Description

29340028401 HAND RAIL 护栏
4011000090 BOLT 螺栓GB5783-M12*35EpZn-8.8
4013000011 NUT 螺母GB6170-M12EpZn-8
29340013741 BRACKET 右支架
4011000197 BOLT 螺栓GB5783-M12*25EpZn-8.8
29340025381 HAND RAIL 右前扶手
4015000186 WASHER 垫圈GB96.1-12EpZn-300HV
29340028411 PLATFORM 右台板
4011000082 BOLT 螺栓GB5783-M10*25EpZn-8.8
4015000197 WASHER 垫圈GB96.1-10EpZn-300HV
008617753913626 XCMG woooyeah1@163.com
29340017781 ANCHOR PLATE 压板
29340000651 MUDFLAP 橡胶板
29340028881 LADDER 右梯
4013000007 NUT 螺母GB6170-M10EpZn-8
29340000571 FOOT STEP 软梯
29340028421 FENDER 右挡泥瓦
29340000571 FOOT STEP 软梯
4011000082 BOLT 螺栓GB5783-M10*25EpZn-8.8
4015000197 WASHER 垫圈GB96.1-10EpZn-300HV
29340000651 MUDFLAP 橡胶板
29340025191 HAND RAIL 护栏
29340015291 HAND RAIL 左前扶手
29340029951 BRACKET 左支架
4013000011 NUT 螺母GB6170-M12EpZn-8
008617753913626 XCMG woooyeah1@163.com
4015000168 WASHER 垫圈GB97.1-12EpZn-300HV
4011000090 BOLT 螺栓GB5783-M12*35EpZn-8.8
29340029941 PLATFORM 左台架
29340017781 ANCHOR PLATE 压板
4011000197 BOLT 螺栓GB5783-M12*25EpZn-8.8
4015000186 WASHER 垫圈GB96.1-12EpZn-300HV
29340025251 LADDER 左梯
4013000007 NUT 螺母GB6170-M10EpZn-8
29280000051 RUBBER CUSHION 侧胶板
-4043001989
29280000061 RUBBER CUSHION 下胶板
29280000071 BOLT 锁紧螺杆
29280000081 BRACKET 锁紧角钢
008617753913626 XCMG woooyeah1@163.com
4013000033 NUT 螺母GB6170-M8EpZn-8
4015000036 SPRING WASHER 垫圈GB93-8-65Mn
4015000072 WASHER 垫圈GB97.1-8EpZn-300HV
29340000691 ANCHOR PLATE 压板
29340000701 FOOT STEP 踏板
4019000008 RIVET 铆钉GB875-6*20-BL2
29340000711 BELT 皮带
4011000107 BOLT 螺栓GB5783-M8*30EpZn-8.8
4015000256 WASHER 垫圈GB96.1-8EpZn-300HV
4013000033 NUT 螺母GB6170-M8EpZn-8
29340000721 BRACKET 连接板
29340002431 LAMP BRACKET 灯架
29340002442 BRACKET 后板
008617753913626 XCMG woooyeah1@163.com
4015000256 WASHER 垫圈GB96.1-8EpZn-300HV
4011000105 BOLT 螺栓GB5783-M8*20EpZn-8.8
29350012951 Air conditioning system 空调系统
4011000461 BOLT 螺栓GB16674-M8*16EpZn-8.8
4130000075 SCREW 螺栓GB16674-M6*12EpZn-8.8
26350003331 ADJUSTING BAR 调整螺杆
4013000016 NUT 螺母GB6170-M16EpZn-8
4011000084 BOLT 螺栓GB5783-M10*30EpZn-8.8
4015000162 WASHER 垫圈GB97.1-10EpZn-300HV
29350009031 CHASSIS GROUND CABLE 压缩机接地线
4011000514 BOLT 螺栓GB5783-M10*45EpZn-8.8
4013000007 NUT 螺母GB6170-M10EpZn-8
4110000885 BELT 压缩机皮带A17-490
4011000447 BOLT 螺栓GB16674-M10*20EpZn-8.8
29350007922 BRACKET 固定板
4011000311 SCREW 螺栓GB5782-M10*135EpZn-8.8
008617753913626 XCMG woooyeah1@163.com
29350009731 BLOCK 固定块
29350009912 BRACKET 支架
