Description

402205826 bucket retract block for XCMG XC8-2570

F1411-4120008409-01 回转马达（26145） Swing motor
4120008409001 挡圈5527-0600 Ring retainer
4120008409002 挡圈5527-0900 Ring retainer
4120008409003 密封圈5527-0800 Sealing ring
4120008409004 护罩5527-1000 Cover
4120008409005 O型圈5527-1100 O-ring
4120008409006 间隔套5527-1300 Spacer
008617753913626 woooyeah1@163.com
4120008409007 轴承5527-0400 Bearing roller
4120008409008 轴5524-0110 Shaft
4120008409009 挡圈5527-0700 Ring retainer
4120008409010 壳体5525-2300 Case
4120008409011 呼吸器5522-1100 Breather
008617753913626 woooyeah1@163.com
4120008409012 油标5522-0600 5522-1000 Pipe
4120008409013 阀5527-3302 Valve
4120008409014 螺栓5527-3200 Screw
4120008409015 斜盘5527-1200 Plate
4120008409016 活塞5522-0700 Piston
4120008409017 九孔盘5525-0400 Plate
4120008409018 轴承座5528-0100 Guide
4120008409019 间隔套5527-1800 Spacer
4120008409020 滚针5527-1700 Needle roller
4120008409021 缸体5524-0090 Cylinder block
4120008409022 弹簧5527-1500 Spring
008617753913626 woooyeah1@163.com
4120008409023 挡圈5527-1600 Ring retainer
4120008409024 摩擦片5525-0900 Plate
4120008409025 摩擦片5525-1000 Plate
4120008409026 盘5524-0050 Plate
4120008409027 销5527-2300 Pin
4120008409028 O型圈5525-1100 O-ring
4120008409029 O型圈5527-2900 O-ring
4120008409030 弹簧座5525-0700 Brake piston
4120008409031 弹簧5522-0400 Spring
008617753913626 woooyeah1@163.com
4120008409032 轴承5527-0500 Bearing roller
4120008409033 阀5527-2401 Valve
4120008409034 堵头5527-3500 Plug
4120008409035 O型圈5527-3700 O-ring
4120008409036 螺栓5527-3900 Screw
4120008409037 弹簧5527-3600 Spring
4120008409038 弹簧座5527-3400 Seat
4120008409039 阀5525-1302 Valve
4120008409040 阀体5522-2400 Valve housing
008617753913626 woooyeah1@163.com
4120008409041 堵头5525-2400 Plug
4120008409042 O型圈5525-2500 O-ring
4120008409043 O型圈9023-2272 O-ring
F1411-4120008409-02 回转减速机（26145） Swing motor
4120008409044 驱动轴0425-5011 Drive shaft
4120008409045 垫片0454-0160 Plate
4120008409046 间隔套0425-5020 Spacer
008617753913626 woooyeah1@163.com
4120008409047 盖板0425-5030 Cover plate
4120008409048 螺栓0425-0280 Screw
4120008409049 轴承0925-3032 Bearing
4120008409050 间隔套0425-5040 Spacer
4120008409051 密封圈1525-0090 Wire
4120008409052 螺塞0423-0140 Plug
4120008409053 排水管0925-0150 0925-0161 Drain pipe
4120008409054 壳体0725-0012 Casing
4120008409055 销0425-0110 Pin
008617753913626 woooyeah1@163.com
4120008409056 密封圈0425-0070 Sealing ring
4120008409057 轴承0925-0051 Bearing
4120008409058 销20D0-0030 Spring pin
4120008409059 止推垫圈0425-2040 Thrust washer
4120008409060 齿轮0425-2020 Planet gear
4120008409061 销0425-4100 Pin
008617753913626 woooyeah1@163.com
4120008409062 行星架0425-4010 Planet carrier
4120008409063 太阳轮0436-0050 Sun gear
4120008409064 垫片0425-0120 Side plate
4120008409065 齿轮架0425-1010 Planet carrier
4120008409066 销0425-1070 Spring pin
008617753913626 woooyeah1@163.com
4120008409067 垫片0425-1040 Side plate
4120008409068 齿轮0425-1020 Planet gear
4120008409069 滚针轴承0425-1060 Needle bearing
4120008409070 销0425-1030 Pin
008617753913626 woooyeah1@163.com
4120008409071 垫片0425-1050 Side plate
4120008409072 挡圈0425-1080 Stop ring
4120008409073 内齿圈0425-0021 Ring gear
4120008409074 太阳轮0425-0040 Sun gear
4120008409075 螺栓0425-0240 Screw
