Description

4021000019 BALL BEARING 滚动轴承GB276-6210N
4015000024 RETAINING RING 挡圈GB894.1-90-65Mn
29050012701 DRIVE SHAFT GEAR 轴齿轮
29050023111 GASKET 密封垫
4021000012 BALL BEARING 滚动轴承GB276-6012
29050011363 Gasket 密封垫
4011000855 BOLT 螺栓GB16674-M10*55EpZn-10.9
4120005410 GEAR PUMP 变速泵LG03-BSB-A
29050020551 SHIM 调整垫片
29050020561 SHIM 调整垫片
29050020571 SHIM 调整垫片
29050020921 SHIM 调整垫片
29050025561 SHIM 调整垫片
4014000030 SCREW 吊环螺钉GB825-M20EpZn-20
008617753913626 SDLG woooyeah1@163.com
29050018031 NIPPLE 透气接头
29050033171 Plug 螺塞R1/2
4011000174 BOLT 螺栓GB21-M10*70EpZn-8.8
4120000064 CONTROL VALVE 变速操纵阀LG03-BSF
29050011381 GASKET 密封垫
4011000097 BOLT 螺栓GB5783-M18*40EpZn-8.8
4015000029 SPRING WASHER 垫圈GB93-18-65Mn
29050019321 ATTACHMENT BRACKET 连接座
2030900065 OIL FILTER 滤油器总成
29050015471 WASHER 垫圈8
4011000107 BOLT 螺栓GB5783-M8*30EpZn-8.8
29050023011 PLATE 压盖
4015000163 WASHER 垫圈JB1002-39-T2
29050023001 NIPPLE 接头体
4190000007 MAGNET 环形磁铁LG03-CT70*32*14
4015000013 RETAINING RING 挡圈GB893.1-70-65Mn
3030900232 SHIM 垫片
4011001013 SCREW 螺栓GB5782-M10*80EpZn-10.9
29050020181 GEAR 转向泵驱动齿轮
4021000020 BALL BEARING 滚动轴承GB276-6211
008617753913626 SDLG woooyeah1@163.com
29050000071 BEARING BUSHING 轴承套
3030900098 PLUG 圆柱堵塞
29050018471 NIPPLE 接头体
4030000013 O-RING O形圈GB1235-32*3.1
29050027261 Name plate 变速箱标牌
4019000012 RIVET 铆钉GB827-3*5-BL2
3030900103 PRESSURE DISC 直接档受压盘
4021000015 BALL BEARING 滚动轴承GB276-6022
3030900104 SHAFT 直接档轴
3030900105 SCREW 螺栓
4015000288 WASHER 垫圈GB1230-12EpZn-45
2030900020 FRICTION DISC 直接档主动片
3030900106 FRICTION DISC 直接档从动片
3030900107 PISTON 直接档活塞
29050016431 GEAR 中间输出齿轮
3030900109 CLUTCH CYLINDER 直接档油缸
3030900115 PIN 销
4021000016 BALL BEARING 滚动轴承GB276-6204
3030900110 SEALING RING 旋转油封
4021000024 BALL BEARING 滚动轴承GB276-6312
008617753913626 SDLG woooyeah1@163.com
3030900111 SEALING RING 旋转油封
29050020491 SHIM 调整垫片
29050020501 SHIM 调整垫片
29050020511 SHIM 调整垫片
29050020931 SHIM 调整垫片
3030900113 SEALING RING 密封环
2030900061
3030900112 PIN 销
3030900114 SPRING RING 碟形弹簧
4011000723 BOLT 螺栓GB5783-M8*20-8.8
4013000162 NUT 螺母GB6170-M8-8
4015000036 SPRING WASHER 垫圈GB93-8-65Mn
4015000023 RETAINING RING 挡圈GB894.1-65-65Mn
4011001358 SCREW 螺栓GB5783-M10*30flZnyc-10.9-480
4015000384 WASHER 防松垫圈NASM1312-7-NL10
29050011161 WASHER 垫圈
4030000536 O-RING O形圈GB3452.1-122*3.55G
29050033351 Sealing retainer 油封座
4021000285 BEARING 滚动轴承GB292-7312ACM
29050023552 OUTPUT SHAFT 输出轴
29050016441 GEAR 输出轴齿轮
29050016931 RETAINING RING 挡圈
008617753913626 SDLG woooyeah1@163.com
4030000768 SEALING RING 密封圈GB13871.1-FB070095-F
4030000048 SEALING RING 骨架油封HG4-692-SG70*95*10
7100002101 O-RING O形圈GB3452.1-54.5*2.65G
29050023541 NUT 螺母
29070000221 WASHER 垫圈
29050012751 SHIM 调整垫片
29050012741 SHIM 调整垫片
29050012731 SHIM 调整垫片
29050025851 SEALING SLEEVE 密封套
29050033991 Shim 调整垫片
4015000017 RETAINING RING 挡圈GB893.1-90-65Mn
3030900168 SPACER SLEEVE 间隔套
4021000011 BALL BEARING 滚动轴承GB276-6010
29050032171 Piston 倒档活塞
3030900143 SEALING RING 外密封环
-2030900061
3030900163 SEALING RING 内密封环
2030900061
3030900170 SCREW 螺栓
008617753913626 SDLG woooyeah1@163.com
4015000036 SPRING WASHER 垫圈GB93-8-65Mn
29050023971 STOP WASHER 止动垫圈
29050023581 PLANET GEAR SHAFT 倒档行星轴
29050032191 Planet carrier 倒档行星架
29050023491 SPACER SLEEVE 隔套
29050020461 SHIM 垫片
29050022651 RETAINING RING 挡圈
4090000311 NEEDLE ROLLER 滚针GB309-4*40-GCr15
29050023471 PLANET GEAR 行星轮
2030900028 FRICTION DISC 倒档一档主动片
3030900140 FRICTION DISC 倒档一档从动片
3030900161 PIN 圆柱销
3030900141 SPRING 弹簧
3030900142 PIN 弹簧销轴
29050032201 Separator 摩擦片隔离架总成
29050023451 GEAR RING 倒档内齿圈
3030900156 RETAINING RING 挡圈
008617753913626 SDLG woooyeah1@163.com
29050023571 PLANET GEAR SHAFT 一档行星轴
29050023431 PLANET CARRIER 一档行星架
29050022671 STOP PLATE 止动盘
29050023481 SUN GEAR 太阳轮
4021000019 BALL BEARING 滚动轴承GB276-6210N
4015000024 RETAINING RING 挡圈GB894.1-90-65Mn
29050022711 FLANGE 直接档连接盘
4011001107 SCREW 螺栓GB5786-M14*1.5*40-8.8
29050023461 GEAR RING 内齿圈
29050022592 PISTON 一档活塞
3030900113 SEALING RING 密封环
2030900061
3030900159 ANCHOR PLATE 固定板
3030900146 SEALING RING 矩形密封圈
3030900145 CLUTCH CYLINDER 一档油缸
008617753913626 SDLG woooyeah1@163.com
4021000020 BALL BEARING 滚动轴承GB276-6211
4013000036 NUT 螺母GB6171-M10*1EpZn-8
4015000025 SPRING WASHER 垫圈GB93-10-65Mn
29050019581 INPUT SHAFT 中间输入轴
4021000055 BALL BEARING 滚动轴承GB276-6010E
4015000015 RETAINING RING 挡圈GB893.1-80-65Mn
