Description

4019000012 铆钉GB827-3*5-BL2 RIVET
29050040001 分动箱总成 Transfer case
4011000564 螺栓GB5783-M16*45EpZn-10.9 SCREW
4015000098 垫圈GB93-16-65Mn SPRING WASHER
29050014331 连接座 ATTACHMENT BRACKET
008617753913626 SDLG woooyeah1@163.com
4014015000 螺钉GB70.1-M12*110flZnyc-12.9-480 Screw
29050013141 接头体 NIPPLE
4041001264 O形圈LGB168-22331 O-RING
4013000011 螺母GB6170-M12EpZn-8 NUT
4012000036 螺柱GB900-M12*35EpZn-8.8 STUD
29050016261 后法兰总成 CONNECTION FLANGE
4011000092 螺栓GB5783-M12*50EpZn-8.8 BOLT
008617753913626 SDLG woooyeah1@163.com
29050016001 制动盘 DISC BRAKE
29050034441 前输出法兰 Connection flange
4011001243 螺栓GB5783-M12*35flZnyc-8.8-480 SCREW
29050039961 转向泵取力器 Power take-off
29050013721 垫片 GASKET
29050035961 变速阀总成 Gear selector valve
4011000148 螺栓GB16674-M16*40EpZn-8.8 BOLT
4110004481 制动器BL50F-2 Parking break
008617753913626 SDLG woooyeah1@163.com
C0520-2905003997.S 工作泵取力器 Power take-off
29050014861 盖 COVER
4030000056 垫圈JB1002-12-T2 WASHER
4021000156 轴承6014 BEARING
29050014881 齿轮 GEAR
29050039981 取力器壳体 Gear housing
29050014891 轴 SHAFT
29050014841 喷嘴 JET
29050014831 盖塞 CAP PLUG
29050013611 垫片 SHIM
4011000082 螺栓GB5783-M10*25EpZn-8.8 BOLT
4030000807 O形圈GB3452.1-109*3.55G-FPM O-RING
C0520-2904001360.S1A 涡轮组总成 Turbine
008617753913626 SDLG woooyeah1@163.com
4011001208 螺栓GB5783-M12*30flZnyc-10.9-480 SCREW
4015000026 垫圈GB93-12-65Mn SPRING WASHER
4110003463 护板二 Plate
4110003465 输入板总成 Plate
4110003466 输入板体 Plate
4110003464 护板一 Plate
4110003457 涡轮组 Turbine
C0520-2905003994.S 变矩器总成 Torque converter assembly
29050013081 密封垫 GASKET
4011000107 螺栓GB5783-M8*30EpZn-8.8 BOLT
29050015471 垫圈8 WASHER
29050036261 盖板总成 COVER PLATE
008617753913626 SDLG woooyeah1@163.com
29050014501 变矩器润滑系统 LUBRICATING SYSTEM
4016000243 销GB119.2-10*18-B PIN
29050013651 安全阀 SAFETY VALVE
4041000777 螺塞LGB135-02227 PLUG
4041001265 O型圈LGB168-21924 O-RING
4041000775 O形圈LGB168-21124 O-RING
29050014411 螺塞 PLUG
008617753913626 SDLG woooyeah1@163.com
29050039951 变矩器壳体 Converter housing
29050014522 取力器过渡齿轮总成 Gear
4011000763 螺栓GB5783-M10*30EpZn-10.9 BOLT
29050013611 垫片 SHIM
29050013181 密封垫 GASKET
29050013191 端盖 END PLATE
4011000106 螺栓GB5783-M8*25EpZn-8.8 BOLT
008617753913626 SDLG woooyeah1@163.com
4016000224 销GB119.2-20h6*45-B PIN
29050013601 定位销 LOCATING PIN
29050013781 垫片 GASKET
29050013371 销轴 PIN
29050015581 导轮座总成 SEAT
29050014781 盖板 COVER PLATE
29050035931 三通接头 Three-way nipple
29050014191 保护板 GUARD PLATE
4019000025 铆钉GB827-3*10-BL2 RIVET
C0520-2905001450.A1E 变矩器润滑系统 Lubricating system
4030000810 O形圈GB3452.1-11.8*1.80G-FPM O-RING
4030000058 垫圈JB1002-18-T2 WASHER
29050014221 螺栓 SCREW
29050013121 螺栓 SCREW
4030000056 垫圈JB1002-12-T2 WASHER
008617753913626 SDLG woooyeah1@163.com
4040000019 O形圈LGB168-21324 O-RING
29050014201 直接头 NIPPLE
