Description

07346-72202 steering pump for Shantui

10030111 GB5783-M10×25 螺栓 Bolt
13010005 GB93-10 垫圈 Washer
82090099 154-33-21262 轴 Shaft
16020037 JB/ZQ4224-36×3.5 O型圈 O-ring
16020038 JB/ZQ4224-31×3.5 O型圈 O-ring
14050037 GB1096-10×25 键 Key
36210261 170-21-12141 螺帽 Nut
10030102 GB5783-M12X25 螺栓 Bolt
13020012 GB97.1-12 垫圈 Washer
33080292 195-27-12620 锁垫 Lock
33080293 170-27-11232 垫圈 Washer
33040273 175-27-31463 法兰盘 Flange
25210198 07013-10120 骨架油封 Oil Seal
10030065 GB5783-M16X40 螺栓 Bolt
13010023 GB7244-16 垫圈 Washer
33020176 154-27-11262 轴承座 Bearing Cage
22210020 07000-05225 O型密封圈 O-ring
25210192 170-09-13160 圆柱滚子轴承 Roller Bearing
35070044 154-27-11256 小齿轮 First Pinion
25210193 150-09-13260 圆柱滚子轴承 Roller Bearing
16020020 JB/ZQ4224-160X5.7 O型密封圈 O-ring
33050062 154-27-11144 盖 Cover
13010010 GB93-20 垫圈 Washer
10030121 GB5783-M20X50 螺栓 Bolt
10030115 GB5783-M12X30 螺栓 Bolt
33080302 154-27-11383 内锁板 Lock
33020186 154-27-11392 内夹板 Holder
33070075 154-27-21341 隔片 Spacer
34020025 154-27-11313 齿轮 Gear
36210269 154-27-11330 键 Key
35070045 154-27-11327 小齿轮 Second Pinion
25210194 150-09-13240 圆柱滚子轴承 Roller Bearing
33040272 154-27-11373 外夹板 Holder
33070072 154-27-11420 外锁片 Lock
16020036 JB/ZQ4224-230X5.7 O型密封圈 O-ring
33020179 154-27-11191 盖 Cover
22210023
22210023 “07000-05410
07000-05410” “O型密封圈 “O-ring
33020177 154-27-12152 盖 Cover
13010006
13010006 “GB93-12
GB93-12 “垫圈 “Washer
10030115
10030115 “GB5783-M12X30
GB5783-M12X30” “螺栓
25210196 170-27-12520 O形密封圈 O-ring
36210268 170-27-12513 浮动油封 Floating Oil Sealing
33020178 154-27-12162 盖 Cover
33070079 04071-00250 挡圈250 Retainer
25210197 150-09-13110 圆柱滚子轴承 Roller Bearing
36060191 175-27-12181 螺栓 Bolt
34020024 154-27-12110 大齿轮 Gear
34040005 154-27-12122 齿轮毂 Gear Sprocket
33080300 175-27-12190 锁片 Lock Plate
25210221 01582-12419 螺母 Nut
25210195 170-09-13250 双列圆柱滚子轴承 Roller Bearing
33070074 154-27-12560 挡圈 Retainer
33080301 170-27-12210 锁垫 Lock Washer
10030053 GB5783-M14X40 螺栓 Bolt
10030137 GB5783-M12X20 螺栓 Bolt
33080304 175-27-31540 锁片 Lock Plate
33070077 154-27-11410 板 Plate
33080294 154-27-11130 密封垫 Seal Pad
33050063 154-27-11113 左终传动箱 Case,Final Drive L.H
33050085
33050064
33050086
36210272
14020014
10030078
33080309
82040465
82040466
10030121
13010010
82040675
154-27-11123
07049-02025
GB119.2-20×40
GB5783-M20X45
01605-12040
154-27-15110
154-27-15120
GB5783-M20X50
GB93-20” “左箱体
36060192 155-27-12181 螺栓 Bolt
36210262 154-27-12131 链轮毂 Sprocket Boss
36210270 154-27-12273 链轮齿 Sprocket Teeth
36210271 154-27-12283 链轮齿 Sprocket Teeth
36060195 01803-02228 螺母M22 Nut
31810120 170-27-12480 环 Ring
14030076 GB882-12X30 销轴 Pin
36210267 170-27-12472 螺母 Nut
35010089 154-27-12313 半轴 Shaft
35040046 175-27-32510 定位销 Pin
22210022 07000-05315 O型密封圈 O-ring
36210263 170-27-12232 链轮毂螺帽 Hub Nut
33070076 154-27-31480 锁挡 Stopper
35040047 170-27-12250 定位销 Pin
13010023 GB7244-16 垫圈 Washer
11020071 GB70.1-M16X35 螺钉 Screw
33060220 154-27-12352 隔套 Spacer
36210266 170-27-12340 O形密封圈 O-ring
36210265 198-30-16612 浮动油封 Floating Oil Sealing
14020026 GB119.2-16X40 销 Pin
33060219 154-27-12334 支承 Sprocket Support
33060221 154-27-12341 轴瓦 Bushing
33080298 154-27-12424 衬垫 Spacer
36210264 154-27-12412 螺帽 Nut
33070073 154-27-15240 垫板 Plate
33080299 154-27-15250 锁片 Lock Plate
