Description

4120002148001 HANDLE BALL 动臂手球LGC9530001
4120002148002 HANDLE BALL 铲斗手球LGC9530002
4120002148003 NUT M12螺母RM-007
4120003865001 Control lever 动臂杆焊合件 LGC953N0001
4120003865002 Control lever 铲斗杆焊合件 LGC953N0002
4120002046001 RUBBER SLEEVE 防尘套LGC9530005
4120002046002 RUBBER MAT 防尘套垫LGC9530006
4120005364001 SCREW 螺栓M6-12 LGC9530014
4120003865003 Control lever 操纵支架焊合件 LGC953N0003
4120002148007 BUSHING 中间轴套LGC9530013
008617753913626 SDLG woooyeah1@163.com
4120002148008 LOCK RING 内卡簧KH-002
4120002148009 BEARING 6003轴承ZC-002
4120002148010 NUT M16薄螺母LGC9530011
4120002148011 BUSHING 轴套LGC9530010
4120002148012 SEAT 轴座LGC9530008
4110000172029 SCREW M8×1.25-30螺栓LGH9530009
4110002042020 WASHER 弹垫Φ8 TD-002
4110002042019 WASHER 平垫Φ8 PD-002
4120002148013 NUT M8螺母RM-001
4120002148014 SHAFT 轴LGC9530012
4120002148015 SCREW M6-20螺栓LGC9530009
4120002148016 NUT M6螺母RM-002
4120006628 BOOM CYLINDER 动臂油缸HSGF-165*90*805-1355
29130025921 Pipe 左小腔钢管总成
4030000026 O-RING O形圈GB3452.1-32.5*3.55G
4011001298 SCREW 螺栓GB16674.1-M10*55flZnyc-8.8-480
4011001288 SCREW 螺栓GB16674.1-M10*50flZnyc-8.8-480
4011001300 SCREW 螺栓GB16674.1-M10*30flZnyc-8.8-480
008617753913626 SDLG woooyeah1@163.com
29130008152 PIPE 举升下降钢管
4030000029 O-RING O形圈GB3452.1-37.5*3.55G
4041000878
29130011991 BRACKET 左支架
4011001299 SCREW 螺栓GB16674.1-M10*25flZnyc-8.8-480
4041000043 FLANGE HALF 分体法兰LGB117-310490
4041002661 Hose assembly 软管LGB107-010130
29130021091 PIPE 左大腔钢管总成
29130021131 PIPE 右大腔钢管总成
29130008201 PIPE 动臂联小腔右钢管
29130008181 PIPE 动臂联大腔右钢管
29130025911 Pipe 右小腔钢管总成
29130012011 BRACKET 右支架
4041001017 U-BOLT U形螺栓LGB159-13040
4013000370 NUT 螺母GB6170-M10flZnyc-8-480
4015000433 WASHER 垫圈GB97.1-10flZnyc-300HV-480
008617753913626 SDLG woooyeah1@163.com
29130008221 PIPE 动臂联大腔左钢管
29130021191 PLATE 固定板
4011001248 SCREW 螺栓GB5783-M10*25flZnyc-8.8-480
4041001018 BRACKET 底板LGB160-3040
29130021971 Clamp 管夹
29130022411 Clamp 管夹
4011001249 SCREW 螺栓GB5783-M10*30flZnyc-8.8-480
29130008241 PIPE 动臂联小腔左钢管
4013000373 NUT 螺母GB6170-M8flZnyc-8-480
4015000430 WASHER 垫圈GB97.1-8flZnyc-300HV-480
4011001296 SCREW 螺栓GB16674.1-M8*20flZnyc-8.8-480
29130010371 CLAMP 管夹
4041000869 RUBBER SLEEVE 缓冲套LGB123-0740
4120006628001 cylinder tube 缸筒总成24A138740
4120006628002 piston rod 活塞杆总成24A113870
4120006628003 cover 缸盖24C101130
4120005980010 BUSHING 衬套24S290501
008617753913626 SDLG woooyeah1@163.com
4120005980008 RETAINING RING 钢丝挡圈-孔用24C090220
4120006628004 SEALING RING KIT 密封件包
4120006628004 SEALING RING KIT 密封件包
4120006628004 SEALING RING KIT 密封件包
4120006628004 SEALING RING KIT 密封件包
4120005980009 RETAINING RING 钢丝挡圈-孔用24C090240
4120006628004 SEALING RING KIT 密封件包