4030000809 O形圈GB3452.1-12.5*1.80G-FPM O-RING
29050012991 螺栓 SCREW
29050013221 管 HOSE ASSEMBLY
29050013621 回油管 TUBE
29050013131 胶管 HOSE ASSEMBLY
29050013151 密封垫 GASKET
008617753913626 SDLG woooyeah1@163.com
29050012981 变矩器润滑阀 LUBRICATING OIL VALVE
29050015471 垫圈8 WASHER
4011000718 螺栓GB5782-M8*60EpZn-8.8 SCREW
29050013771 管 TUBE
4011000717 螺栓GB5782-M8*60-8.8 SCREW
29050018421 销 PIN
29050015461 垫圈6 WASHER
4011000713 螺栓GB5782-M6*40-8.8 SCREW
4041001459 螺塞LGB135-11422 PLUG
4011000715 螺栓GB5783-M8*35-8.8 SCREW
008617753913626 SDLG woooyeah1@163.com
4030000811 O形圈GB3452.1-14.0*1.80G-FPM O-RING
29050013791 管接头 NIPPLE
29050013741 配油器 OIL DISTRIBUTOR
29050013751 管 TUBE
4011000723 螺栓GB5783-M8*20-8.8 BOLT
29050013581 油分流块 CONNECTION BLOCK
4011000966 螺栓GB5782-M6*35-8.8 SCREW
29050014701 螺塞 PLUG
C0565-2905001298.A1B 变矩器润滑阀 Lubricating oil valve
4120002109 测压接头SMK20-M14*1.5-VE-SK JOINT
4041000767 O形圈LGB168-11124 O-RING
008617753913626 SDLG woooyeah1@163.com
4014000058 螺钉GB70.1-M6*20EpZn-8.8 SCREW
4015000207 垫圈GB97.1-6EpZn-300HV WASHER
29050015011 端盖 COVER
29050015451 垫片 SHIM
29050015061 阀杆 VALVE ROD
29050015081 阀体 VALVE HOUSING
29050015071 垫圈 WASHER
29050015041 弹簧 SPRING
29050015001 端盖 COVER
29050015441 垫片 SHIM
29050015031 弹簧 SPRING
29050015051 阀杆 VALVE ROD
29050015021 弹簧 SPRING
29050015331 垫圈 WASHER
29050015341 螺塞 PLUG
C0520-2905002521.S1A 取力器过渡齿轮总成 Gear
008617753913626 SDLG woooyeah1@163.com
29050013404 轴 Shaft
4014000587 螺钉GB70.1-M8*25-10.9 Screw
4015000273 挡圈GB893.2-72-65Mn RETAINING RING
29050013421 限位环 RETAINING RING
4014000344 螺钉GB70.1-M10*30-10.9 SCREW
29050013411 垫片 SHIM
4021000158 轴承NJ207ECP BEARING
29050024341 齿轮 齿轮
008617753913626 SDLG woooyeah1@163.com
C0520-2905001558.A1A 导轮座总成 GUIDE WHEEL SEAT ASSEMBLY
4015000306 挡圈GB894.1-75-65Mn RETAINING RING
29050015551 内圈 SLEEVE
4110000707 轴承K85*92*20 BEARING
29050015571 导轮座 CONVERTER BASE
29050015561 涡轮轴 TURBINE SHAFT
4110000652 滚动轴承6210 BEARING
4015000046 挡圈GB894.1-50-65Mn RETAINING RING
4110000708007 小密封环YB-231/0-03 Sealing ring
4110000708006 大密封环YB-231/0-02 Sealing ring
008617753913626 SDLG woooyeah1@163.com
C0520-2905004154.S 离合器箱总成 Transmission
29050040061 变速箱体 Transmission house
4041001458 O形圈LGB168-22931 O-RING
4041000577 直接头LGB120-03633 NIPPLE
4011000934 螺栓GB5783-M8*12-8.8 SCREW
4015000297 垫圈LGB001-8 WASHER
4030000809 O形圈GB3452.1-12.5*1.80G-FPM O-RING
29050040851 胶管 House assembly
29050013231 离合器KFR CLUTCH
29050025181 中间轴总成 PROPELLER SHAFT
29050013381 离合器K34 CLUTCH
4030000816 O形圈GB3452.1-23.6*3.55G-FPM O-RING
008617753913626 SDLG woooyeah1@163.com
29050014541 后退挡过渡齿轮总成 GEAR
29050040831 F/R胶管总成 House
4030000060 垫圈JB1002-22-T2 WASHER
29050013161 油嘴 NIPPLE
29050041551 离合器K12 Clutch
4011000107 螺栓GB5783-M8*30EpZn-8.8 BOLT
