Description

倒档一档主动片 250200527 Reverse-1st Driving Plate
倒档一档从动片 250200531 Reverse-1st Friction Plate
直接档连接盘 250200432 Direct Forward Connecting Flange
挡圈90 805400078 GB/T894.1-1986 RING
滚动轴承6210N 800511304 GB／T276-94 Ball Bearing
太阳轮 272200133 Sun Gear
止动盘 272200131 Lock Plate
一档行星架 272200132 1st Forward Planetary Carrier
挡圈 250200353 Snap Ring
倒档内齿圈 272200134 Reverse Inner Gear Ring
摩擦片隔离架总成 272200160 Clutch Anchor Assy
倒档行星架 272200125 Reverse Planetary Carrier
008617753913626 XCMG woooyeah1@163.com
止动垫片 250200355 Lock Washer
垫圈 10 805300010 Washer
螺栓 M8×12 805000616 GB/T5783-2000 Bolt
内密封环 250200481 Inner Seal Ring
倒档活塞 272200124 Reverse Piston
轴承6010E 800511274 GB／T276-94 Bearing
一档行星轴 272200130 1st Forward Planetary Shaft
垫片 272200129 Washer
隔离套 250200360 Spacer
滚针φ4 x 34.8 800511260 GB309-77 Needle Roller
行星轮 250200646 Planetary Gear
弹簧销轴 250200356 Guide Pin
弹簧 250200485 Spring
倒档行星轴 272200137 Reverse Planet Spindle
挡圈 90 805400009 GB/T893.1-1986 Circlip 90
轴承6022 800511306 GB／T276-94 Ball Bearing
导向销 272200146 Leading Pin
直接档受压盘 272200143 Direct Forward Gear Reaction Disc
008617753913626 XCMG woooyeah1@163.com
二档主动片 250200521 2st Forward Driving Plate
直接档轴 272200144 Direct Forward Gear Dive Shaft
螺栓 M10×20 805000714 GB/T5783-2000 Blot
垫圈 10 805300014 GB/T93-1987 Washer
二档齿圈 272200145 2st Forward Gear Ring
二档从动片 250200522 2st Forward Friction Plate
内密封环 250200484 Inner Seal Ring
轴承6204 800511301 GB／T276-94 Ball Bearing
挡圈 65 805400076 GB/T894.1-1986 WASHER
盘形弹簧 250200349 Belleville Spring
直接档活塞 272200147 Direct Forward Piston
旋转油封 250200525 Seal Ring
销 250200613 Pin
直接档油缸 272200148 Direct Forward Cylinder
螺栓M12X1.25X100 805002101 8.8级 Bolt
止动垫片 250200361 Lock Nut Washer
直接档输出齿轮 272200273 Valve Body
滚动轴承6312 800511596 GB／T276-94 Ball Bearing
旋转油封 250200526 Seal Ringearing
调整垫片 250200813 Adjust Washer
锁紧螺母M33X1.5 272200177 Nut
垫圈 272200176 Cover
法兰 252101239 Flange
法兰 272200179 II Flange
防尘环 272200140 Dustproof Ring
轴套 250200689 spacer
O形圈130×5.7 803164062 GB1235-76 O-Ring
油封座 272200138 Oil Seal Seat
油封CR HMS5 70X95X10 801101745 SKF Oil Seal
油封B70x95x10B 801101722 GB9877.1-88 Oil Seal
008617753913626 XCMG woooyeah1@163.com
挡圈 130 805400024 WASHER
轴承6312 800500196 GB/T276-1994 Ball Bearing
输出轴齿轮 272200265 Output Shaft Gear
输出轴 272200354 Output Shaft
轴承6410 800511302 GB/T276-1994 Ball Bearing
O形圈 250200687 O-Ring
螺栓 M6×16 805000322 GB/T5783-2000 Bolt
挡罩 272200169 II Cover
联结螺栓 252101238 II Link Bolt
隔套 272200353 Spacer
胶垫 250200227 Rubber Pad
变速操纵阀 250200147 Gearshift Control Valve
