Description

29230011581 Plate 板
4011001268 SCREW 螺栓GB5783-M10*16flZnyc-8.8-480
4015000433 WASHER 垫圈GB97.1-10flZnyc-300HV-480
29240047604 Front frame 前车架JF975
4043004943 Pin 销轴LGB301-110*200N*370-1000G
4011001261 SCREW 螺栓GB5783-M16*30flZnyc-8.8-480
4040000051 WASHER 垫圈LGB001-16flZnyc-480
008617753913626 SDLG woooyeah1@163.com
4011001296 SCREW 螺栓GB16674.1-M8*20flZnyc-8.8-480
29250013741 Plate 压板
4011001613 Screw 螺栓GB5783-M12*50flZnyc-8.8-480
4015000427 WASHER 垫圈GB96.1-12flZnyc-300HV-480
29250001361 RUBBER SLEEVE 走线胶套
29250024842 Lubricating pipe 油管
29250024862 Lubricating pipe 油管
29250015281 Lubricating pipe 左下动臂润滑油管
29250014121 NIPPLE 接头
4030000065 LUBRICATING NIPPLE 油杯JB7940.1-M10*1
4043004944 Pin 销轴LGB301-95*200N*370-1000G
4011001280 SCREW 螺栓GB5783-M10*40flZnyc-8.8-480
4015000426 WASHER 垫圈GB96.1-10flZnyc-300HV-480
4011001248 SCREW 螺栓GB5783-M10*25flZnyc-8.8-480
008617753913626 SDLG woooyeah1@163.com
29250026541 1 压板
29250026471 Plate 橡胶板
29280010021 TENSIONING HOOK 挂钩
29250024231 Pin 锁定销轴
29250009131 TRANSPORT LOCK 锁定杆
29250024241 Pin 锁定销轴
29270000081 LOCK RING 卡环
29250026411 Front fender 右挡泥瓦
29250016811 Protecting plate 灯架护板
29250011021 PROTECTING PLATE 照灯网板
29250025523 Lamp bracket 右灯架
29250015231 PIPE 右上动臂润滑油管
4043000043 SHIM 垫片LGB303-110*180*1
29250015251 PIPE 上转斗缸润滑油管
4043000353 SHIM 垫片LGB303-100*180*1
008617753913626 SDLG woooyeah1@163.com
29250001351 RUBBER SLEEVE 走线胶套
29250015201 PIPE 左上动臂润滑油管
29250000301 SHIM 垫片
29250000291 BOLT 通油螺栓
29250025513 Lamp bracket 左灯架
29250026391 Front fender 左挡泥瓦
29250009221 PIN 前转向销轴
4011001241 SCREW 螺栓GB5783-M12*25flZnyc-8.8-480
4043000438 BUSHING 轴套LGB302-50*36A2
008617753913626 SDLG woooyeah1@163.com
4043000032 SHIM 垫片LGB303-50*90*1
29370027091 Rubber damper 减震橡胶
29370027081 Tube 套筒
29250014941 PROTECTING COVER 前盖板总成
4015000425 WASHER 垫圈GB96.1-8flZnyc-300HV-480
4011001247 SCREW 螺栓GB5783-M8*20flZnyc-8.8-480
4043004620 Pin 销轴LGB301-100*140N*255-1000G
29250023861 Mirror 镜子
29260053485 Rear frame 后车架JR975
4011001387 Bolt 螺栓GB5783-M16*45flZnyc-10.9-480
008617753913626 SDLG woooyeah1@163.com
29270009381 PIN 销轴
4015000011 RETAINING RING 挡圈GB893.1-130-65Mn
4021000233 SPHERICAL PLAIN BEARING 关节轴承GB9163-GE90ES-2RS
29270009461 SEALING RING 防尘圈
29270009421 PLASTIC PLUG 塑料塞
29270009431 PIN 销
29270009441 SLEEVE 隔套
29270009451 SLEEVE 套
4030000260 SEALING RING 旋转轴唇形密封圈GB9877.1-B100*125*12
4011001329 SCREW 螺栓GB5782-M12*150flZnyc-8.8-480
4015000026 SPRING WASHER 垫圈GB93-12-65Mn
4015000428 WASHER 垫圈GB97.1-12flZnyc-300HV-480
008617753913626 SDLG woooyeah1@163.com
29270009471 DISC 盘
4043002667 Shim 开口垫片LGB338-4*15*170*0.2
4043002666 Shim 开口垫片LGB338-4*15*170*0.1
