Description

29040001031 HOSE ASSEMBLY 滤清器至变速箱油管
4011000207 BOLT 螺栓GB5783-M12*45EpZn-8.8
4015000026 SPRING WASHER 垫圈GB93-12-65Mn
29040000041 GASKET 密封垫
4011001375 Bolt 螺栓GB16674.1-M12*30flZnyc-8.8-480
29040001041 BRACKET 支承架
29050018471 NIPPLE 接头体
4030000013 O-RING O形圈GB1235-32*3.1
4011000448 SCREW 螺钉GB70.1-M8*30EpZn-8.8
4015000036 SPRING WASHER 垫圈GB93-8-65Mn
4015000072 WASHER 垫圈GB97.1-8EpZn-300HV
4110000507057 Cover 上壳体QF60M33G-1-001
008617753913626 SDLG woooyeah1@163.com
4110000507058 By-pass valve 旁通阀QF60M33G-1-100
4030000305 O-RING O形圈GB3452.1-106*3.55G
4110000507007 FILTER INSERT 滤清器滤芯（传动油滤清器滤芯）
4110000507060 Filter cartridge 滤筒焊合件QF60M33G-1-200
4014000119 SCREW 螺钉GB70.1-M8*55EpZn-8.8
4110000507061 Valve shelf 旁通阀壳体QF60M33G-1-101
4110000507062 Sealing washer 密封垫DFM50S2T-10BG-204
4110000507063 Spring seat 弹簧座QF60M33G-1-102
4110000507064 Spring 旁通阀弹簧QF60M33G-1-104
4110000507065 Spring plate 弹簧盖QF60M33G-1-103
4013000360 NUT 螺母GB6182-M8EpZn-9
4110000507002 HOUSING 上壳体PYQ120A-001
4110000507
4110000507003 VALVE 旁通阀SFM360-300
008617753913626 SDLG woooyeah1@163.com
4110000507004 SEALING RING 胶圈PYQ120A-002W
4110000507007 FILTER INSERT 滤清器滤芯（传动油滤清器滤芯）
4110000507005 HOUSING 下壳体PYQ120A-200
4110000507
4014000128 SCREW 螺钉GB70-M8*25EpZn-8.8
4015000036 SPRING WASHER 垫圈GB93-8-65Mn
4011000448 SCREW 螺钉GB70.1-M8*30EpZn-8.8
4015000036 SPRING WASHER 垫圈GB93-8-65Mn
4110000507052 COVER 上盖QF60M33G-1-01
4110000507053 BY-PASS VALVE 旁通阀QF60M33G-1-02
4110000507054 O-RING O型圈QF60M33G-1-03
4110000507007 FILTER INSERT 滤清器滤芯（传动油滤清器滤芯）
4110000507055 SPRING 弹簧QF60M33G-1-06
4110000507056 FILTER CARTRIDGE 筒体QF60M33G-1-05
008617753913626 SDLG woooyeah1@163.com
4110000507020 Seat 底座JS-LQQX-01
4110000507021 Valve body 阀体JS-LQQ-05-05
4110000507023 SEALING WASHER 密封垫JS-LQQ-05-04
4110000507024 Spring support 弹簧支撑JS-LQQ-05-03
4110000507025 Spring 弹簧JS-LQQ-05-02
4110000507026 NUT 压紧螺母JS-LQQ-05-01
4014000235 SCREW 螺钉GB2671.2-M8*40EpZn-8.8
4110000507027 PLATE 滤清器压板JS-LQQX-04
4110000507028 SEALING RING O型密封圈44*3.1 JS-LQQ-06
4015000036 SPRING WASHER 垫圈GB93-8-65Mn
4013000033 NUT 螺母GB6170-M8EpZn-8
008617753913626 SDLG woooyeah1@163.com
4110000507007 FILTER INSERT 滤清器滤芯（传动油滤清器滤芯）
4110000507029 COVER 外罩JS-LQQX-03
4110000507030 SPRING 支撑簧JS-LQQX-08
4110000507031 SEALING RING 密封圈106*3.1 JS-LQQX-07
4110001544 BREATHER ASSEMBLY 空气滤清器SJXKL-M12
29050024951 Bracket 变速箱空滤支架
4011000447 BOLT 螺栓GB16674-M10*20EpZn-8.8
4030001101 HOSE 胶管JB8406-B16*1000
4017000011 CLAMP 喉箍JB8870-d32
29050027241 TRANSMISSION 变速箱总成BX50-03
29050023022 HOSE ASSEMBLY 变速泵吸油管总成
4041000056 FLANGE HALF 分体法兰LGB117-312550
4011000475 BOLT 螺栓GB16674-M10*30EpZn-8.8
4030000029 O-RING O形圈GB3452.1-37.5*3.55G
4041000878
4011001240 SCREW 螺栓GB16674-M12*25flZnyc-8.8-480