密封垫 250200292 Seal Gasket
箱体 272200153 Transmission Housing
轴承6211 800511443 GB/T276-1982 Bearing
轴承套 272200152 Bearing Gasket
密封垫 272200150 Seal Gasket
密封垫 250200442 Seal Gasket
端盖 250200441 End Cover
圆柱销 250200359 Seal Gasket
FSKGA1放水阀 803605397 Water Drain Valve
O形圈 45×3.5 801100042 GB 1235-76 O-ring
轴承6012 800500249 GB／T276-94 Ball Bearing
工作泵轴齿轮 272200262 Working Pump Shaft Gear
挡圈90 805400078 GB/T894.1-1986 RING
滚动轴承6210N 800511304 GB／T276-94 Ball Bearing
转向泵轴齿轮 272200263 Steering Pump Shaft Gear
008617753913626 XCMG woooyeah1@163.com
弹簧 272200288-01 Spring
滚柱 272200288-02 Cylinder Roller
销 272200288-03 Pin
轴承6211 800511443 GB/T276-1982 Bearing
螺母 M10×1 805200090 GB/T6171-2000 NUT
垫圈 10 805300014 GB/T93-1987 Washer
中间输入轴 272200288-04 Medium Input Shaft
球轴承6010 800511300 GB／T276-1994 Ball Bearing
隔离套 272200288-05 Space Bushing
内环凸轮 272200288-06 Inner Ring Cam
盖板 272200288-07 Plate
隔离环 272200288-08 Bearing Cage
螺栓 272200288-09 Bolt
挡圈 80 805400061 GB893.1-86 Anti-extrusion Ring
外环齿轮 272200288-10 Outer Ring Gear
球轴承6210(50X90X20) 800500185 GB／T276-94 Ball Bearing
隔离垫圈 272200288-11 Washer
弹簧座 272200270-01 Spring Cover
弹簧 272200270-02 Spring
滚柱Φ15X32 272200270-03 Cylinder Roller
轴承6211 800511443 GB/T276-1982 Bearing
螺母 M10×1 805200090 GB/T6171-2000 NUT
垫圈10 805300062 GB859-87 Lock Washer
中间输入轴 272200271 Medium Input Shaft
轴承6010E 800511274 GB／T276-94 Bearing
隔离套 272200270-04 Space Bushing
滚柱左挡圈 272200270-05 Left End Cover
内环凸轮 272200270-06 Inner Ring Cam
滚柱右挡圈 272200270-07 Right End Cover
挡圈 80 805400061 GB893.1-86 Anti-extrusion Ring
螺栓 272200270-08 Bolt
外环齿轮 272200274 Outer Ring Gear
球轴承6210(50X90X20) 800500185 GB／T276-94 Ball Bearing
008617753913626 XCMG woooyeah1@163.com
隔离环 272200270-09 Bearing Cage
隔套 272200270-10 Space Bushing
螺母 M12 805200049 GB/T6170-2000 Nut
双头螺栓AMl2X35 803004322-01 GB897-74 Stud
骨架油封PG45x62x12 803004322-02 B2600-80 Skeleton Oil Seal
骨架油封PG45x62x12 4818007 B2600-80 Skeleton Oil Seal
泵体（止口Φ127） 803004322-03 Valve Body
泵体（止口Φ127） 403601 Valve Body
垫圈 402106 Washer
垫圈 803004322-04 Washer
管接头 803004322-05 Joint
管接头 402111 Joint
轴 403603 Shaft
轴 803004322-06 Shaft
隔离套 803004322-07 Spacer
隔离套 403611 Spacer
滚针φ4X30 803004322-08 GB309-84 Needle Roller
008617753913626 XCMG woooyeah1@163.com
小齿轮 803004322-09 Driving Gear
小齿轮 403602 Driving Gear
密封垫 403606 Seal Gasket
密封垫 803004322-10 Seal Gasket
泵盖 803004322-11 Pump Cover
泵盖 403608 Pump Cover
密封垫 403609 Seal Gasket
密封垫 803004322-12 Seal Gasket
挡圈 803004322-13 GB893.1-86 Snap Ring
挡环 803004322-14 Snap Ring