4043002664 Shim 开口垫片LGB338-4*15*170*0.5
4021000231 ROLLER BEARING 滚动轴承GB297-32316
29270009911 SLEEVE 隔套
29270009511 DISC 盘
4013000368 NUT 螺母GB6170-M12flZnyc-8-480
29270009521 SLEEVE 套
4043002668 Shim 开口垫片LGB338-2*19*105*0.1
4043002669 Shim 开口垫片LGB338-2*19*105*0.15
4043002670 Shim 开口垫片LGB338-2*19*105*0.5
4043002671 Shim 开口垫片LGB338-2*19*105*1.2
008617753913626 SDLG woooyeah1@163.com
29270009571 DISC 盘
4015000436 WASHER 垫圈GB97.1-16flZnyc-300HV-480
4011001328 SCREW 螺栓GB5783-M16*50flZnyc-8.8-480
4011001267 SCREW 螺栓GB5782-M16*90flZnyc-8.8-480
4011001241 SCREW 螺栓GB5783-M12*25flZnyc-8.8-480
4040000050 WASHER 垫圈LGB001-12flZnyc-480
29270009581 PIN 转向销轴
4043000032 SHIM 垫片LGB303-50*90*1
29270009101 RUBBER SLEEVE 走线胶套
008617753913626 SDLG woooyeah1@163.com
4015000426 WASHER 垫圈GB96.1-10flZnyc-300HV-480
4011001248 SCREW 螺栓GB5783-M10*25flZnyc-8.8-480
29270011431 FOOT STEP 圆形踏脚
29270011441 FOOT STEP 圆形踏脚
4015000425 WASHER 垫圈GB96.1-8flZnyc-300HV-480
4011001397 SCREW 螺栓GB5783-M8*25flZnyc-8.8-480
29270026383 Cover plate 右挡板
4043003036 Sealing strip 卡子胶条LGB320-U610
29270027461 Lubricating pipe 右润滑油管
29270014461 LUBRICATING PIPE 油管
29270028591 Plate 压板
4011001246 SCREW 螺栓GB5783-M8*16flZnyc-8.8-480
4011001270 SCREW 螺栓GB5783-M10*35flZnyc-8.8-480
4015000433 WASHER 垫圈GB97.1-10flZnyc-300HV-480
008617753913626 SDLG woooyeah1@163.com
4190001829 ABSORBER 缓冲器
29250014121 NIPPLE 接头
29270027441 Lubricating pipe 左润滑油管
29270026361 Cover plate 左挡板
29250000291 BOLT 通油螺栓
29250000301 SHIM 垫片
29270027502 Lubricating pipe 后润滑油管
29270027481 Lubricating pipe 前润滑油管
29280018012 Counterweight 平衡铁2500
29280015861 Battery retainer 蓄电池固定总成
4043004545 Rubber sleeve 护套LGB313-B10*80*125
29280014301 Towing pin 牵引销
4013000064 LOCK NUT 螺母GB889.2-M30*2EpZn-8
4011000703 BOLT 螺栓GB5785-M30*2*330EpZn-8.8
008617753913626 SDLG woooyeah1@163.com
29280015121 Lamp shroud 防护网
4014000624 Screw 螺钉GB70.1-M6*12flZnyc-8.8-480
4015000424 WASHER 垫圈GB97.1-6flZnyc-300HV-480
4190000025 LOCK 扣锁NBxs1013
29280016761 Plate 盖板
4011001247 SCREW 螺栓GB5783-M8*20flZnyc-8.8-480
4015000425 WASHER 垫圈GB96.1-8flZnyc-300HV-480
29280015871 Plate 电源开关固定板
4014000515 SCREW 螺钉GB818-M5*10flZnyc-4.8-480
4015000431 WASHER 垫圈GB97.1-5flZnyc-300HV-480
008617753913626 SDLG woooyeah1@163.com
29270009421 PLASTIC PLUG 塑料塞
29280015841 Plate 压板
29280010841 RUBBER PLATE 胶板
4011001008 SCREW 螺栓GB5782-M10*250EpZn-8.8
4015000426 WASHER 垫圈GB96.1-10flZnyc-300HV-480
4043001989 Rubber plate 橡胶板LGB332-A180*60*25
4043001983 Rubber plate 橡胶板LGB332-A180*60*10
008617753913626 SDLG woooyeah1@163.com
29290058066 Cab 驾驶室总成
29430008231 Cab electric system 驾驶室外置电气总成
4130003077 Rocker switch 后雨刮开关CV4B2AJ0B-HYG
29290058051 Cab 驾驶室系统
