Description

29080006521 PROPELLER SHAFT 前传动轴
4011000568 BOLT 螺栓GB5786-M12*1.25*40EpZn-10.9
4015000168 WASHER 垫圈GB97.1-12EpZn-300HV
4013000072 LOCK NUT 螺母GB889.2-M12*1.25EpZn-10
29050006531 DRIVE SHAFT 主传动轴
29080001031 SCREW 螺栓
29080008031 WASHER 止动垫圈
008617753913626 SDLG woooyeah1@163.com
29080006531 PROPELLER SHAFT 后传动轴
29050006541 SCREW 螺栓
2908000653001 LINK YOKE 突缘叉130-2201023B
2908000652002 SPIDER 万向节十字轴总成6700-33093
2908000653002 LOCK RING 卡簧2201061N
4110002086003 GREASE CUP 油杯M6 JB/T7940.1-1995
4030000535
2908000652001 INTERMEDIATE HOUSING 传动轴中间支撑
008617753913626 SDLG woooyeah1@163.com
29070010771 Wheel assembly 车轮总成
4110000016 TIRE 轮胎GB2980-16/70-20
4110000016Q
4190000119 RIM 轮辋LY13-20.916.0A
29090009163 Rear axle A513后驱动桥总成
4013000160 LOCK NUT 螺母GB889.2-M20*1.5EpZn-8
4011000848 BOLT 螺栓GB5785-M20*1.5*185EpZn-8.8
008617753913626 SDLG woooyeah1@163.com
4120001827 DISC BRAKE 制动钳-LG918
4120001740 NIPPLE 放气嘴
4011000842 BOLT 螺栓GB5786-M16*1.5*55EpZn-10.9
29070009511 WASHER 垫圈
29070000051 TUBE 透气管
4013000078 NUT 螺母GB6173-M10*1EpZn-05
4016000124 PIN 销GB119.2-10u8*30
29090009171 FINAL DRIVE 后主传动
4011000124 BOLT 螺栓GB5786-M12*1.25*35EpZn-10.9
4015000026 SPRING WASHER 垫圈GB93-12-65Mn
008617753913626 SDLG woooyeah1@163.com
29090009183 Axle casing 后桥壳总成
29070014141 SHAFT HALF 半轴
3050900003 NUT 轮辋螺母
29070014151 HUB REDUCTION 轮边减速器
29070012481 PLUG 磁性螺塞
4019000012 RIVET 铆钉GB827-3*5-BL2
29090009191 NAME PLATE 后桥标牌
4013000042 NUT 螺母GB6171-M24*2EpZn-8
29070010522 Washer 垫圈
29070010051 CONNECTION FLANGE 输入法兰
29070014251 DUST COVER 防尘罩
008617753913626 SDLG woooyeah1@163.com
4011000064 BOLT 螺栓GB5782-M12*50EpZn-8.8
4015000026 SPRING WASHER 垫圈GB93-12-65Mn
4011000048 BOLT 螺栓GB5782-M10*50EpZn-8.8
4015000025 SPRING WASHER 垫圈GB93-10-65Mn
29070014181 SEALING COVER 密封盖
4030000854 SEALING RING 密封圈GB13871.1-FB06008508-F
29070014401 GASKET 密封垫片
29070014201 BEARING BUSHING 轴承套
29070014361 SHIM 调整垫片
29070014371 SHIM 调整垫片
29070014381 SHIM 调整垫片
29070014391 SHIM 调整垫片
008617753913626 SDLG woooyeah1@163.com
4021000132 ROLLER BEARING 滚动轴承GB297-31309
29070010221 SHIM 调整垫片
29070010241
29070010231 SHIM 调整垫片
29070010241
29070010241 SHIM 调整垫片
29070014231 CENTER HOUSING 托架总成
29070014431 CENTER HOUSING 托架
29070009511 WASHER 垫圈
4011000231 SCREW 螺栓GB5782-M16*70EpZn-8.8
