Description

4110001121:第二轴(230102)-17 shaft and clutch assembly(230102)
4110001121065 挡环1701393-1700 RETAINING RING
4110001121066 滑动齿套-同步器 1701393-11 SLEEVE
4110001121067 卡环-固定第三速齿座用 1701396-11 RETAINING RING
4110001121068 卡环-固定第三速齿座用 1701397-11 RETAINING RING
4110001121069 齿座-第同步器 1701391-11 TOOTH HOLDER
4110001121070 弹簧-同步器1701357-11 SPRING
4110001121071 定位块-同步器1701358-11 BLOCK
4110001121072 推块-同步器1701359-11 BLOCK
008617753913626 XCMG woooyeah1@163.com
4110001121073 同步环-第三速同步器1701387-11 SYNCHRONIZER RING
4110001121074 卡环-固定同步器锥体1701386-11 RETAINING RING
4110001121075 同步锥-三速齿轮1701384-11 SYNCHRONIZING CONE
4110001121076 三速齿轮1701351-1700 GEAR
008617753913626 XCMG woooyeah1@163.com
4110001121077 滚针轴承-三速齿轮K48 54 43 NEEDLE BEARING
4110001121078 轴用卡环1701374-11 RETAINING RING
4110001121079 挡圈-二速齿轮1701367-1700 RETAINING RING
4110001121080 衬套-二速齿轮1701366-1700 SLEEVE
4110001121081 滚针轴承-二速齿轮K65 72 35 NEEDLE BEARING
4110001121082 第二速齿轮1701311-1700 GEAR
008617753913626 XCMG woooyeah1@163.com
4110001121083 锥体-第二速齿轮1701352-11 CONE FITTING
4110001121084 卡环-固定同步器锥体1701353-11 RETAINING RING
4110001121085 同步环-第一、二速同步器1701354-11 SYNCHRONIZER RING
4110001121086 齿套-第一、二速同步器1701361-11 GEAR SLEEVE
4110001121087 齿座-第一、二速同步器1701356-11 TOOTH HOLDER
4110001121089 锥体-第一速齿轮1701352-11 CONE FITTING
4110001121090 第一速齿轮1701331-1700 GEAR
008617753913626 XCMG woooyeah1@163.com
4110001121091 滚针轴承-第一速齿轮K65 72 20 NEEDLE BEARING
4110001121092 隔套-滚针轴承1701332-1700 BEARING BUSHING
4110001121093 防转销-二速齿轮衬套1701368-11 PIN
4110001121094 第二轴-变速箱1701301-1700H SECONDARY SHAFT
4110001121095 滚针轴承-倒一速齿轮K65 72 20 NEEDLE BEARING
4110001121097 倒一速齿轮1701339-1700 REVERSE GEAR
4110001121098 锥体-倒一速齿轮1701352-11 CONE FITTING
008617753913626 XCMG woooyeah1@163.com
4110001121100 同步环-倒一、倒二速同步器1701354-11 SYNCHRONIZER RING
4110001121101 齿套-倒一、倒二速同步器1701361-11 GEAR SLEEVE
4110001121102 齿座-倒一、倒二速同步器1701356-11 TOOTH HOLDER
4110001121103 挡圈-倒二速齿轮齿轮衬套1701348-1700 RETAINING RING
4110001121104 滚针轴承-倒二速齿轮K59 66 20 NEEDLE BEARING
4110001121106 锥体-倒二速齿轮1701352-11 CONE FITTING
4110001121107 衬套-倒二速齿轮1701341-1700 SLEEVE
4110001121108 倒二速齿轮1701371-1700 REVERSE GEAR
008617753913626 XCMG woooyeah1@163.com
4110001121109 止推垫-倒二档齿轮1701343-1700A THRUST WASHER
4110001121110 衬套-二轴后轴承1701344-1700A SLEEVE
4110001121174 圆柱滚子轴承-二轴后NUP311EN Roller bearing