008617753913626 SDLG woooyeah1@163.com
29050027531 PLATE 橡胶垫
29050032872 Hose assembly 加油管总成
4190000010 PLUG 检油塞LG03-JYS1/4
29050022281 SHIM 调整垫片
29050022291 SHIM 调整垫片
29050022301 SHIM 调整垫片
4110001544001 FILTER INSERT 空气滤清器滤芯SJXKL-M12-H-02
29050026551 Tube 加油弯管
4017000007 CLAMP 喉箍JB8870-d60
4120003121 HOSE ASSEMBLY 胶管JB8406-B38*350
29050031781 Tube 加油管
29050025721 Oil filler cap assembly 加油管盖总成
29050025942 Chain 连接链
008617753913626 SDLG woooyeah1@163.com
29050027231 TRANSMISSION HOUSING 箱体
4011000017 BOLT 螺栓GB21-M10*30EpZn-8.8
29050015481 WASHER 垫圈10
4011001127 SCREW 螺栓GB5783-M14*40-10.9
4015000358 PLAIN WASHER 垫圈GB1230-14EpZn-45
29050024791 Shaft 二档总成
29050024241
29050022981 COVER 中盖
3030900091 END PLATE 端盖
29050011321 GASKET 密封垫
4030000011 O-RING O形圈GB1235-20*2.4
3030900102 PLUG 螺塞
29230009952 Brake assembly 鼓式制动器总成
29050027361 FLANGE 输出法兰总成
29050032401 Output shaft 输出轴总成
29050021541 FLANGE 输出法兰总成
29050023122 PIN 销
008617753913626 SDLG woooyeah1@163.com
29050032151 Planet gear kit 一倒档总成
29050025551 SHIM 调整垫片
29050020581 SHIM 调整垫片
29050020541 SHIM 调整垫片
29050020531 SHIM 调整垫片
29050020521 SHIM 调整垫片
7200000462 SECONDARY SHAFT 二轴总成
29050019471 CLUTCH 超越离合器总成
7200000462
7200000462
7200000462
2030900027 SHAFT 三轴总成
4110002522 TORQUE CONVERTER 变矩器YJSW315-8A
29040008321 TORQUE CONVERTER 变矩器总成YJSW315-8A
4110002522
4021000019 BALL BEARING 滚动轴承GB276-6210N
4015000024 RETAINING RING 挡圈GB894.1-90-65Mn
29050012701 DRIVE SHAFT GEAR 轴齿轮
29050023111 GASKET 密封垫
008617753913626 SDLG woooyeah1@163.com
4021000012 BALL BEARING 滚动轴承GB276-6012
29050011363 Gasket 密封垫
4011000855 BOLT 螺栓GB16674-M10*55EpZn-10.9
4120005410 GEAR PUMP 变速泵LG03-BSB-A
29050020551 SHIM 调整垫片
29050020561 SHIM 调整垫片
29050020571 SHIM 调整垫片
29050020921 SHIM 调整垫片
29050025561 SHIM 调整垫片
4014000030 SCREW 吊环螺钉GB825-M20EpZn-20
008617753913626 SDLG woooyeah1@163.com
29050018031 NIPPLE 透气接头
29050033171 Plug 螺塞R1/2
4011000174 BOLT 螺栓GB21-M10*70EpZn-8.8
4120000064 CONTROL VALVE 变速操纵阀LG03-BSF
29050011381 GASKET 密封垫
4011000097 BOLT 螺栓GB5783-M18*40EpZn-8.8
4015000029 SPRING WASHER 垫圈GB93-18-65Mn
29050019321 ATTACHMENT BRACKET 连接座
2030900065 OIL FILTER 滤油器总成
29050015471 WASHER 垫圈8
4011000107 BOLT 螺栓GB5783-M8*30EpZn-8.8
29050023011 PLATE 压盖
4015000163 WASHER 垫圈JB1002-39-T2
29050023001 NIPPLE 接头体
4190000007 MAGNET 环形磁铁LG03-CT70*32*14
4015000013 RETAINING RING 挡圈GB893.1-70-65Mn
3030900232 SHIM 垫片
008617753913626 SDLG woooyeah1@163.com
4011001013 SCREW 螺栓GB5782-M10*80EpZn-10.9
29050020181 GEAR 转向泵驱动齿轮
4021000020 BALL BEARING 滚动轴承GB276-6211
29050000071 BEARING BUSHING 轴承套
3030900098 PLUG 圆柱堵塞
29050018471 NIPPLE 接头体
4030000013 O-RING O形圈GB1235-32*3.1
29050027261 Name plate 变速箱标牌
4019000012 RIVET 铆钉GB827-3*5-BL2