4120006628004 SEALING RING KIT 密封件包
4120006628004 SEALING RING KIT 密封件包
4120006628005 Piston 活塞24C102090
4120006628004 SEALING RING KIT 密封件包
4120006628004 SEALING RING KIT 密封件包
4120006628004 SEALING RING KIT 密封件包
4120006628004 SEALING RING KIT 密封件包
4120005980011 NUT 活塞背母24C103050
4090000168 BALL 钢球GB308-5-GCr6
4120005685008 SCREW 螺钉-内六角凹端紧定24T908161 M8*16L
4120006628006 BUSHING 轴套24C116150
4120006628004 SEALING RING KIT 密封件包
4120006628007 SCREW 螺钉-内六角圆柱头24T516805
4120005685012 ANCHORAGE 固定座24C003020 M16
29140020431 Plate 放平护板
008617753913626 SDLG woooyeah1@163.com
4011001248 SCREW 螺栓GB5783-M10*25flZnyc-8.8-480
4015000426 WASHER 垫圈GB96.1-10flZnyc-300HV-480
4120007577 Tilt cylinder 转斗油缸HSGF-190*90*548-1043
4011001249 SCREW 螺栓GB5783-M10*30flZnyc-8.8-480
4041000144 FLANGE HALF 分体法兰LGB117-312552
4030000029 O-RING O形圈GB3452.1-37.5*3.55G
-4041000878
4011001510 SCREW 螺栓GB16674.1-M12*35flZnyc-8.8-480
4041000774 PLUG 螺塞LGB135-01422
4041000767 O-RING O形圈LGB168-11124
29140018531 PIPE 转斗缸大腔钢管
008617753913626 SDLG woooyeah1@163.com
4011001529 Screw 螺栓GB16674.1-M12*55flZnyc-8.8-480
4011001559 Screw 螺栓GB16674.1-M12*50flZnyc-8.8-480
29140015431 CLAMP 管夹
4041000056 FLANGE HALF 分体法兰LGB117-312550
4011001300 SCREW 螺栓GB16674.1-M10*30flZnyc-8.8-480
29140019171 PIPE 转斗联右小腔钢管
29140014801 COVER PLATE 前盖板
4011001280 SCREW 螺栓GB5783-M10*40flZnyc-8.8-480
4043002603 Attaching sleeve 防松套LGB331-10*20*16flZnyc-45
4041000178 HOSE ASSEMBLY 软管LGB106-012138
4041001794 HOSE ASSEMBLY 软管LGB106-012135
29140019161 PIPE 转斗联左大腔钢管
4120007577001 Cylinder tube 缸筒总成24A141200
4120007577002 Piston rod 活塞杆总成24A115200
4120005980003 cover 缸盖24C101270
4120005980010 BUSHING 衬套24S290501
008617753913626 SDLG woooyeah1@163.com
4120005980008 RETAINING RING 钢丝挡圈-孔用24C090220
4120005999004 Sealing ring 密封件-缓冲24H009004
4120005999005 Sealing ring 密封件-活塞杆24F209003
4120005999006 Retaining ring 挡圈-U形圈24E009025
4120005999007 Sealing ring 密封件-防尘24D209001
4120005980009 RETAINING RING 钢丝挡圈-孔用24C090240
4120007577003 O-ring O形圈24K11800A
4120007577004 O-ring 挡圈-O形圈24M11900D
4120007577005 O-ring O形圈24K318521
4120005980005 Piston 活塞24C102210
4120007577006 Piston 密封件-活塞24P219002
4120005999013 O-ring O形圈24K10900A
4120005999014 O-ring 挡圈-O形圈24M30950A
4120007577007 Sealing ring 支承环24G219021
4120005980011 NUT 活塞背母24C103050
4090000168 BALL 钢球GB308-5-GCr6
008617753913626 SDLG woooyeah1@163.com
4120005685008 SCREW 螺钉-内六角凹端紧定24T908161 M8*16L
4120005980012 BUSHING 轴套24C116170
4120006998003 Sealing ring 销边防尘24R309520
4120005980007 BUSHING 轴套24C117170
4120006560024 Screw 螺钉-内六角圆柱头24T520805
4120005801013 GREASE CUP 油杯24V2100A1 M10x1
4030000065
4120007577008 Sealing kit 密封件维修包24A103940S
