Description

4110000218075 PIN 开口销04050-04030
4110000218080 NUT 螺母BD05-00010
4110000218022 WASHER 大垫圈01643-32260
4110000218005 O-RING O 形圈07000-03032 32*3.5
4110000218050 FLANGE 法兰盘BD05K-03000
008617753913626 SDLG woooyeah1@163.com
4110000218057 SEALING RING 骨架油封 07012-00048
4110000218058 SEALING RING 骨架油封07012-70050
4110000960006 SCREW 螺栓 M12X25 01010-81225
4110000160054 GASKET 垫圈01602-21236
4110000218110 SEAT 轴承座BD05-00008
4110000218046 SHIM 调整垫BD05-00014
4110000218007 O-RING O 形圈07000-02105 105*3.1
4021000171 ROLLER BEARING P轴承GB297-30308
4110000218099 GEAR 输出齿轮BDS05-00016
4110000218056 SPACER SLEEVE 隔套BD05-00007
4110000218100 OUTPUT SHAFT 输出轴BD05L-00003
4110000218111 SEAT 轴承座BD05L-00002
008617753913626 SDLG woooyeah1@163.com
4011000061 BOLT 螺栓GB5782-M12*35EpZn-8.8
4110000218105 SEAT 制动器支座ZL15E-00002
4110000013028 BRAKE SYSTEM 制动器总成BD05-14000C
4015000381 Washer 垫圈GB7244-10-65Mn
4014000185 SCREW 螺钉GB70-M10*30EpZn-8.8
4110000218049 FLANGE 法兰BD05K-00001
4110000960005 SCREW 螺栓01010-81025
4110000218108 COVER 轴承盖BDX05-00001
4110000218038 RUBBER WASHER 垫片BDX05-00002
4110000218039 RUBBER WASHER 垫片BDX05-00003
008617753913626 SDLG woooyeah1@163.com
4110000218109 SEAT 轴承座BDX05-00004
4110000218101 FLANGE 输入法兰盘BDX05-01000
4110000218092 GASKET 密封垫BDX05-00006
4110000218045 SHIM 调整垫BDX05-00008
4110000218102 INPUT SHAFT 输入轴BDX05-00009
4110000218015 GEAR 齿轮BDX05-00010
4110000218021 HOUSING 传动箱壳体BDX05-00011
4110000218065 NIPPLE 管接头BDX05-00012
4110000218075 PIN 开口销04050-04030
4110000960004 SCREW 螺栓01010-81230
4110000160054 GASKET 垫圈01602-21236
008617753913626 SDLG woooyeah1@163.com
4110000218057 SEALING RING 骨架油封 07012-00048
4110000218004 O-RING O 形圈07000-02105 105*2.5
4110000218007
4021000021 BALL BEARING 滚动轴承GB276-6308
4021000169 BALL BEARING P轴承GB276-6006
4110000960010 SCREW 螺栓Bolt M10X30 01010-81030
4015000381 Washer 垫圈GB7244-10-65Mn
4110000960005 SCREW 螺栓01010-81025
4110000218005 O-RING O 形圈07000-03032 32*3.5
4110000218022 WASHER 大垫圈01643-32260
008617753913626 SDLG woooyeah1@163.com
4110000218080 NUT 螺母BD05-00010
4110000218103 NIPPLE 弯管接头BD05-00024
4110000218059 HOSE ASSEMBLY 管BD05-08000
4110000218060 HOSE ASSEMBLY 管BD05-09000
4110000218061 HOSE ASSEMBLY 管BD05-10000
4110000218062 HOSE ASSEMBLY 管BD05-11000
4110000218076 HOUSING 壳体BD05-00001
4110000218033 GASKET 垫BD05-00013
008617753913626 SDLG woooyeah1@163.com
4110000218031 ANCHOR PLATE 底板BD05-00012
4110000218083 PLUG 螺塞07044-12412
4110000218006 O-RING O 形圈07002-02434
4015000381 Washer 垫圈GB7244-10-65Mn
4110000960005 SCREW 螺栓01010-81025
4110000218037 RUBBER WASHER 垫片BD05-03004
4110000218011 BEARING BUSHING 衬套BD05-04002
4110000218053 COVER PLATE 盖BD05-04001
008617753913626 SDLG woooyeah1@163.com
