Description

2827000601.S1f:支撑构件总成-97 Support section
28270006021 中间支撑板 SUPPORT PLATE
4190003003 连接架（左） ATTACHING FRAME
28270006161 前支撑板总成 SUPPORT PLATE
4190003002 连接架（右） ATTACHING FRAME
28270006221 连接轴 SHAFT
28270006081 上轴套 BUSHING
008617753913626 XCMG woooyeah1@163.com
4021000282 带座外球面轴承GB7810-UEPFL 204 BEARING
4011000105 螺栓GB5783-M8*20EpZn-8.8 BOLT
4015000072 垫圈GB97.1-8EpZn-300HV WASHER GB97.1-8EpZn-300HV
28270006131 侧支撑板 SUPPORT PLATE TELL:008617753913626
28270006141 锁销 PIN 008617753913626 XCMG woooyeah1@163.com
4011000102 螺栓GB5783-M8*16EpZn-8.8 BOLT GB5783-M8*16EpZn-8.8
28270006091 下轴套 BUSHING TELL:008617753913626
28270006231 把手 HANDLE TELL:008617753913626
28270006271 内六角螺栓5/16-18UNC SCREW
28270008851 垫圈10*20*0.5 WASHER
008617753913626 XCMG woooyeah1@163.com
28270008861 垫圈10*20*1 WASHER TELL:008617753913626
28270006311 弹簧2 SPRING 008617753913626 XCMG woooyeah1@163.com
4015000181 垫圈GB97.1-16EpZn-300HV WASHER GB97.1-16EpZn-300HV
4013000082 螺母GB6172.1-M16EpZn-05 NUT GB6172.1-M16EpZn-05
28270006291 弹簧销2 PIN 008617753913626 XCMG woooyeah1@163.com
4013000007 螺母GB6170-M10EpZn-8 NUT GB6170-M10EpZn-8
4015000129 挡圈GB894.1-20-65Mn RETAINING RING GB894.1-20-65Mn
28270007801 调整垫片Ⅰ SHIM 008617753913626 XCMG woooyeah1@163.com
28270007811 调整垫片Ⅱ SHIM 008617753913626 XCMG woooyeah1@163.com
4015000204 挡圈GB893.1-42-65Mn RETAINING RING GB893.1-42-65Mn
4021000283 滚动轴承GB276-6004-2Z BALL BEARING TELL:008617753913626
28270006281 弹簧销1 PIN 008617753913626 XCMG woooyeah1@163.com
28270006301 弹簧1 SPRING
28270011091 中间支撑板总成 Support section
2827000658.S1c:转向控制总成-98 Steering assembly
4120003680 方向盘FXP-953 STEERING WHEEL
4110001907 转向柱 STEERING COLUMN
4013000028 螺母GB6170-M6EpZn-8 NUT GB6170-M6EpZn-8
4015000198 垫圈GB96.1-6EpZn-300HV WASHER GB96.1-6EpZn-300HV
28270006411 压板 PLATE 008617753913626 XCMG woooyeah1@163.com
28270006421 保护罩 LIFTER CASING TELL:008617753913626
28270006431 转向柱支架 BRACKET TELL:008617753913626
4011000082 螺栓GB5783-M10*25EpZn-8.8 BOLT GB5783-M10*25EpZn-8.8
4015000162 垫圈GB97.1-10EpZn-300HV WASHER
28270006481 转向器固定架 BRACKET TELL:008617753913626
28270008121 销轴 PIN 008617753913626 XCMG woooyeah1@163.com
4016000100 开口销GB91-2*20EpZn-Q235A SPLIT PIN GB91-2*20EpZn-Q235A
4014000144 螺钉GB70.1-M10*70EpZn-8.8 SCREW GB70.1-M10*70EpZn-8.8
2828001076.S:上罩总成-100 Cover 008617753913626 XCMG woooyeah1@163.com
28280010011 衬网 IRON NET 008617753913626 XCMG woooyeah1@163.com
4011000101 螺栓GB5783-M6*20EpZn-8.8 BOLT GB5783-M6*20EpZn-8.8
4015000198 垫圈GB96.1-6EpZn-300HV WASHER GB96.1-6EpZn-300HV
4015000162 垫圈GB97.1-10EpZn-300HV WASHER
4011000081 螺栓GB5783-M10*20EpZn-8.8 BOLT GB5783-M10*20EpZn-8.8
4015000168 垫圈GB97.1-12EpZn-300HV WASHER
4016000035 开口销GB91-4*20EpZn-Q235A SPLIT PIN GB91-4*20EpZn-Q235A
28280007941 拉杆焊合 GUIDE MEMBER 008617753913626 XCMG woooyeah1@163.com
29330022651 橡胶垫 RUBBER PLUG
4190000916 门锁NBS5013A DOOR LOCK
28280010051 盖板 COVER
28280010671 上罩 HOOD