4011000090 BOLT 螺栓GB5783-M12*35EpZn-8.8
4015000168 WASHER 垫圈GB97.1-12EpZn-300HV
4190003273 EVAPORATOR 蒸发器总成（加滤网）
4130000418 THERMOSTAT ZG30.11XG-09温控器
4130000418A)
4130000418R)
4014000068 SCREW 螺钉GB845-ST4.2*13-C-H
4120001516 PIPE 管路：蒸发器-压缩机3000
4190000810 MOULDING 储液器卡子
4011000286 SCREW 螺栓GB5783-M6*35EpZn-8.8
4015000207 WASHER 垫圈GB97.1-6EpZn-300HV
008617753913626 XCMG woooyeah1@163.com
4013000358 NUT 螺母GB6187.1-M6EpZn-8
4130000419 RESERVOIR ZG30.06XG储液罐
4130000419R)
4130000419A)
4130002212 COMPRESSOR 压缩机
4130000658 WIRING HARNESS 空调线束LG956
4120001513 PIPE 管路：压缩机-冷凝器3000
4120001514 PIPE 管路：冷凝器-储液罐2300
4120001515 PIPE 管路：储液罐-蒸发器2300
4130000457 CONDENSER ZG30L14.05冷凝器总成
4130000457R)
4130000457A)
4190003273001 DRAIN PIPE 放水管T2005
008617753913626 XCMG woooyeah1@163.com
4190003273002 CLOSURE 下壳组件GKZ33-5.0F8-10
4190003273003 COVER 上盖组件GKZ33-5.0F8-20
4190003429 AIR VENT COCK 上出风口GKZ33-5.0F8-01
4190003436 FILTER 回风滤纸GKZ33-5.0F8-80
4130000633006 ANCHOR PLATE 风机固定板GKZ33-5.0F-50
4190003273004 Plate 侧盖板组件GKZ33-5.0F8-30
4190003430 AIR VENT COCK 下出风口GKZ33-5.0F8-03
4190003431 EVAPORATOR 制冷器GKZ33-5.0F8-50
4130000415002 TEMPERATURE SENSOR 感温探头TB6502
4190003273005 Clamp 塑料夹MKZ9-3.0-09
4190003435 HEATER 制热器GKZ33-5.0F8-60
008617753913626 XCMG woooyeah1@163.com
4130002346 WIRING HARNESS 蒸发器线束GKZ33-5.0F8-70
4130000633005 FAN 蒸发风机TB5101
4190003273006 Clamp 塑料卡21210050
4190003532 TEMPERATURE SENSOR 温度传感器13700014
4190003531 Cable harness 蒸发器线束27110079
4190003436 FILTER 回风滤纸GKZ33-5.0F8-80
4190003526 Heat exchanger core 蒸发器芯体组件23210087
4190003273007 Closure 上盖组件23310232
4190003530 Heat exchanger core 水芯组件23210088
4190003273009 Closure 壳体组件23310231
4190003273008 Plate 侧盖板组件23310233
4130000633113 FAN 蒸发风机6DT10-611
4190003273010 Plate 风机底板组件23310250
4130000457001 FAN 冷凝风机GKL33-5.0-60
008617753913626 XCMG woooyeah1@163.com
4130000457004 GROUND CABLE 接地线GK33-5.0-90
4130000457005 HOUSING 冷凝器下壳体GKL33-5.0-40
4130000457006 PLATE 固定板GKL33-5.0-50
4130000457002 CONDENSER 冷凝器芯GK19-5.0-50-50
4130002211003 Anchor plate 固定圆板T0032-1
4130000457008 ANCHOR PLATE 固定圆板1T0033-1
29360019341 DECAL SET 工作装置标识包
29360015121 NAME PLATE 万能铭牌
4019000072 RIVET 铆钉GB12618.1-4*10-10
008617753913626 XCMG woooyeah1@163.com
29360019591 DECAL SET 前车架标识包
29360019371 DECAL SET 后车架标识包
29360019281 DECAL SET 附件标识包
29360015191 EMBLEM 后标志
29360019401 DECAL SET 发动机罩标识包
29360020361 DECAL SET 操纵箱标识包
29360019531 DECAL SET 驾驶室标识包
