006 轴套24C116150 BUSHING
4120006611009 销边防尘24R308540 Sealing ring
4120006611010 螺钉-内六角圆柱头24T516755 Screw
4120005685012 固定座24C003020 M16 ANCHORAGE
4120006611011 密封件包24A103320S Sealing ring kit
2914001893.S1e:转斗缸总成-40 Tilt cylinder assembly
008617753913626 SDLG woooyeah1@163.com
29140020431 放平护板 Plate
4011001238 螺栓GB5783-M10*20flZnyc-8.8-480 SCREW
4015000426 垫圈GB96.1-10flZnyc-300HV-480 WASHER
4120007577 转斗油缸HSGF-190*90*548-1043 Tilt cylinder
4011001249 螺栓GB5783-M10*30flZnyc-8.8-480 SCREW
4011001510 螺栓GB16674.1-M12*35flZnyc-8.8-480 SCREW
4041000144 分体法兰LGB117-312552 FLANGE HALF
008617753913626 SDLG woooyeah1@163.com
4030000029 O形圈GB3452.1-37.5*3.55G O-RING
4041000878
4041000774 螺塞LGB135-01422 PLUG
4041000767 O形圈LGB168-11124 O-RING
29140018531 转斗缸大腔钢管 PIPE
008617753913626 SDLG woooyeah1@163.com
4011001529 螺栓GB16674.1-M12*55flZnyc-8.8-480 Screw
4011001559 螺栓GB16674.1-M12*50flZnyc-8.8-480 Screw
29140015431 管夹 CLAMP
008617753913626 SDLG woooyeah1@163.com
4011001248 螺栓GB5783-M10*25flZnyc-8.8-480 SCREW
4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 SCREW
4041000056 分体法兰LGB117-312550 FLANGE HALF
29140019171 转斗联右小腔钢管 PIPE
008617753913626 SDLG woooyeah1@163.com
4041000178 软管LGB106-012138 HOSE ASSEMBLY
4041001794 软管LGB106-012135 HOSE ASSEMBLY
29140019161 转斗联左大腔钢管 PIPE
4120007577:转斗油缸-41 Tilt cylinder(3713CH)
4104 I will give you the next payment code after payment
4120007577001 缸筒总成24A141200 Cylinder tube
4120007577002 活塞杆总成24A115200 Piston rod
4120005980003 缸盖24C101270 cover
4120005980010 衬套24S290501 BUSHING
4120005980008 钢丝挡圈-孔用24C090220 RETAINING RING
4120005999004 密封件-缓冲24H009004 Sealing ring
4120005999005 密封件-活塞杆24F209003 Sealing ring
4120005999006 挡圈-U形圈24E009025 Retaining ring
4120005999007 密封件-防尘24D209001 Sealing ring
4104 I will give you the next payment code after payment
4120005980009 钢丝挡圈-孔用24C090240 RETAINING RING
4120007577003 O形圈24K11800A O-ring
4120007577004 挡圈-O形圈24M11900D O-ring
4120007577005 O形圈24K318521 O-ring
4120005980005 活塞24C102210 Piston
4120007577006 密封件-活塞24P219002 Piston
4120005999013 O形圈24K10900A O-ring
4120005999014 挡圈-O形圈24M30950A O-ring
4120007577007 支承环24G219021 Sealing ring
4120005980011 活塞背母24C103050 NUT
4090000168 钢球GB308-5-GCr6 BALL
4104 I will give you the next payment code after payment
4120005685008 螺钉-内六角凹端紧定24T908161 M8*16L SCREW
4120005980012 轴套24C116170 BUSHING
4120006998003 销边防尘24R309520 Sealing ring
4120005980007 轴套24C117170 BUSHING
4104 I will give you the next payment code after payment
4120006560024 螺钉-内六角圆柱头24T520805 Screw
4120005801013 油杯24V2100A1 M10x1 GREASE CUP
4030000065
4120007577008 密封件维修包24A103940S Sealing kit
2915002250.S1a:连杆机构-42 Linkage structure
29150022492 动臂LL2810A Lifting arm
29150012281 摇臂 ROCKER ARM
4104 I will give you the next payment code after payment
4043001540 连杆LGB317-B648*100*113-46*124 CONNECTING ROD
2916000970.S2a:工作装置附件-43 Working equipment
4043001506 销轴LGB301-95*130*240-1000Y WELD PIN
4043000728 销轴LGB301-85*115*210/2G-40Cr WELD PIN
4043001422 销轴LGB301-110*212*405-1300Y WELD PIN
4043001507 销轴LGB301-85*130*240-1000Y WELD PIN
4043000173 销轴LGB301-80*140*260-40Cr WELD PIN
4043001505 销轴LGB301-85*142*265-1000Y WELD PIN
4104 I will give you the next payment code after payment
4043000027 轴套LGB302-85*95B3 BUSHING
4043000026 轴套LGB302-80*90A2 BUSHING
4043000031 轴套LGB302-110*80B1 BUSHING
4043000028 轴套LGB302-85*80B2 BUSHING
4043000035 垫片LGB303-85*130*1 SHIM
4043000752 轴套LGB302-95*104C2 BUSHING
4043000057 防尘圈LGB307-95 SEALING RING
4040000051 垫圈LGB001-16flZnyc-480 WASHER
4104 I will give you the next payment code after payment
4011001261 螺栓GB5783-M16*30flZnyc-8.8-480 SCREW
4043000059 O形圈LGB308-128*12 O-RING
4043000056 防尘圈LGB307-85 SEALING RING
4043000055 防尘圈LGB307-80 SEALING RING
4043000033 垫片LGB303-80*130*1 SHIM
4043000034 垫片LGB303-80*130*2 SHIM
4104 I will give you the next payment code after payment
4030000065 油杯JB7940.1-M10*1 LUBRICATING NIPPLE
4043000058 防尘圈LGB307-110 SEALING RING
4043000043 垫片LGB303-110*180*1 SHIM