008617753913626 XCMG woooyeah1@163.com
4043001382 卡子胶条LGB320-S770 SEALING STRIP
2829000633.S1a:覆盖件附件-101 Cover
28290004871 梯子 LADDER
28290006351 电瓶箱总成 BATTERY BOX
28290006341 液压油箱支架总成 Bracket
28290006311 右后转向灯罩 LAMP SHROUD
28290006301 左后转向灯罩 LAMP SHROUD
008617753913626 XCMG woooyeah1@163.com
4015000168 垫圈GB97.1-12EpZn-300HV WASHER
4013000011 螺母GB6170-M12EpZn-8 NUT GB6170-M12EpZn-8
4011000207 螺栓GB5783-M12*45EpZn-8.8 BOLT GB5783-M12*45EpZn-8.8
4011000082 螺栓GB5783-M10*25EpZn-8.8 BOLT GB5783-M10*25EpZn-8.8
4015000162 垫圈GB97.1-10EpZn-300HV WASHER
28290007391 底封板 PLATE 008617753913626 XCMG woooyeah1@163.com
4043000948 卡子胶条LGB320-U210 SEALING STRIP
29340011901 走线胶套 RUBBER SLEEVE
4011000102 螺栓GB5783-M8*16EpZn-8.8 BOLT GB5783-M8*16EpZn-8.8
4015000256 垫圈GB96.1-8EpZn-300HV WASHER GB96.1-8EpZn-300HV
28290006271 右后转向灯罩 LAMP SHROUD
008617753913626 XCMG woooyeah1@163.com
2829000487.S1d:梯子-102 Ladder
28290004882 胶板 Rubber plate
28290004891 踏脚 PEDAL
28290004901 踏脚 PEDAL
28290004921 固定板 Fixing plate
28290004931 丝座 Fixing plate
28290004941 套管 Thimble 008617753913626 XCMG woooyeah1@163.com
4011000049 螺栓GB5782-M10*55EpZn-8.8 SCREW GB5782-M10*55EpZn-8.8
4015000197 垫圈GB96.1-10EpZn-300HV WASHER GB96.1-10EpZn-300HV
4011000184 螺栓GB5783-M10*40EpZn-8.8 BOLT GB5783-M10*40EpZn-8.8
28290004911 压板 Fixing plate 008617753913626 XCMG woooyeah1@163.com
2829000635.S1e:电瓶箱总成-103 Battery box assembiy
28290007351 电瓶箱小总成 BATTERY BOX
29340011901 走线胶套 RUBBER SLEEVE
4013000033 螺母GB6170-M8EpZn-8 NUT
4015000072 垫圈GB97.1-8EpZn-300HV WASHER GB97.1-8EpZn-300HV
28290006471 压板 ANCHOR PLATE
28290006501 锁紧螺杆 SCREW 008617753913626 XCMG woooyeah1@163.com
4011000447 螺栓GB16674-M10*20EpZn-8.8 BOLT GB16674-M10*20EpZn-8.8
4043003367 橡胶板LGB332-A200*80*17 Rubber plate
4043002886 橡胶板LGB332-A200*60*6 Rubber plate
2829000735.S:电瓶箱小总成-104 Battery box
28290006361 电瓶箱 BATTERY BOX
008617753913626 XCMG woooyeah1@163.com
4190000025 扣锁NBxs1013 LOCK NBXS1013
4014000023 螺钉GB818-M5*10EpZn-4.8 SCREW GB818-M5*10EpZn-4.8
29340009101 橡胶塞 RUBBER PLUG ZL30F.12.2-1
28290006451 拉杆 PULL ROD 008617753913626 XCMG woooyeah1@163.com
4015000168 垫圈GB97.1-12EpZn-300HV WASHER
4016000035 开口销GB91-4*20EpZn-Q235A SPLIT PIN GB91-4*20EpZn-Q235A
2829000634.S:液压油箱支架总成-105 Bracket 008617753913626 XCMG woooyeah1@163.com
28290005041 右支架 BRACKET
28290004961 左支架 BRACKET
4011000089 螺栓GB5783-M12*30EpZn-8.8 BOLT
28120002011 厚垫圈12 WASHER 008617753913626 XCMG woooyeah1@163.com
2829000631.S:右后转向灯罩-106 Right rear steering lamp shroud
4011000102 螺栓GB5783-M8*16EpZn-8.8 BOLT GB5783-M8*16EpZn-8.8
4015000256 垫圈GB96.1-8EpZn-300HV WASHER GB96.1-8EpZn-300HV
28290006271 右后转向灯罩 LAMP SHROUD
008617753913626 XCMG woooyeah1@163.com
2829000630.S:左后转向灯罩-107 Left rear steering lamp shroud
4011000102 螺栓GB5783-M8*16EpZn-8.8 BOLT GB5783-M8*16EpZn-8.8
4015000256 垫圈GB96.1-8EpZn-300HV WASHER GB96.1-8EpZn-300HV
28290006261 左后转向灯罩 LAMP SHROUD
