Description

轴承6211 800511443 GB/T276-1982 Bearing
螺母 M10×1 805200090 GB/T6171-2000 NUT
垫圈 10 805300014 GB/T93-1987 Washer
中间输入轴 ▲272200288-04 Medium Input Shaft
球轴承6010 800511300 GB／T276-1994 Ball Bearing
隔离套 ▲272200288-05 Space Bushing
内环凸轮 ▲272200288-06 Inner Ring Cam
盖板 ▲272200288-07 Plate
隔离环 ▲272200288-08 Bearing Cage
螺栓 ▲272200288-09 Bolt
008617753913626 XCMG woooyeah1@163.com
挡圈 80 805400061 GB893.1-86 Anti-extrusion Ring
外环齿轮 ▲272200288-10 Outer Ring Gear
球轴承6210(50X90X20) 800500185 GB／T276-94 Ball Bearing
隔离垫圈 ▲272200288-11 Washer
弹簧座 ▲272200270-01 Spring Cover
弹簧 ▲272200270-02 Spring
滚柱Φ15X32 ▲272200270-03 Cylinder Roller
轴承6211 800511443 GB/T276-1982 Bearing
螺母 M10×1 805200090 GB/T6171-2000 NUT
垫圈10 805300062 GB859-87 Lock Washer
中间输入轴 272200271 Medium Input Shaft
轴承6010E 800511274 GB／T276-94 Bearing
隔离套 ▲272200270-04 Space Bushing
滚柱左挡圈 ▲272200270-05 Left End Cover
内环凸轮 ▲272200270-06 Inner Ring Cam
滚柱右挡圈 ▲272200270-07 Right End Cover
挡圈 80 805400061 GB893.1-86 Anti-extrusion Ring
螺栓 ▲272200270-08 Bolt
外环齿轮 272200274 Outer Ring Gear
球轴承6210(50X90X20) 800500185 GB／T276-94 Ball Bearing
隔离环 ▲272200270-09 Bearing Cage
隔套 ▲272200270-10 Space Bushing
螺母 M12 805200049 GB/T6170-2000 Nut
008617753913626 XCMG woooyeah1@163.com
双头螺栓AMl2X35 ▲803004322-01 GB897-74 Stud
骨架油封PG45x62x12 ▲803004322-02 B2600-80 Skeleton Oil Seal
骨架油封PG45x62x12 4818007 B2600-80 Skeleton Oil Seal
泵体（止口Φ127） ▲803004322-03 Valve Body
泵体（止口Φ127） 403601 Valve Body
垫圈 402106 Washer
垫圈 ▲803004322-04 Washer
管接头 ▲803004322-05 Joint
管接头 402111 Joint
轴 403603 Shaft
轴 ▲803004322-06 Shaft
隔离套 ▲803004322-07 Spacer
隔离套 403611 Spacer
滚针φ4X30 ▲803004322-08 GB309-84 Needle Roller
小齿轮 ▲803004322-09 Driving Gear
小齿轮 403602 Driving Gear
密封垫 403606 Seal Gasket
密封垫 ▲803004322-10 Seal Gasket
泵盖 ▲803004322-11 Pump Cover
泵盖 403608 Pump Cover
密封垫 403609 Seal Gasket
密封垫 ▲803004322-12 Seal Gasket
挡圈 ▲803004322-13 GB893.1-86 Snap Ring
挡环 ▲803004322-14 Snap Ring
挡环 403604 Snap Ring
螺栓M10×75 805000876 GB/T5782-2000 Bolt
垫圈 10 805300014 GB/T93-1987 Washer
螺栓 M10×55 805000100 GB/T 5782-2000 Bolt
销A10X30 860102487 GB119-86 Pin
大齿轮 403605 Driven Gear
大齿轮 ▲803004322-15 Driven Gear
轮边减速器总成 275101951 Planetary Reductor Assembly
盘式制动器总成 275101705 Brake Assembly
制动盘 275101789 Brake Plate
主减速器总成 275101678 Main Reductor Assy(Front Axle)
前桥桥壳总成 275101792 Front Axle Housing Assy
防尘罩 275101791 Top cover of brake
008617753913626 XCMG woooyeah1@163.com
轮边减速器总成 275101695 Planetary Reductor Assy
主减速器总成 Main Reductor Assy(Rear Axle)
端盖 275100137 bracket
限位块 275100123 Limiting Block
轮辋螺母 250300296 Nut
轮辋螺栓 275101677 Bolt
太阳轮 275100138 Sun Gear
隔套 275100113 Sleeve
螺栓 275100264 Bolt
螺母 275100262 Nut
内齿圈总成 275101952 Inner Gear Assy
内齿圈总成 275100310 Inner Gear Assy
挡板 275100141 Washer
行星轮 275100142 Planet Gear