008617753913626 SDLG woooyeah1@163.com
29070014441 BEARING SEAT 轴承座
4021000240 ROLLER BEARING 滚动轴承GB297-32210
29070014301 NUT 调整螺母
3050900024 LOCK WASHER 锁紧片
4011000597 BOLT 螺栓GB5786-M10*1*20EpZn-8.8
29070014191 SLEEVE 轴套
4021000239 ROLLER BEARING 滚动轴承GB297-32310
29090009201 CROWN WHEEL 主动螺旋伞齿轮（右）
008617753913626 SDLG woooyeah1@163.com
29070014241 THRUST WASHER 锥齿轮垫片
29070010161 DIFFERENTIAL PINION 锥齿轮
29070010171 SPIDER 十字轴
29090009211 CROWN WHEEL 从动螺旋伞齿轮（左）
29070014271 DIFFERENTIAL SIDE GEAR 半轴齿轮
29070014261 SHIM 半轴齿轮垫片
29070010211 PIN 固定销
29070014281 DIFFERENTIAL HOUSING 差速器左壳
29070015981 WASHER 垫圈
008617753913626 SDLG woooyeah1@163.com
4011000967 SCREW 螺栓GB5786-M12*1.25*25EpZn-8.8
29070014311 DIFFERENTIAL HOUSING 差速器右壳
4011000699 BOLT 螺栓GB5785-M12*1.25*50EpZn-10.9
29070010251 SHIM 调整垫片
-29070010241
29070019561 DIFFERENTIAL SPIDER 差速器总成
21909005161 DIFFERENTIAL HOUSING A513差速器左右壳
21909005151 CROWN WHEEL A513后主从动伞齿轮
008617753913626 SDLG woooyeah1@163.com
21909006481 GEAR KIT 锥齿半齿总成
4011000095 SCREW 螺栓GB5783-M16*35EpZn-8.8
4015000305 RETAINING RING 垫圈GB96.1-16EpZn-300HV
29100025241 Hydraulic fluid tank 液压油箱
29100006621 FILTER INSERT 吸油滤芯
29100006611 FILTER INSERT 回油滤芯（液压油箱回油滤芯）
4030000065 LUBRICATING NIPPLE 油杯JB7940.1-M10*1
4120001088 BREATHER CAP 换气过滤器L1.0807-31
4120000452 FILTER INSERT 加油滤芯SFM-323M
4011000461 BOLT 螺栓GB16674-M8*16EpZn-8.8
4030000209 O-RING O形圈GB3452.1-136*3.55G
008617753913626 SDLG woooyeah1@163.com
29100025261 Flange 回油法兰总成
4011000481 BOLT 螺栓GB16674-M8*30EpZn-8.8
4110000807 LEVEL GAUGE 圆形油标YB-M42*1.5
29100006531 HINGE 合页
29100025251 Hydraulic fluid tank 液压油箱体
29100006541 GUIDE MOULDING 销轴
29100006551 WASHER 垫圈
4015000018 RETAINING RING 挡圈GB894.1-18-65Mn
29100006601 FLANGE 法兰
4030000213 O-RING O形圈GB3452.1-67.0*2.65G
4011000458 BOLT 螺栓GB16674-M8*20EpZn-8.8
008617753913626 SDLG woooyeah1@163.com
29100006561 FLANGE 放油法兰总成
4030000210 O-RING O形圈GB3452.1-165*3.55G
4190000007 MAGNET 环形磁铁LG03-CT70*32*14
4030000211 O-RING O形圈GB3452.1-30.0*2.65G
4041000192 PLUG 螺塞LGB135-03341
29100006581 FLANGE 吸油法兰总成
4030000208 O-RING O形圈GB3452.1-132*3.55G
008617753913626 SDLG woooyeah1@163.com
4040000020 PLUG 螺塞LGB135-01622
4040000019 O-RING O形圈LGB168-21324
4041000508 PLUG 螺塞LGB135-01824
4041000768 O-RING O形圈LGB168-11524