4110000415139 轴用挡圈Q433120 RETAINING RING
4110001121:中间轴组件(230102)-18 drive shaft(230102)
4110001121112 滚柱轴承-中间轴前端NJK309V1 ROLLER BEARING
4110001121113 传动齿轮-中间轴1701224-1700 GEAR
4110001121114 三速齿轮-中间轴1701214-1700 GEAR
4110001121115 中间轴-变速箱1701211-1700 SHAFT
008617753913626 XCMG woooyeah1@163.com
4110001121116 滚柱轴承-中间轴后端NUPK309NRV3 ROLLER BEARING
4110001121117 轴用挡圈Q433100 RETAINING RING
4110001121118 卡环-锁紧中间轴后轴承1701399-680 RETAINING RING
4110001121:倒档惰轮组件(230102)-19 idler gear(230102)
4110001121119 挡圈-倒档惰轮1701487-1700 RETAINING RING
4110001121120 倒档惰轮1701482-1700 IDLER GEAR
008617753913626 XCMG woooyeah1@163.com
4110000415144 滚针轴承-倒档惰轮K42 54 42 NEEDLE BEARING
4110001121121 隔套-滚针轴承1701486-1700 BEARING BUSHING
4110001121122 倒档惰轮轴1701481-1700 REVERSE SHAFT
4110000415147 O型圈-倒档惰轮轴 Q7343142B O-RING
4110001121123 锁片-倒档惰轮轴1701489-11 LOCK PLATE
4110000415148 008617753913626 XCMG woooyeah1@163.com
4110000415149 弹簧垫圈Q40308 SPRING WASHER
4110000415150 螺栓-紧固锁片用CQ1500816 BOLT
4110001121:上盖总成(230102)-20 Engine cover(230102)
4110001121124 堵盖总成1701015-C1 PLUG
008617753913626 XCMG woooyeah1@163.com
4110001121125 变速叉-第三速1702062-1700 GEAR SELECTOR FORK
4110001121126 波口弹簧销-锁住变速叉用1702041-11 SPRING PIN
4110001121127 弹性销-锁住变速叉用1702042-11 SPRING PIN
4110001121128 吊钩1702143-6T1 LIFTING EYE
4110001121172 弹簧垫圈Q40310 Spring washer
4110001121129 螺栓-紧固上盖CQ1501025 BOLT
4110000415052 TELL:008617753913626 XCMG
4110001121130 螺栓-紧固上盖CQ1501045 BOLT
4110000415185 通气塞1702091-11 PLUG
4110001121171 上盖-变速箱1702021-1707 Cover
008617753913626 XCMG woooyeah1@163.com
4110000415162 变速叉轴-第一、二速1702057-1100 GEAR SELECTOR SHAFT
4110001121132 互锁块-变速叉轴互锁用1702028-11 BLOCK
4110001121133 互锁销-变速叉轴互锁用1702029-11 PIN
4110001121134 变速叉-第一、二速1702058-1700 GEAR SELECTOR FORK
4110001121135 吊装臂1702069-1103 LIFTING EYE
4110001121017 组合垫圈1701712-C1 WASHER
4110001121137 变速叉轴-第三速1702061-11 GEAR SELECTOR SHAFT
4110000415170 钢球-变速叉轴自锁用Q966955 BALL
4110000415169 弹簧-变速叉轴自锁用1702026-11 SPRING
4110001121138 塞片CQ72112 PLUG 008617753913626 XCMG
4110001121139 变速导块总成-第三速1702065-1700 TRANSPORT BLOCK
4110001121140 变速导块总成-倒一、二速1702045-1700 TRANSPORT BLOCK
4110001121141 变速叉轴-倒一、二速1702053-1700 GEAR SELECTOR SHAFT
4110001121142 变速叉-倒一、二速1702037-1704 GEAR SELECTOR FORK
4110001121143 倒档信号开关3729100-XMJLS REVERSE LIGHT SWITCH
4110001121016 注油螺塞1701711-C1 PLUG
