Description

4110000046 SCREW 螺栓LG05-LS1/2＂-20UNF
4110001858005
4015000202 WASHER 垫圈LG05-DQ1/2＂
29080000051 PROPELLER SHAFT 后传动轴
4110000463002 SCREW 螺栓1/2″UNF
4110001858005
4120001054234 WASHER 垫圈GB93-87 12
008617753913626 XCMG woooyeah1@163.com
2908000753001 SPIDER 万向节十字轴总成G5-7126
4110001950008 SCREW 螺栓 1/2″20UNF
4110001858005
4110002086003 GREASE CUP 油杯M6 JB/T7940.1-1995
4030000535
29070000021 Wheel assembly 车轮总成
4190000237 RIM 轮辋LG19.50/2.5-25
4110000006 TIRE 轮胎GB2980-23.5-25
4110000006L)
4110000006X)
4110000006S)
4110000006Z)
4110000006L)
4110000006X)
4110000006S)
4110000006Z)
4110000006L)
4110000006X)
4110000006S)
4110000006Z)
4110000006L)
4110000006X)
4110000006S)
4110000006Z)
4110000006L)
4110000006X)
4110000006S)
4110000006Z)
29090000091 BRACKET 后桥支架
29090008801 REAR AXLE A510A摆动桥总成
008617753913626 XCMG woooyeah1@163.com
29090007982 SCREW 螺栓
4013000064 LOCK NUT 螺母GB889.2-M30*2EpZn-8
29090009641 REAR AXLE A510A后驱动桥总成
29090000062 SLEEVE 衬套
4015000098 SPRING WASHER 垫圈GB93-16-65Mn
4011000244 BOLT 螺栓GB5786-M16*1.5*50EpZn-8.8
29090000051 SLEEVE 套
29090000091 BRACKET 后桥支架
4041000021 O-RING O形圈LGB308-260*3.5
29090000151 SUPPORT SHAFT 支承轴
4015000026 SPRING WASHER 垫圈GB93-12-65Mn
4011000090 BOLT 螺栓GB5783-M12*35EpZn-8.8
29090000101 SEALING COVER 密封盖
4030000021 O-RING O形圈GB3452.1-160*5.30G
008617753913626 XCMG woooyeah1@163.com
29090000141 END PLATE 端盖
29090000121 SHIM 衬垫
4011000113 BOLT 螺栓GB5785-M20*1.5*90EpZn-8.8
4015000030 SPRING WASHER 垫圈GB93-20-65Mn
29090000131 BLOCK 垫块
4011000064 BOLT 螺栓GB5782-M12*50EpZn-8.8
29090000161 SHIM 垫片
29090000112 SLEEVE 轴套
29070000081 NUT 轮辋螺母
29070015101 SEALING COVER 油封端盖
4021000038 ROLLER BEARING 滚动轴承GB297-32224
29070012892 Gear ring 齿圈支架总成
29070015792 Gear ring 内齿圈
29070026451
29070010931 FRONT WHEEL HUB 轮毂
29070000621 STUD 轮辋螺栓
008617753913626 XCMG woooyeah1@163.com
4013000203 NUT 螺母GB6171-M20*1.5EpZn-10
4015000030 SPRING WASHER 垫圈GB93-20-65Mn
4041000020 O-RING O形圈LGB308-440*3.5
29070012661 PLANET CARRIER 行星轮架
29070012481 PLUG 磁性螺塞
4011000084 BOLT 螺栓GB5783-M10*30EpZn-8.8
4015000025 SPRING WASHER 垫圈GB93-10-65Mn
29070007621 COVER 盖
29070009161 BLOCK 定位块
4090000006 BALL 钢球GB308-17.462-GCr15
4015000022 RETAINING RING 挡圈GB894.1-52-65Mn
008617753913626 XCMG woooyeah1@163.com
29070012671 SUN GEAR 太阳轮
29070012681 SHIM 行星轮垫片
4090000008 BALL 钢球GB308-9.525-GCr15
29070012691 PLANET GEAR SHAFT 行星齿轮轴
29070012701 RETAINING RING 挡环
29070012711 PLANET GEAR 行星齿轮
4090000158 NEEDLE ROLLER 滚针GB309-P6*54-GCr15
29070015591 ROUND NUT 圆螺母
4014000118 SCREW 螺钉GB70-M8*1*20-8.8
4021000034 ROLLER BEARING 滚动轴承GB297-32028
29070000581 SPACER SLEEVE 隔套
29070000591 GASKET 密封垫
4030000146 SEALING RING 油封HG4-692-SG170*200*15
4011000298 BOLT 螺栓GB5782-M8*45EpZn-8.8
4015000036 SPRING WASHER 垫圈GB93-8-65Mn
008617753913626 XCMG woooyeah1@163.com
29070015111 DUST COVER 防尘罩
4120001739 BRAKE CALIPER 制动钳
4120001740 NIPPLE 放气嘴
4015000030 SPRING WASHER 垫圈GB93-20-65Mn
29070000101 BOLT 螺栓
29070012581 SHAFT HALF 半轴
29090009481 FINAL DRIVE 后主传动总成
4011000494 BOLT 螺栓GB5786-M16*1.5*45EpZn-8.8
4015000098 SPRING WASHER 垫圈GB93-16-65Mn
4016000124 PIN 销GB119.2-10u8*30
4110000818 NOZZLE 透气嘴
29090009381 REAR AXLE CASING 后桥壳总成
29070000071 DISC BRAKE 制动盘
4011000130 BOLT 螺栓GB5786-M20*1.5*50EpZn-8.8
008617753913626 XCMG woooyeah1@163.com
29070012881 HUB REDUCTION 轮边减速器
29090008851 NAME PLATE 后桥标牌
4019000012 RIVET 铆钉GB827-3*5-BL2
29070012481 PLUG 磁性螺塞
29070000151 SHIM 调整垫片
29070000161 SHIM 调整垫片
29070000171 SHIM 调整垫片
4011000067 BOLT 螺栓GB5782-M14*55EpZn-8.8
4015000027 SPRING WASHER 垫圈GB93-14-65Mn
4013000066 LOCK NUT 螺母GB889.2-M33*1.5-8
29070000221 WASHER 垫圈
4030001002 SEALING RING 密封圈GB13871.1-FB08010010-D
4030000035 O-RING O形圈GB3452.1-53.0*5.30G
29070000241 RETAINING RING 挡圈
4030000789 SEALING RING 密封圈GB13871.1-FB08010012-F
29070000251 SEALING COVER 密封盖
4011000186 BOLT 螺栓GB5782-M12*55EpZn-8.8
4015000026 SPRING WASHER 垫圈GB93-12-65Mn
008617753913626 XCMG woooyeah1@163.com
29070000261 GASKET 密封垫
4021000030 ROLLER BEARING 滚动轴承GB297-31313
29070000271 BEARING SEAT 轴承座
29070022561 SLEEVE 隔套
4021000032 ROLLER BEARING 滚动轴承GB297-31314
29090008841 CROWN WHEEL 主动螺旋伞齿轮（右）
29070000301 SCREW 止推螺栓
4013000052 NUT 螺母GB6173-M27*2-05
29070000311 LOCK WASHER 锁紧片
008617753913626 XCMG woooyeah1@163.com
4021000027 ROLLER BEARING 滚动轴承GB283-NUP2307
4015000020 RETAINING RING 挡圈GB894.1-35-65Mn
4041000019 O-RING O形圈LGB308-430*3.5
29070000321 CENTER HOUSING 托架
2050900104