滚针 275100139 Roller
隔套 269900210 Snap Ring
行星轮轴 275100122 Gear Shaft
行星轮架 275101676 Planetary Pinion Carrier
弹性挡圈 50 805400027 GB/T894.1-2000 805400027
调整支柱 275100125 t=23 Adjust Pole
调整支柱 275100126 t=24 Adjust Pole
调整支柱 275100196 t=25 Adjust Pole
半轴 275100111 Axle Shaft
密封圈 275100116 Ring
轴承32028 226800185 GB/T297-94 Bearing
轴承32026 800511283 GB/T297-94 Bearing
轮毂 275101954 Wheel Hob
轴承32024 800511281 GB/T297-94 Bearing
隔套 275100265 Sleeve
挡油板 250301676 Plate
密封圈 CR HMSA10 FB150×180×15 803164086 Oil Seal
密封圈 CR HMS5 B150×180×15 803164085 Oil Seal
008617753913626 XCMG woooyeah1@163.com
锁紧螺母 275100187 Nut
垫圈 275100174 Washer
连接法兰组件 275100257 Flange
连接法兰组件 275100258 Flange
密封圈 CR HMSA10 FB80X100X10 803164330 Oil Seal
密封圈 CR HMS5 B80X100X10 803164331 Oil Seal
密封盖 250300322 Cover
轴承 31313 800511282 GB/T297-1994 Bearing
轴承套 275100175 Sleeve
调整垫片 250300352 Cushion
轴承调整隔套组 275100182 T=20.1 Sleeve
轴承调整隔套组 275100184 T=20.4 Sleeve
轴承调整隔套组 275100185 T=20.7 Sleeve
轴承调整隔套组 275100186 T=21 Sleeve
轴承 31314 800511279 GB/T 297-94 Bearing
主动螺旋齿轮（左旋） 275100167 Gear
从动螺旋齿轮（右旋） 275101683 Gear
轴承 47686/47620A 800511379 英制轴承 Bearing
差速器左壳 275100161 Cover
半轴齿轮 275100157 Gear
半轴齿轮垫片 275100154 Cushion
半轴齿轮垫片 275100155 Cushion
半轴齿轮垫片 275100156 Cushion
十字轴 275101723 Axis
锥齿轮 275100153 Gear
锥齿轮垫片 275100150 Cushion
锥齿轮垫片 275100151 Cushion
锥齿轮垫片 275100152 Cushion
差速器右壳 275101684 Cover
托架 275101680 Bracket
止推螺栓 275100164 Bolt
锁紧片 275100181 Cushion
螺母M27X2 805200156 GB/T6173-2000 Nut
调整垫片 250300353 Cushion
主减速器盖 275101681 Bracket
锁紧片 275100178 Cushion
螺栓 M10×1×20 805002186 GB/T32.1-1988 Bolt
调整螺母 275101682 Nut
142807Y轴承组件 275101955 英制轴承 Bearing
008617753913626 XCMG woooyeah1@163.com
放气咀 275101705-1 JC-A-4050-04 Exhaust Nipple
活塞 275101705-5 JC-A-4050-09 Piston
卡圈 275101705-8 JC-A-4050-11 Clip
制动片 275101705-9 JC-A-4050-06 Brake Pad
螺栓销 275101705-11 JC-A-4050-12 Bolt Pin
直销 275101705-12 Pin
放气咀座 275101705-13 JC-A-4050-05 Seat
橡皮帽 275101705-14 JC-A-4050-03 Rubber Cap
螺栓M22 275101705-15 JC-A-4050-10 Bolt
PLIER KIT PISTON REPAIR KIT
轮边减速器总成 275101695 Planetary Reductor Assy
盘式制动器总成 275101705 Brake Assembly
制动盘 275101789 Brake Plate
主减速器总成 275101687 Main Reductor Assy(Rear Axle)
后桥桥壳总成 275101795 Rear Axle Housing Assy
轮辋体 250400167 Rim Base
锁圈 250400164 Lock Ring
外轮缘 250400165 Side Ring
前罩板 252101728 FRONT COVER
右挡泥板 253000638 Right Splash Fender
右前灯支架 803546484 Right Lamp Bracket
前车架 252111524 Front Chassis
前车架 252111647 Front Chassis
前车架 252112275 Front Chassis
前车架 252111675 Front Chassis
调整垫片 269900194 ADJUSTING SHIM
动臂-车架销 252904920 Pin
动臂-车架销 252900386 central lubrication Pin
调整垫片 269900193 GB/T16674.1-2004 ADJUSTING CUSHION
008617753913626 XCMG woooyeah1@163.com
翻斗缸-车架销 252900387 SHAFT PIN
左前灯支架 803546483 Left Lamp Bracket
下销上法兰 252100482 UPPER FLANGE
下销下法兰 252100483 LOWER FLANGE
