Description

7200001539 THRUST WASHER 止推垫圈0730150759
7200001623 THRUST WASHER 止推垫圈4644303534
7200001624 GEAR 齿轮 Z=29(HVZ)4644308587
7200001626 THRUST WASHER 止推垫圈0730150777
7200001625 NEEDLE BEARING 滚针轴承0735358069
7200001627 WASHER 端垫4642308185
7200001628 CYLINDER PISTON 活塞4644353062
7200001629 SEALING RING 贴面密封圈0501.338.224:000
7200001549 THRUST WASHER 止推垫圈4644351094
7200001550 THRUST WASHER 止推垫圈4642308555
7200001551 SEALING RING 密封环0750112140
4110000076251 TENSION SPRING 压力弹簧0732041183
7200001553 GUIDE RING 导向环4642308083
7200001554 LOCK RING V形杯AV550630531346
7200001555 GUIDE RING 导向环4642308084
008617753913626 SDLG woooyeah1@163.com
7200001637 NEEDLE BEARING 滚针轴承0750115182
7200001557 RETAINING RING 挡圈0730513610
7200001639 NEEDLE BEARING 滚针轴承0635303204
7200001559 RETAINING RING 挡圈0730513611
7200001641 RETAINING RING 挡圈0730513420 A=2.25
4110000042019 RETAINING RING 挡圈A= 2.30 0730 513 419
4110000042021 RETAINING RING 挡圈A= 2.35 0730 513 418
4110000042022 RETAINING RING 挡圈A= 2.40 0730 513 417
4110000042024 RETAINING RING 挡圈A= 2.45 0730 513 416
4110001742016 TRIM WASHER 调整垫圈 0730 513 180,416-421,455,456
4110000042017 RETAINING RING 挡圈A= 2.20 0730 513 421
4110000042016 RETAINING RING 挡圈A= 2.15 0730 513 455
4110000042014 RETAINING RING 挡圈A= 2.10 0730 513 456
7200001561 THRUST WASHER 止推垫圈0730150779
7200001643 WASHER 垫圈0730109643
4110000042012 GEAR 齿轮4644 308 630
7200001646 SEALING RING 滚针轴承贴面密封圈组件0750115109
4110002230077
7200001647 ROLLER 滚柱0735.470.272
008617753913626 SDLG woooyeah1@163.com
7200001648 SUPPORT 摩擦片支承4644253045
7200001649 FRICTION DISC 外摩擦片0501332095
7200001650 FRICTION DISC 内摩擦片4642308330
7200001651 FRICTION DISC 内摩擦片4642308332
7200001652 FRICTION DISC 内摩擦片4642308331
7200001499 OUTPUT SHAFT 输出轴4633303216
7200002248 GEAR 输出齿轮4644303279
7200001501 BEARING 滚柱轴承0635416285
7200001503 WASHER 垫圈4620303247
7200001504 SCREW 六角螺钉(M10*30)0636015127
7200001505 THRUST WASHER 止动垫圈1269302164
7200001506 SEALING RING 轴密封0750 319 445
7200001507 BALL BEARING 球轴承0750116134
7200001508 LOCK RING 卡环(120*4)0630502048
008617753913626 SDLG woooyeah1@163.com
7200001509 SHIM 调整垫圈0730002654
4110000042086 SHIM 调整垫圈s=1.5 0730 002 657
4110000042088 SHIM 调整垫圈s=1.6 0730 002 656
4110000042089 SHIM 调整垫圈s=1.7 0730 002 655
4110000042064 SHIM 调整垫圈s=0.2 1204 308 014
4110000042065 SHIM 调整垫圈s=0.3 1204 308 061
7200001502 SHIM 调整垫圈1204308062
4110000042074 SHIM 调整垫圈s=1.1 0730 002 661
4110000042080 SHIM 调整垫圈s=1.3 0730 002 659
4110000042077 SHIM 调整垫圈s=1.2 0730 002 660
4110000042083 SHIM 调整垫圈s=1.4 0730 002 658
4110000042071 SHIM 调整垫圈s=1.0 1204 308 123
4110000042076 SHIM 调整垫圈s=1.15 0730 007 638
4110000042085 SHIM 调整垫圈s=1.45 0730 006 164
4110000042087 SHIM 调整垫圈s=1.55 0730 006 165
4110000042073 SHIM 调整垫圈s=1.05 0730 007 637
4110000042079 SHIM 调整垫圈s=1.25 0730 007 639