4110000218082 PLUG 螺塞07043-00108
4110000960013 WASHER 垫圈07005-02716
4110000960014 NIPPLE 接头ZL15X-02000
4110000218089 SCREW 螺栓ZL15B-00001
4110000611016 DRAIN VALVE 放水阀（组合垫10）BD05L-00006（JB982-77）
4110000218012 BEARING BUSHING 衬套BD05-03001
4110000218052 COVER PLATE 盖BD05-03002
008617753913626 SDLG woooyeah1@163.com
4110000218079 SCREW 螺钉BD05-03003
4110000218034 WASHER 垫BD05-00025
4110000218116 CONTROL VALVE 变速箱操纵阀BD05-15000-04
4110000013032 SEALING WASHER 组合密封垫圈07005-01812
4110000013033 NIPPLE 接头BD05N1-00003
4110000218001 OIL FILTER 滤油器 BD05-13000
4015000299 WASHER 垫圈JB982-48
4110000218084 PLUG 螺塞BD05-00027
4110000223018 BREATHER CAP 呼吸器1BD05N1-05000
4110003056 Control mechanism 变速操纵软轴
29060008191 BRACKET 软轴固定支架
008617753913626 SDLG woooyeah1@163.com
4011000474 BOLT 螺栓GB16674-M10*25EpZn-8.8
4011001299
4011000807 BOLT 螺栓GB16674-M8*12EpZn-8.8
29060009321 BRACKET 支架
29060009331 BLOCK 感应块
4190002767001 HANDLE BALL 换挡手球LGH9180001
4190002767002 HANDLE BALL 高低速手球LGH9180002
4110002149001 CONNECTING ROD 换挡手柄焊合LGH9180003
4190002767004 CONNECTING ROD 高低速手柄焊合LGH9180004
4120000084073 Washer 6 gb/t93-1987 垫圈6 GB/T93-1987
008617753913626 SDLG woooyeah1@163.com
4190002767006 Bolt M6×1-25螺栓LGH9330007
4190002767007 Bolt M6×1-30螺栓LGH9180005
4190002767008 SHAFT 齿轮轴组合件LGH9180006
4190002767009 LINK 连接颈LGH9180007
4190002767010 box 换挡盒焊合件LGH9180008
4190002767011 GEAR RACK 齿条LGH9180009
4190002767012 WASHER 平垫φ8
4190002767013 WASHER 弹垫φ8
4110002434007 Screw 螺栓M8-50 LGH916D0001
008617753913626 SDLG woooyeah1@163.com
4110003056001 Seat 固定座4110003056-01
4190002767016 BALL φ8钢珠GZ-001
4110002149005 SPRING 弹簧LGH93300010
4190002767018 Nut rm-008-01 m12×1.25 M12×1.25螺母RM-008-01
4190002767019 Bolt M12×1.25-15螺栓LGH9330009
4190000915019 Control cable 高低速软轴总成LGHR91800001
4190000915020 Control cable 换挡软轴总成LGHR91800002
4110001119010 Screw M6-7沉头螺栓GB/T819.2
008617753913626 SDLG woooyeah1@163.com
29070010771 Wheel assembly 车轮总成
4110000016 TIRE 轮胎GB2980-16/70-20
4110000016Q
4190000119 RIM 轮辋LY13-20.916.0A
29070014112 Front axle A513前驱动桥总成
4013000160 LOCK NUT 螺母GB889.2-M20*1.5EpZn-8
4011000848 BOLT 螺栓GB5785-M20*1.5*185EpZn-8.8
4120001827 DISC BRAKE 制动钳-LG918
4120001740 NIPPLE 放气嘴
008617753913626 SDLG woooyeah1@163.com
4011000842 BOLT 螺栓GB5786-M16*1.5*55EpZn-10.9
29070009511 WASHER 垫圈
29070000051 TUBE 透气管
4013000078 NUT 螺母GB6173-M10*1EpZn-05
4016000124 PIN 销GB119.2-10u8*30
29070014121 FINAL DRIVE 前主传动
008617753913626 SDLG woooyeah1@163.com
4011000124 BOLT 螺栓GB5786-M12*1.25*35EpZn-10.9
4015000026 SPRING WASHER 垫圈GB93-12-65Mn
29070014132 Front axle casing 前桥壳总成
29070014141 SHAFT HALF 半轴
3050900003 NUT 轮辋螺母
29070014151 HUB REDUCTION 轮边减速器
29070012481 PLUG 磁性螺塞
4019000012 RIVET 铆钉GB827-3*5-BL2