4110000042082 SHIM 调整垫圈s=1.35 0730 007 640
7200001510 TUBE 管0730062296
4110002230050 FLANGE 输出法兰4644 303 547
7200001512 SCREW 六角螺钉0736020031
7200001513 WASHER 定距垫圈4644303500 A=0.6
4110000042097 SPACER RING 间隔垫圈A=1.1 4644 303 501
7200001514 O-RING O形圈0634303466
7200002198 BRAKE SYSTEM 制动器0501003819
7200002199 BRAKE SYSTEM 制动器4644309002
008617753913626 SDLG woooyeah1@163.com
4110000042128 CONNECTION FLANGE 前输出法兰4657309004
7200002200 SCREW 六角螺钉(M14*1.5*45)0636020082
7200002201 SCREW 六角螺钉(M10*25)0636015166
7200002202 WASHER 垫圈(10.5)0630001014
7200002203 ANCHOR PLATE 固定盘4644309008
7200002204 WASHER 垫圈4644309066
7200002205 WASHER 垫圈0730107676
7200002206 SCREW 六角螺钉(M10*40)0636010159
7200002207 SCREW 六角螺钉(M10*22)0636015115
7200002208 O-RING O型圈(17.3*2.4)0634306017
7200002209 O-RING O型圈(25.3*24)0634306024
7200002210 BRAKE SHOE 制动蹄片0501 224 618
7200002211 SPRING 拉伸弹簧0501300460
7200002212 SCREW 螺栓0501.338.824
7200002213 SCREW 螺栓0501.338.826
7200002214 WASHER 垫圈0501300407
008617753913626 SDLG woooyeah1@163.com
7200002215 LOCK RING 卡环(22*1.2)0630501018
7200002217 BRAKE CAM 制动凸轮0501 338 829
7200002216 O-RING O型圈(22*0634306213
7200001668 SHAFT 取力器轴Z=384644311196
7200001669 BALL BEARING 球轴承0750116259
7200001670 RETAINING RING 挡圈(SP85)0630503011
7200001671 LOCK RING 卡环(45*1.75)0630501033
7200001672 SEALING RING 密封圈4644311214
4110000042108 SCREW 六角头螺钉0636 015 077
7200001674 STUD 螺柱0636610014
7200001675 NUT 六角螺母(M8)0637006018
7200001676 HOUSING 取力器壳4644311120
7200001677 GEAR 主动齿轮4644311117
008617753913626 SDLG woooyeah1@163.com
7200001678 RETAINING RING 挡圈(SW47)0630513068
7200001679 NEEDLE BEARING 滚针轴承0635303104
7200001680 RETAINING RING 挡圈(SB52)0630513016
7200001668 SHAFT 取力器轴Z=384644311196
7200001682 GEAR 主动齿轮(Z=74)4644311118
7200001678 RETAINING RING 挡圈(SW47)0630513068
7200001679 NEEDLE BEARING 滚针轴承0635303104
7200001680 RETAINING RING 挡圈(SB52)0630513016
008617753913626 SDLG woooyeah1@163.com
7200001669 BALL BEARING 球轴承0750116259
7200001670 RETAINING RING 挡圈(SP85)0630503011
7200001671 LOCK RING 卡环(45*1.75)0630501033
7200001684 COVER 盖4644311121
7200001685 SEALING RING 密封圈4644311209
7200001686 SCREW 六角螺钉(M8*16)0636 100 622
7200001687 TUBE 软管0750147048
7200001688 NOZZLE 喷管4642211001
7200001689 SCREW 空心螺钉(10)0637835515
7200001690 SEALING RING 密封圈(A14*20)0634801151
7200001692 GASKET 密封4644306362
7200001693 COVER PLATE 盖板4644306363
7200001694 GASKET 密封4644306364
7200001695 OIL DISTRIBUTOR PLATE 油道板4644306365
008617753913626 SDLG woooyeah1@163.com
4110000042119 SCREW 圆柱头螺钉0636 102 173
7200001697 WASHER 垫圈(8.4)0630003006
7200001698 GASKET 密封4644306497
7200001699 COVER PLATE 盖板4644306508
4110000042110 GASKET 密封垫4644 306 370
4110000042123 SCREW 圆柱头螺钉0736 101 205
4110000042121 SCREW 圆柱头螺钉0736 101 203
4110000042122 SCREW 圆柱头螺钉0736 101 204
7200001750 PLUG 螺塞(M10*1)0636302053
